Bently Nevada 200151-40-03-00 Accelerometer Cable
Introduction:
Bently Nevada accelerometer interface cable. 4.0 meter length. Blue cable with armor. Standard coupling nuts on both ends.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Overview
The Bently Nevada 200151-40-03-00 is an accelerometer interface standard cable. This cable features connectors on both ends for straightforward installation. The 200151-40-03-00 measures 4.0 meters in total length. Industrial users trust this cable for reliable accelerometer connections in demanding environments.
This cable uses a blue PVC outer jacket with full armor protection. The standard coupling nuts provide secure attachment. The molded connectors create an IP67 seal to transducers. Consequently, this cable suits machinery monitoring applications requiring extra mechanical protection.
Ordering Information Breakdown
The 200151-40-03-00 part number follows a clear ordering structure.
| Position | Code | Meaning |
|---|---|---|
| Model | 200151 | Accelerometer Interface Standard Cable, connectors on both ends |
| Cable length | -40 | 4.0 meters |
| Armor option | -03 | Blue cable with armor |
| Coupling nut | -00 | Standard coupling nut |
Technical Specifications
Mechanical Specifications
Construction: 4-conductor, 22 AWG with braided shield
Shield Coverage: 85% minimum with drain wire
Outer Jacket: PVC (blue)
Armor: Blue cable with armor (option -03)
Coupling Nut Material: Standard (nickel-plated)
Connector Type: Molded connectors on both ends
Minimum Bend Radius: 63.5 mm (2.5 inches)
Temperature Ratings
Operating Temperature Range: -20°C to +100°C (-4°F to +212°F)
Extended Temperature Range: -55°C to +121°C (-67°F to +250°F) for specific applications
Cure Time: 24 hours for DC4 compound
Environmental Protection
Connector Seal Rating: IP67 (to transducers and mating hardware)
Connector Protection: Molded with DC4 electrical insulating compound
Thermal Shock Protection: Added moisture protection from DC4 compound
Low Temperature Usage Note
These cables may be used at lower temperatures under certain conditions. Specifically, the installation must prevent the cable from flexing or bending. Flexing these cables at temperatures below -20°C (-4°F) may damage the cables. Therefore, careful installation planning is required for cold environments.
Key Features
The 200151-40-03-00 uses a 4-conductor 22 AWG construction. The braided shield provides 85% minimum coverage for noise rejection. In addition, the drain wire ensures proper grounding for signal integrity.
The blue PVC outer jacket offers flexibility and durability. The armor option -03 adds a protective layer against mechanical damage. This armored construction suits installations with potential abrasion or impact risks. As a result, the cable survives harsh industrial environments.
The standard nickel-plated coupling nuts resist corrosion. Both connectors are molded directly to the cable for superior strain relief. Furthermore, the connectors provide an IP67 seal to transducers and mating hardware.
The DC4 electrical insulating compound adds extra moisture protection. This compound also protects during thermal shock events. Consequently, the cable performs reliably in challenging environmental conditions.
The minimum bend radius is 63.5 mm (2.5 inches). Following this bend limitation prevents internal conductor damage. Therefore, signal integrity remains consistent over the cable's service life.
Installation Guidelines
Install the 200151-40-03-00 with careful attention to bend radius. Do not bend the cable tighter than 63.5 mm (2.5 inches). Secure the cable using appropriate clips or ties at regular intervals.
Connect both ends to compatible Bently Nevada accelerometers. Hand-tighten the standard coupling nuts until secure. Do not overtighten the nuts as this may damage the connectors. The armored jacket provides additional protection during routing.
For low temperature installations below -20°C, follow special precautions. Specifically, prevent the cable from any flexing or bending. Use rigid cable trays or conduits in cold environments. Allow 24 hours cure time for DC4 compound before full operation.
Route the armored cable away from sharp edges and heat sources. The armor protects against abrasion but does not prevent heat damage. Inspect the cable periodically for signs of wear or damage.
Package Contents
Bently Nevada 200151-40-03-00 Accelerometer Cable (1 unit)
Standard coupling nuts (factory installed, nickel-plated)
Protective caps for connectors (shipping)
Frequently Asked Questions (FAQ)
1. What is the length of the Bently Nevada 200151-40-03-00 cable?
The 200151-40-03-00 is 4.0 meters in length as indicated by the -40 option. The cable has connectors on both ends for straightforward installation.
2. Does this 200151 cable include armor protection?
Yes. The armor option -03 specifies blue cable with armor. This armored construction provides extra protection against mechanical damage, abrasion, and impact.
3. What type of coupling nuts does this cable use?
The 200151-40-03-00 uses standard coupling nuts (option -00). These nuts are nickel-plated for corrosion resistance. The connectors are molded directly to the cable.
4. What is the operating temperature range of the 200151-40-03-00?
The standard operating range is -20°C to +100°C (-4°F to +212°F). The extended temperature range is -55°C to +121°C for specific applications. However, flexing below -20°C may damage the cable.
5. What is the minimum bend radius for this Bently Nevada armored cable?
The minimum bend radius is 63.5 mm (2.5 inches) for the 200151 series. This applies to both armored and non-armored versions. Following this limitation prevents internal conductor damage.
