ABB V18348-10111310110 – TZIDC-200 Digital Positioner with HART Communication

The ABB V18348-10111310110 is a TZIDC-200 digital positioner. Specifically, this device features a flameproof enclosure. It is intelligent and software-configurable. Furthermore, it includes Local Communication Interface (LKS) and HART communication. Consequently, this positioner delivers high-precision control with optimal operational reliability.

Ordering Configuration and Options

• Model: V18348 TZIDC-200 Digital Positioner.

• Case/Mounting (1 0): Aluminum varnished case for linear or rotary actuators (DIN/IEC 534/NAMUR or VDI/VDE 3845).

• Operation (1): Operator panel and display integrated in enclosure cover.

• Explosion Protection (1): ATEX Ex d II C T4/T5/T6 Gb.

• Output/Safe Position (1): Single acting, fail safe.

• Connections (3): Cable thread 1/2-14 NPT, air pipe thread 1/4-18 NPT.

• Analog Feedback Module (1): Plug-in module for 4-20 mA two-wire analog position feedback.

• Mechanical Feedback Kit (0): Without.

• Parameter Setting (1): Factory setting for HART devices.

• Design (1): Standard varnish and coding.

• Device Label (0): Without.

• Therefore, the ABB V18348-10111310110 offers complete configuration flexibility.

Operating Parameters

• Signal Range: Minimum 4 mA, maximum 20 mA (0-100%).

• Split-Range Operation: Freely selectable with minimum range 20% (3.2 mA).

• Recommended Range: >50% (8.0 mA).

• Action (Signal): Direct (4-20 mA = 0-100%) or reverse (20-4 mA = 0-100%).

• Characteristic Curve: Linear, equal percentage (1:25, 1:50, 25:1, 50:1), or user-configurable with 20 reference points.

• Travel Limit: Reducible within 0-100% range (minimum 20% observed).

• Shut-off Function: Separately configurable for each end position.

• Travel Time Prolongation: Max travel time increase configurable per direction.

• Switching Points: Two position limits for signalling via digital feedback module.

• Digital Output: Polls alarms as collective alarm; configurable active high or low.

• Digital Input: Selectable functions including move to 0% or 100%, hold position, disable local config, disable any access.

• Digital Input Activation: Function activates when 24 V DC signal drops below 10 V DC.

• Thus, the ABB V18348-10111310110 provides extensive parameter customization.

Adjustment and Control Parameters

• Tolerance Band: Factory setting 0.3%; position considered corrected when reached.

• Dead Band: Factory setting 0.1%; position held when reached.

• Actuator Spring Action: Selectable sensor shaft rotating sense for safe position movement.

• Zero Position: Adjustable display (0-100%) for opening or closing direction.

• Auto-Adjustment: Special function for automatic parameter adjustment.

• Control Mode: Adaptive (automatic) or manual control parameter setting.

• Therefore, the TZIDC-200 optimizes adaptation to process requirements.

Monitoring and Diagnosis Parameters

The total range of parameters includes operating parameters, adjustment parameters, monitoring parameters, diagnosis parameters, and maintenance parameters. Consequently, the ABB V18348-10111310110 supports comprehensive device diagnostics. The microprocessor-based position control provides for optimal results. High operational reliability is guaranteed through elaborate structure and easy accessibility. Device parameters can be quickly adapted to respective applications.

Installation Guide

First, mount the ABB V18348-10111310110 to your linear or rotary actuator. Use the aluminum case with standard varnish finish. Then, connect the 1/2-14 NPT cable thread for electrical wiring. After that, connect the 1/4-18 NPT air pipe threads for pneumatic supply. Next, apply 4-20 mA HART signal to the positioner. Ensure the minimum signal is 4 mA and maximum is 20 mA. Then, configure the action (direct or reverse) as required for your valve. Subsequently, perform auto-adjustment of control parameters. Alternatively, set tolerance band and dead band manually. Finally, test the shut-off function and travel limits. As a result, the ABB V18348-10111310110 will deliver precise valve positioning.

Packaging List

• One ABB V18348-10111310110 TZIDC-200 digital positioner

• One integrated operator panel and display

• One plug-in analog position feedback module (4-20 mA)

• One mounting kit for linear or rotary actuators

• One quick start configuration guide

Common FAQs

Q1: What communication protocols does the ABB V18348-10111310110 support?
A: This positioner supports HART communication. It also includes Local Communication Interface (LKS). Therefore, it integrates easily with existing control systems.

Q2: Is this positioner suitable for hazardous areas?
A: Yes, absolutely. The ABB V18348-10111310110 has ATEX Ex d II C T4/T5/T6 Gb certification. Specifically, it features a flameproof enclosure. Consequently, it suits explosive atmospheres.

Q3: What output configuration does this model provide?
A: This model provides single acting output with fail safe position. In case of electrical power failure, the actuator moves to safe position. Therefore, it ensures process safety.

Q4: Can I adjust the travel limits on the TZIDC-200?
A: Yes, travel limits are adjustable within 0-100% range. However, a minimum value of 20% must be observed. The shut-off function can be set separately for each end position.

Q5: What analog feedback does the ABB V18348-10111310110 include?
A: This model includes a plug-in analog position feedback module. Specifically, it provides 4-20 mA signal range, two-wire configuration. Consequently, it enables remote position monitoring.
