Product Overview of Bently Nevada 9200-03-05-01-00

The Bently Nevada 9200-03-05-01-00 is a two-wire velocity seismoprobe transducer. This sensor measures absolute casing vibration on industrial rotating machinery. The 9200-03-05-01-00 delivers reliable data for machine protection systems. It works well on turbines, compressors, pumps, and fans in non-hazardous areas.

Key Technical Specifications

Sensitivity: 20 mV/mm/s (500 mV/in/s) with ±5% tolerance. This rating applies when properly terminated and oriented at the calibration angle.

Velocity Range: 25 mm/s (1 in/s) at +22°C casing vibration at 100 Hz with a 10 kΩ load.

Dynamic Operating Range: 2.54 mm (0.100 in) peak to peak maximum displacement.

Coil Resistance: 1.25 kΩ ±5%. Locked coil inductance measures 125 mH typical.

Calibration Load: 10 kΩ between Terminal A and Terminal B. Output measurement occurs across pins A and B.

Sensitivity Temperature Coefficient: 0.2% per degree Celsius for stable readings across temperature changes.

Operating and Storage Temperature: -29°C to +121°C (-20°F to +250°F) for the 9200 series.

Environmental Protection: Dust and moisture resistant construction. Relative humidity tolerance reaches 95% noncondensing.

Housing Material: Case uses anodized aluminum A204. Gasket material is neoprene for reliable sealing.

Dimensions and Weight: Height measures 102 mm (4 inches) typical. Diameter is 41 mm (1.6 inches) typical. Weight equals 300 grams (10.5 ounces).

Ordering Information Breakdown

The Bently Nevada 9200-03-05-01-00 includes these factory options:

• Transducer Mounting Angle/Minimum Operating Frequency Option 03: 90 ±2.5 degrees, 4.5 Hz (270 cpm).
• Connector Option 05: Terminal block top mount for easy wiring access.
• Mounting Base Option 01: Circular base with 1/4-20 UNC stud.
• Agency Approval Option 00: No approvals required for non-hazardous installations.

Installation Guidelines

Mount the 9200-03-05-01-00 directly on the machine casing surface. Use the 1/4-20 UNC stud on the circular base. Ensure the mounting surface is clean, flat, and free of paint. Orient the transducer at the 90 degree angle for proper calibration. Connect wires to the terminal block top mount connector. Use a 10 kΩ termination load between Terminal A and Terminal B. Secure the terminal block cover to prevent moisture ingress. Route signal wires away from high voltage cables. Verify proper grounding before connecting to the monitor. Do not exceed the maximum displacement of 2.54 mm peak to peak.

Package Contents (No certificates, No warranty clauses, No courier info)

• 1 x Bently Nevada 9200-03-05-01-00 velocity transducer
• 1 x terminal block top mount connector with cover
• 1 x circular mounting base with 1/4-20 UNC stud
• 1 x neoprene gasket for sealing
• 1 x installation instruction sheet

Frequently Asked Questions (FAQ)

1. What makes the 9200-03-05-01-00 different from the 9200-01-50-01-04?

The Bently Nevada 9200-03-05-01-00 has a 90° mounting angle and terminal block connector, while the other has 0° angle and 50-foot cable.

2. Can this transducer work in hazardous area locations?

No, this 9200-03-05-01-00 has agency approval option 00 with no certifications. Use it only in non-hazardous environments.

3. What termination load does this sensor require?

You need a 10 kΩ load between Terminal A and Terminal B for proper sensitivity calibration.

4. What is the minimum operating frequency of this model?

The Bently Nevada 9200-03-05-01-00 has a minimum operating frequency of 4.5 Hz (270 cpm) at the 90° mounting angle.

5. Can I replace the terminal block connector in the field?

Yes, the top mount terminal block allows easy field wiring and replacement without changing the entire transducer.

Application Scenarios

The Bently Nevada 9200-03-05-01-00 excels in predictive maintenance programs for non-hazardous facilities. Power plants use it on boiler feed pumps and cooling tower fans. Manufacturing facilities install these sensors on stamping presses and conveyor drives. The 90° mounting angle suits tight spaces where vertical mounting is impossible. The terminal block connector simplifies wiring in junction boxes. Paper mills monitor dryer sections and winder rolls. Water treatment plants use this transducer on aeration blowers and pump motors.

Environmental Robustness & Compliance

This 9200-03-05-01-00 transducer withstands dusty industrial environments. The anodized aluminum case resists corrosion from moisture and mild chemicals. Neoprene gaskets prevent dust and water ingress. Relative humidity up to 95% noncondensing does not affect operation. The sensitivity temperature coefficient of 0.2%/°C ensures stable readings across the full -29°C to +121°C range. The terminal block top mount option provides a sealed connection point for field wiring. This model carries no hazardous area approvals, making it suitable for general purpose use only.

Compatibility Information

The Bently Nevada 9200-03-05-01-00 works with most Bently Nevada monitoring systems. Use it with 1900/65A, 3500, and 2300 series monitors. The 20 mV/mm/s output matches standard velocity input cards. The 10 kΩ termination load requirement matches Bently Nevada barrier and monitor inputs. The terminal block output connects easily to field junction boxes. For legacy systems, verify the input impedance before connecting. This transducer also works with third party monitors that accept 20 mV/mm/s velocity inputs with 10 kΩ loading.

Advantages of Terminal Block Connector Option

The terminal block top mount on the 9200-03-05-01-00 offers several benefits. You can wire the sensor without special tools. Field replacement of cables becomes simple and fast. The sealed cover protects connections from dust and moisture. You can extend signal wires using standard instrumentation cable. This design reduces spare part inventory since cables are not integral to the sensor. Maintenance teams can test continuity without dismounting the transducer.

Conclusion

The Bently Nevada 9200-03-05-01-00 delivers accurate casing velocity measurements for non-hazardous machine monitoring. Its 90° mounting angle fits tight installations where space limits vertical access. The terminal block connector simplifies wiring and field maintenance. For reliable vibration monitoring on rotating machinery without hazardous area requirements, this transducer offers a cost-effective solution.
