Siemens 6AR1306-0HC00-0AA0 Power Supply Module Overview

The Siemens 6AR1306-0HC00-0AA0 is a robust power supply module for electronic systems. This unit operates at 120 V AC or 230 V AC input for global installation flexibility. It delivers three different output voltages to cater to various application needs. Specifically, outputs include 5.1 V DC, 12 V DC, and -12 V DC. The 6AR1306-0HC00-0AA0 is specifically designed for compatibility with Siemens SICOMP systems. As a result, it ensures cohesive integration into existing electrical setups. The module measures 100 mm wide, 80 mm high, and 20 mm deep for compact installation.

Output Specifications

The Siemens 6AR1306-0HC00-0AA0 provides substantial output current capacity. The 5.1 V DC output delivers 12 Amps for powering digital logic circuits. The 12 V DC output provides 5 Amps for analog and interface circuits. The -12 V DC output supplies 0.5 Amps for operational amplifiers and dual-supply components. Total power rating reaches 3 kW (4 HP) for demanding applications. Therefore, this module offers sufficient energy for complex industrial systems. The triple output configuration eliminates the need for multiple separate power supplies.

Environmental & Physical Specifications

The Siemens 6AR1306-0HC00-0AA0 operates reliably in harsh industrial environments. Operating temperature range spans -20°C to +60°C for stable performance. Storage temperature extends from -40°C to +85°C for warehouse conditions. Humidity tolerance reaches up to 95% relative humidity (non-condensing) . Consequently, this module works well in humid manufacturing environments. The 6AR1306-0HC00-0AA0 uses a passive cooling system without fans. This design eliminates noise and reduces maintenance requirements. Weight is approximately 1.59 kg (3.51 lbs) for easy handling.

Key Features & Benefits

• Triple output voltages – The 6AR1306-0HC00-0AA0 provides 5.1V, 12V, and -12V DC outputs.

• High current capacity – Delivers 12A at 5.1V and 5A at 12V for demanding loads.

• Dual input compatibility – Accepts both 120V AC and 230V AC power sources.

• Passive cooling design – Operates without fans for silent, maintenance-free performance.

• Wide temperature range – Functions reliably from -20°C to +60°C ambient.

• International approvals – CE and UL/CSA certified for global installation compliance.

Installation Guidelines

Follow these steps to install the Siemens 6AR1306-0HC00-0AA0 correctly. First, ensure the input power source matches either 120V or 230V AC. Second, mount the module securely in a SICOMP system rack or enclosure. Third, connect the AC input wires to the designated input terminals. Fourth, verify proper grounding for electrical safety. Fifth, connect the 5.1V DC output to the logic circuit load. Finally, connect the +12V and -12V outputs to their respective loads.

Do not exceed the maximum output current ratings for any output. Provide adequate clearance around the 6AR1306-0HC00-0AA0 for passive cooling airflow. Use appropriately sized wiring for the 12A output current. The module requires no forced air cooling under normal operating conditions.

Package Contents

Your shipment includes the following items:

• 1 x Siemens 6AR1306-0HC00-0AA0 power supply module

• 1 x Installation manual with wiring diagrams

• 1 x Terminal connector kit for input and output wiring

• 1 x Grounding screw with washer

No input power cord is included with the 6AR1306-0HC00-0AA0. Therefore, you must provide appropriate AC wiring based on local electrical codes. Likewise, no mounting hardware is provided beyond the module itself.

Frequently Asked Questions (FAQ)

1. What systems is this power supply compatible with?
The Siemens 6AR1306-0HC00-0AA0 is designed for Siemens SICOMP systems. However, it can be used as a general purpose power supply for other applications.

2. Can I use only one output and leave others unconnected?
Yes. The 6AR1306-0HC00-0AA0 allows any combination of output loading. Unused outputs can remain unconnected without affecting performance.

3. Does this module require external cooling fans?
No. The Siemens 6AR1306-0HC00-0AA0 uses passive cooling. Therefore, no fans are needed for normal operation within the temperature range.

4. What is the maximum total power across all outputs?
The 6AR1306-0HC00-0AA0 has a total power rating of 3 kW. However, observe individual output current limits for proper operation.

5. Is this power supply certified for use in North America?
Yes. The Siemens 6AR1306-0HC00-0AA0 holds UL/CSA certifications. These approvals cover installation in North American industrial facilities.
