Overview

The FANUC A06B-6150-H011 is a high-voltage three-phase power supply module. This unit belongs to the FANUC Alpha Power Supply family. It converts high-voltage AC power to regulated DC output. The A06B-6150-H011 provides reliable energy for CNC systems. Industrial automation applications depend on this module for stable DC bus voltage at higher voltage levels.

This power supply module supports heavy machining operations. The 13 kW output handles demanding servo loads. The unit suits large CNC machines and industrial automation systems.

Technical Specifications

The FANUC A06B-6150-H011 operates on three-phase AC input voltage. The input voltage range is 400 to 480 VAC. It accepts 50 or 60 Hz frequency standards. The input current reaches 24A at 400V.

Output Specifications

• Output Voltage: 565 to 679 VDC

• Rated Output Power: 13 kW

• Number of Phases: 3-Phase

Environmental Specifications

• Ambient Operating Temperature: 0°C to 55°C

• Ambient Storage Temperature: -20°C to 60°C

• Ambient Humidity: 90% RH or less (no condensation)

Physical Specifications

• Weight: 4.99 kg (11.00 lbs)

• Cooling Method: Air cooled (forced ventilation recommended)

Key Features

The A06B-6150-H011 delivers high-voltage DC power for large FANUC servo systems. The 13 kW output supports multiple servo axes. The 24A input current at 400V shows the module’s substantial capacity.

This FANUC power module accepts high-voltage global power standards at 400-480V AC. The output voltage of 565-679 VDC matches high-voltage Alpha series servo amplifier requirements. This higher voltage range enables more efficient power transmission over longer distances. Larger servo motors benefit from the increased DC bus voltage.

The module operates reliably in demanding industrial environments. The 0°C to 55°C operating range covers most factory floors. The -20°C to 60°C storage temperature allows safe warehousing in various climates. The 90% humidity tolerance ensures reliable performance in humid conditions without condensation.

Installation Guidelines

Install the FANUC A06B-6150-H011 in a well-ventilated cabinet. Maintain adequate clearance around the unit for air circulation. Use proper gauge wiring for 24A input current. Follow FANUC’s recommended cable sizes for high-voltage three-phase AC input.

Connect the 3-phase input power correctly to L1, L2, and L3 terminals. Secure the ground connection for safety and noise reduction. Install appropriate circuit protection upstream of the module. Verify the input voltage matches 400-480 VAC before power-up.

Keep the ambient temperature below 55°C during operation. Allow the unit to cool before performing maintenance. Check for dust accumulation on cooling surfaces regularly. Do not install the module in condensing humidity environments.

Package Contents

• FANUC A06B-6150-H011 Power Supply Module (1 unit)

• Mounting screws and hardware kit

• Terminal block covers

• Grounding terminal and wire

• Installation and wiring manual

Frequently Asked Questions (FAQ)

1. What CNC systems work with the FANUC A06B-6150-H011?
The A06B-6150-H011 works with FANUC CNC systems using high-voltage Alpha series servo amplifiers. It suits large machining centers, heavy-duty lathes, and high-power industrial equipment.

2. What is the output voltage range of this power supply module?
The FANUC A06B-6150-H011 produces 565 to 679 VDC output voltage. This high voltage range matches high-voltage Alpha series servo amplifier requirements for larger machines.

3. What is the power rating and input current of the A06B-6150-H011?
This module delivers 13 kW rated output power. At 400V input, it draws 24A of input current. This capacity supports multiple high-power servo axes.

4. What are the temperature limits for this FANUC power module?
The A06B-6150-H011 operates from 0°C to 55°C. Storage temperature ranges from -20°C to 60°C. This wide range suits various industrial and warehouse conditions.

5. Does the A06B-6150-H011 require three-phase input power?
Yes. The FANUC A06B-6150-H011 requires three-phase AC input voltage between 400 and 480 VAC. It does not operate on single-phase or lower voltage systems.
