Product Overview for the ANB10D-425/CU2N ESB Bus Node Unit

The ANB10D-425/CU2N is an ESB Bus Node Unit from Yokogawa. Firstly, this device is designed for dual-redundant ESB bus applications. Specifically, the ANB10D model serves as a node unit for high-availability control systems. In addition, the ANB10D-425/CU2N includes dual-redundant power supplies for maximum reliability. The /CU2N option adds a dedicated connector unit for ESB bus connections. Consequently, this node unit provides robust communication between field devices and the control system. Moreover, the 19-inch rack mounting design simplifies installation in standard industrial cabinets. Therefore, the ANB10D-425/CU2N is ideal for critical process applications requiring uninterrupted bus communication.

Model Number Breakdown

The ANB10D-425/CU2N part number contains several meaningful sections. Firstly, ANB10D identifies the base model as a Node Unit for Dual-Redundant ESB Bus. The suffix -4 indicates dual-redundant power supply configuration for high availability. In addition, suffix 2 specifies a 220 to 240 V AC power supply input. Specifically, suffix 5 denotes basic type with no explosion protection. The option code /CU2N adds a Connector Unit for ESB Bus connectivity. Consequently, the ANB10D-425/CU2N provides a complete, ready-to-install node unit for ESB bus networks. Therefore, this configuration suits standard industrial environments without hazardous area requirements.

Key Features and Benefits

Dual-Redundant Power Supply
The ANB10D-425/CU2N features dual-redundant power supplies for fault tolerance. Firstly, two power supply modules operate in parallel for continuous operation. In addition, if one supply fails, the other immediately takes full load without interruption. Specifically, the -4 suffix code explicitly indicates this dual-redundant configuration. Consequently, the ANB10D-425/CU2N maintains bus communication even during power supply maintenance. Therefore, critical processes continue running without disruption.

Flexible Power Input Options
The ANB10D-425/CU2N accommodates various site power configurations. Firstly, suffix code 2 specifies 220 to 240 V AC at 50/60 Hz for this model. In addition, other suffix options support 100 to 120 V AC or 24 V DC as alternatives. Specifically, the power consumption at 220 to 240 V AC is 230 VA and 120 W. Therefore, the ANB10D-425/CU2N adapts to global electrical standards.

Integrated ESB Bus Connector Unit
The ANB10D-425/CU2N includes the /CU2N option for ESB bus connectivity. Firstly, this connector unit provides reliable physical connections for the dual-redundant bus. In addition, it simplifies field wiring by consolidating bus connections in one location. Specifically, the connector unit is factory-installed and tested with the node unit. Consequently, the ANB10D-425/CU2N reduces installation time and eliminates field wiring errors.

High I/O Module Capacity
The ANB10D-425/CU2N supports up to 8 I/O modules in a single unit. Firstly, the weight of approximately 10 kg includes 8 I/O modules when fully populated. In addition, this high density reduces cabinet space requirements compared to distributed I/O solutions. Specifically, each I/O module connects to the ESB bus through the node unit. Therefore, the ANB10D-425/CU2N efficiently serves as a centralized I/O hub for control system applications.

Redundancy and Reliability Features

Dual-Redundant ESB Bus Support
The ANB10D-425/CU2N is designed for dual-redundant ESB bus architecture. Firstly, two independent bus paths connect the node unit to the field control station. In addition, the node unit automatically selects the active bus path for communication. Specifically, if one bus path fails, the other path continues operation seamlessly. Consequently, the ANB10D-425/CU2N provides fault-tolerant communication for critical processes.

Dual Power Supply Redundancy
The -4 suffix code on the ANB10D-425/CU2N provides power supply redundancy. Firstly, two power supply modules share the load under normal conditions. In addition, each power supply can handle the full load independently. Specifically, hot-swappable design allows replacement without powering down the node unit. Therefore, the ANB10D-425/CU2N achieves exceptional power availability for continuous processes.

Technical Specifications of the ANB10D-425/CU2N

General Specifications

• Manufacturer: Yokogawa.

• Product No.: ANB10D-425/CU2N.

• Product Type: ESB Bus Node Unit.

• Model: ANB10D = Node Unit for Dual-Redundant ESB Bus.

