Product Overview

The GE Fanuc IC693BEM333 is a remote FIP interface module. This device offers a Series 90-30 PLC the option of sending and receiving information to and from a Factory Instrumentation Protocol (FIP) network. It comes from the factory with a data transmission speed of 1 MHz.

The module does not support hot-swap operations. Therefore, installation should be done with no electrical supply connected. Furthermore, this module is not compatible with RX3i systems.

General Specifications

The IC693BEM333 provides reliable FIP network connectivity for Series 90-30 PLCs.

• Brand: GE Fanuc.

• Series: Series 90-30.

• Part Number: IC693BEM333.

• Type of Component: Remote FIP Interface.

• Communication Protocol: Factory Instrumentation Protocol (FIP).

• IP Rating: IP20.

Communication Specifications

The IC693BEM333 uses standard FIP network characteristics.

• Number of Serial Ports: 2.

• Type of Serial Port: D-type, 9-pin connector.

• Transmission Speed: 1 MHz.

Thus, the module connects to FIP networks using standard 9-pin D-sub cabling.

Status Indicators

The IC693BEM333 provides clear operational status via LEDs.

• Number of Status LEDs: 4.

• LED Markings: CD1, TEN1, CD2, and TEN2.

Consequently, technicians can monitor network activity and connection status without external tools.

Physical and Environmental Considerations

The IC693BEM333 has an open construction design. Therefore, it is not suitable for the following conditions:

• Outdoor installation.

• High levels of humidity.

• High temperatures.

• Large quantities of dust or dirt.

For longer machine lifespan and reduced downtime, place the IC693BEM333 inside a panel with climate control. This protects the module from adverse environmental conditions.

Installation Guidelines

Install the IC693BEM333 in a Series 90-30 PLC backplane. Insert the module in any available slot except Slot 1. Slot 1 is reserved for CPU modules.

The power supply connection is on the back of the device. Always disconnect electrical power before installation. The module does not support hot-swap operations. Therefore, never insert or remove the module with power applied.

Connect FIP network cables to the two 9-pin D-type serial ports on the front of the module. Observe the 4 status LEDs (CD1, TEN1, CD2, TEN2) to verify proper operation.

System Compatibility

The IC693BEM333 is compatible with Series 90-30 PLCs. However, it is not supported in RX3i systems. Consequently, do not attempt to install this module in an RX3i rack.

Typical Applications

The IC693BEM333 suits various FIP network applications.

• Connecting Series 90-30 PLCs to FIP industrial control networks.

• Transmitting process information from analog and discrete field devices.

• Monitoring and controlling industrial processes and machinery via FIP bus.

• Integrating special field devices into a FIP network architecture.

What is in the Box

Please inspect all items upon delivery.

• GE Fanuc IC693BEM333 remote FIP interface module.

• Installation instruction manual.

• Anti-static protective bag.

Frequently Asked Questions (FAQ)

1. What is the transmission speed of the IC693BEM333?

The IC693BEM333 has a factory-set data transmission speed of 1 MHz. This is standard for FIP networks.

2. Does this module support hot-swap installation?

No. The IC693BEM333 does not support hot-swap operations. Therefore, always disconnect electrical power before installing or removing the module.

3. Is the IC693BEM333 compatible with RX3i systems?

No. The IC693BEM333 is not supported in RX3i systems. It is designed exclusively for Series 90-30 PLCs.

4. How many serial ports does this module have?

The IC693BEM333 has two serial ports. Both are D-type connectors with 9 pins each.

5. What do the LED indicators on this module show?

The IC693BEM333 has four status LEDs marked CD1, TEN1, CD2, and TEN2. These indicate carrier detect and transmission enable status for each of the two serial ports.
