GE Fanuc IC695STK010 RX3i PROFINET Starter Kit Overview

The GE Fanuc IC695STK010 is a complete RX3i PROFINET starter kit. This kit includes everything needed to begin a PACSystems RX3i project. The IC695STK010 comes with a CPE305 CPU for powerful control capabilities. A 7-slot base provides ample space for additional I/O modules. An AC power supply powers the entire system reliably. Furthermore, input and output modules are included for basic I/O connectivity. Consequently, this starter kit is ideal for testing, training, and small-scale applications.

Kit Components

The GE Fanuc IC695STK010 contains several essential components for a complete control system. First, the CPE305 CPU serves as the heart of the RX3i system. This processor supports PROFINET communication for high-speed industrial networking. Second, the 7-slot backplane allows expansion with up to seven modules total. Third, the AC power supply converts standard industrial AC power to DC for the backplane. Fourth, an input module accepts field device signals. Fifth, an output module controls actuators and indicators. Therefore, the IC695STK010 provides a fully functional PLC system out of the box.

CPE305 CPU Specifications

The CPE305 CPU included in the GE Fanuc IC695STK010 delivers reliable performance for control applications. This processor features a built-in PROFINET port for high-speed communication. It supports up to 128 MB of user memory for large programs and data tables. The CPE305 also includes a USB port for easy program transfer and firmware updates. Consequently, this CPU handles demanding automation tasks with ease.

7-Slot Base & Power Supply

The 7-slot base included with the GE Fanuc IC695STK010 provides flexible expansion options. Up to seven modules can be installed in any combination. Slots accommodate CPUs, power supplies, communication modules, and I/O modules. The AC power supply converts 120/230 V AC to the required DC voltages. Therefore, no external DC power supply is needed for basic operation.

Included I/O Modules

The GE Fanuc IC695STK010 includes both input and output modules for immediate connectivity. The input module typically provides discrete input points for switches and sensors. The output module typically provides discrete output points for relays and indicators. Exact module part numbers may vary based on kit configuration. Therefore, confirm specific I/O module details at the time of order.

Key Features & Benefits

• Complete starter package – The IC695STK010 includes CPU, rack, power supply, and I/O modules.

• CPE305 PROFINET CPU – Provides high-speed industrial networking and powerful processing.

• 7-slot expansion capacity – Allows room for additional modules as your application grows.

• AC power supply – Operates directly from standard industrial AC power sources.

• Ready to use – No additional components needed for basic PLC operation.

• RX3i PacSystems platform – Compatible with the full range of RX3i modules.

Installation Guidelines

Follow these steps to set up the GE Fanuc IC695STK010 starter kit correctly. First, mount the 7-slot base securely in a control panel. Second, install the AC power supply in the leftmost slot of the base. Third, install the CPE305 CPU in the next available slot. Fourth, install the input and output modules in the remaining slots. Fifth, connect AC power to the power supply terminals. Finally, apply power and connect a programming PC via Ethernet or USB.

Use Proficy Machine Edition software to program the CPE305 CPU. The IC695STK010 requires proper grounding for reliable operation. Leave adequate clearance around the rack for cooling airflow.

Package Contents

Your shipment includes the following items:

• 1 x GE Fanuc IC695STK010 RX3i PROFINET starter kit

• 1 x CPE305 PROFINET CPU module

• 1 x 7-slot backplane (base)

• 1 x AC power supply module

• 1 x Input module (discrete or analog, kit dependent)

• 1 x Output module (discrete or analog, kit dependent)

• 1 x Quick start guide with basic setup instructions

No programming software is included with the IC695STK010. Therefore, you must order Proficy Machine Edition separately. No communication cables are provided.

Frequently Asked Questions (FAQ)

1. What software is required to program this starter kit?
The GE Fanuc IC695STK010 requires Proficy Machine Edition software. This software is sold separately from the hardware kit.

2. Can I add more I/O modules to this system?
Yes. The IC695STK010 includes a 7-slot base. After installing the CPU, power supply, and included I/O modules, additional slots remain for expansion.

3. What is the CPE305 CPU's memory capacity?
The CPE305 CPU included in the IC695STK010 supports up to 128 MB of user memory. This capacity suits mid-range control applications.

4. Is PROFINET already configured on the CPE305?
The CPE305 CPU in the IC695STK010 has PROFINET hardware built-in. However, you must configure the network settings using Proficy Machine Edition software.

5. What is the weight of this starter kit?
The GE Fanuc IC695STK010 weighs approximately 20.00 lbs (9.07 kg). This includes all components and packaging.

Why Choose the GE Fanuc IC695STK010?

This RX3i PROFINET starter kit delivers everything needed for a complete PLC system. For starters, the GE Fanuc IC695STK010 includes a powerful CPE305 CPU with built-in PROFINET. The 7-slot base provides room for the power supply, CPU, and additional I/O modules. An AC power supply eliminates the need for external DC power conversion. Input and output modules are included for immediate connectivity to field devices. Consequently, the IC695STK010 is ready for testing, training, or small-scale automation projects right out of the box. The RX3i PacSystems platform supports a wide range of additional modules for future expansion. Furthermore, PROFINET communication enables high-speed integration with other devices and SCADA systems. Most importantly, this starter kit provides a cost-effective entry point into the GE Fanuc RX3i ecosystem.

Order the GE Fanuc IC695STK010 today for your RX3i project needs. Specifically, this starter kit is perfect for system testing, operator training, prototype development, and small machine control applications requiring PROFINET communication.
