GE Fanuc IC695SPC100 PROFINET Scanner Module Overview

The GE Fanuc IC695SPC100 is a PROFINET scanner and transceiver module for RX3i PacSystems. This module provides special functions for data transfers between devices. It is an essential component for most RX3i racks and controllers. The IC695SPC100 features a copper base-T controller for short-range communication links. Specifically, this transceiver is designed as a pluggable part for base-TX devices. The module fits directly into RX3i PacSystems controllers that require PROFINET scanning capability. Therefore, the IC695SPC100 enables high-speed industrial networking for automation applications.

Communication Specifications

The GE Fanuc IC695SPC100 supports multiple communication speeds for network flexibility. Operating speeds include 10 Mbps, 100 Mbps, and 1000 Mbps (1 Gbps) . As a result, the module adapts to various network infrastructure capabilities. The copper material is generally used for short-range links with devices like this transceiver. Cable type must be twisted pair with a maximum length of 100 meters. This length cannot be modified since the part is designed for controller connections rather than long-distance links. Port connectors include two RJ-45 ports and two SFP cages. Consequently, the IC695SPC100 supports both copper and fiber optic physical layers.

Hardware Features

The GE Fanuc IC695SPC100 includes several hardware features for enhanced functionality. LED indicators provide visual status of network activity and module health. An SD card is supported for transferring information from one I/O module to another. Therefore, the IC695SPC100 facilitates easy data backup and restoration. A USB port is also included but is meant to be used only for firmware updates. Power requirements range from 3.3 to 5 Volts from the backplane. Configuration and programming use Proficy Machine Edition Software for system integration.

Environmental Specifications

The GE Fanuc IC695SPC100 operates within standard industrial temperature ranges. Operating temperature spans 0 to 60 degrees Celsius for reliable performance. If used with higher temperatures and exposed to frequent overheating, damage may occur. Therefore, ensure proper cooling and ventilation around the module. The IC695SPC100 is designed for installation inside control cabinets with adequate airflow.

Key Features & Benefits

• Triple speed support – The IC695SPC100 operates at 10, 100, or 1000 Mbps for network flexibility.

• Dual port types – Two RJ-45 ports and two SFP cages for copper or fiber connections.

• SD card support – Enables easy data transfer between I/O modules for backup and restore.

• USB firmware update – Dedicated USB port simplifies module upgrades.

• RX3i compatible – Designed specifically for GE Fanuc RX3i PacSystems controllers.

• LED status indicators – Provides clear visual confirmation of network and module health.

Installation Guidelines

Follow these steps to install the GE Fanuc IC695SPC100 correctly. First, power down the RX3i PacSystems rack completely. Second, select an available slot in the chassis for the module. Third, align the IC695SPC100 with the card guides in the rack. Fourth, push the module firmly into the backplane connector until fully seated. Fifth, secure the module with the retaining screws at top and bottom. Finally, connect twisted pair cables to the RJ-45 ports or SFP modules to the cages.

Do not exceed the 100 meter cable length for copper connections. Ensure ambient temperature stays within 0 to 60°C during operation. Use the USB port only for firmware updates, not for general communication. The IC695SPC100 requires Proficy Machine Edition Software for configuration.

Package Contents

Your shipment includes the following items:

• 1 x GE Fanuc IC695SPC100 PROFINET scanner module

• 1 x Installation manual with wiring diagrams

• 1 x SD card for data transfer (where applicable)

• 1 x Dust covers for unused SFP cages

No Ethernet cables or SFP transceivers are included with the IC695SPC100. Therefore, you must order these separately based on your network requirements.

Frequently Asked Questions (FAQ)

1. What is the maximum cable length for copper connections?
The GE Fanuc IC695SPC100 supports twisted pair cables up to 100 meters. Therefore, this module is designed for local rack-to-rack communication rather than long distances.

2. Can I use fiber optic cables with this module?
Yes. The IC695SPC100 includes two SFP cages. Consequently, you can install fiber optic SFP transceivers for longer distance connections.

3. What software is required to configure this module?
The IC695SPC100 requires Proficy Machine Edition Software. Use this software to configure PROFINET scanning parameters and I/O mapping.

4. Is the USB port for general communication?
No. The USB port on the IC695SPC100 is meant only for firmware updates. Therefore, do not use it for control or data transfer.

5. What happens if the module overheats?
If the IC695SPC100 is exposed to frequent overheating, damage may occur. Therefore, maintain ambient temperatures within 0 to 60°C and ensure proper ventilation.