• Weight: Approx. 10 kg (including 8 I/O modules).

Suffix Code Specifications

• -4: Dual-redundant power supply.

• 2: 220 to 240 V AC power supply.

• 5: Basic type with no explosion protection.

Option Code Specifications

• /CU2N: Connector Unit for ESB Bus.

Power Supply Specifications (Suffix Code 2)

• Voltage: 220 to 240 V AC.

• Frequency: 50/60 Hz.

• Power Consumption (VA): 230 VA.

• Power Consumption (W): 120 W.

Alternative Power Supply Specifications (for reference)

• 100 to 120 V AC: 200 VA, 120 W at 50/60 Hz.

• 24 V DC: 5.5 A.

Mechanical Specifications

• Mounting Type: 19-inch Rack Mounting.

• Mounting Hardware: Rack mount (M5 x 4 screws).

• Included Accessories: Insulation bush (accessory).

• I/O Module Capacity: Supports up to 8 I/O modules.

Installation Guide for the ANB10D-425/CU2N

Follow these steps for a proper installation of the ANB10D-425/CU2N.

Step 1: Rack Mounting Preparation
Firstly, ensure your 19-inch rack has sufficient depth for the ANB10D-425/CU2N. Then, verify that the rack is securely anchored to the floor or wall. The node unit weighs approximately 10 kg when fully populated with I/O modules.

Step 2: Node Unit Installation
After that, slide the ANB10D-425/CU2N into the 19-inch rack from the front. Align the mounting holes with the rack rails. Then, secure the unit using four M5 screws through the mounting brackets. Install the included insulation bush accessories as required.

Step 3: Power Supply Connection
Then, connect the 220 to 240 V AC power source to the ANB10D-425/CU2N. The dual-redundant power supplies require separate input feeds for full redundancy. Verify that both power supplies receive voltage within the specified range.

Step 4: ESB Bus Wiring
Furthermore, connect the ESB bus cables to the /CU2N connector unit. The dual-redundant bus requires two separate cable runs for fault tolerance. Follow Yokogawa wiring guidelines for proper termination and shielding.

Step 5: I/O Module Installation and Testing
Finally, install up to 8 I/O modules into the ANB10D-425/CU2N as needed. Apply power to both redundant power supplies. Then, verify communication with the field control station over both ESB bus paths. Check that the node unit recognizes all installed I/O modules correctly.

Packaging List for the ANB10D-425/CU2N

• ANB10D-425/CU2N ESB Bus Node Unit (1 unit)

• /CU2N Connector Unit for ESB Bus (pre-installed)

• Insulation bush accessories (1 set)

• Mounting screws (M5 x 4)

• Product documentation and installation guide (1 copy)

Frequently Asked Questions (FAQs) About the ANB10D-425/CU2N

Q1: What is the purpose of the ANB10D-425/CU2N in a Yokogawa system?

The ANB10D-425/CU2N serves as an ESB Bus Node Unit for dual-redundant communication. It connects up to 8 I/O modules to the field control station. Therefore, it is a central component for distributed I/O architecture.

Q2: What power supply options are available for the ANB10D-425/CU2N?

The ANB10D-425/CU2N with suffix code 2 uses 220 to 240 V AC at 50/60 Hz. Other suffix codes support 100 to 120 V AC or 24 V DC inputs. Therefore, choose the appropriate suffix code for your site power availability.

Q3: Does the ANB10D-425/CU2N include the ESB connector unit?

Yes, it does. The ANB10D-425/CU2N includes the /CU2N option code. This adds a Connector Unit for ESB Bus connectivity. Consequently, you do not need to order a separate connector unit for this node.

Q4: What does the -4 suffix code mean on the ANB10D-425/CU2N?

The -4 suffix code indicates dual-redundant power supply configuration. Two power supply modules provide fault tolerance for continuous operation. Therefore, if one power supply fails, the node unit continues functioning without interruption.

Q5: How many I/O modules can the ANB10D-425/CU2N support?

The ANB10D-425/CU2N supports up to 8 I/O modules in a single unit. The approximate weight of 10 kg includes 8 I/O modules when fully populated. Therefore, plan your I/O count accordingly to stay within the node unit capacity.
