Product Overview

The Siemens 6ES7136-6RA00-0BF0 is an F-RQ digital output module. It belongs to the SIMATIC ET 200SP product family. This module provides one fail-safe digital output channel. The Siemens 6ES7136-6RA00-0BF0 operates with both AC and DC loads. It handles voltages from 24V DC up to 230V AC. Users trust this safety module for critical output applications.

Technical Specifications

The 6ES7136-6RA00-0BF0 delivers reliable fail-safe digital output performance. Below are the complete technical details.

General Specifications

• Product Type Designation: F-RQ 1x24VDC/24...230VAC/5A.

• Part Number: 6ES7136-6RA00-0BF0 for precise identification.

• Series: SIMATIC ET 200SP distributed I/O system.

• Hardware Product Version: 01 for this release.

• Firmware Version: V1.0.0 pre-installed.

Product Functions

• I&M Data: Supports I&M0 to I&M3 identification data.

• Identification Function: Provides module identification and maintenance data.

• Safety Function: Fail-safe output for safety-related applications.

Engineering Compatibility

• STEP 7 TIA Portal Version: Configurable as of V13.

• STEP 7 Classic Version: Configurable as of V5.5 SP4 and higher.

• Integration: Works with Siemens engineering platforms.

Mounting Specifications

• Rail Mounting Possible: Yes on standard mounting rail.

• Mounting Type: ET 200SP base unit mounting.

• Installation: Plugs into a compatible base unit.

Supply Voltage Specifications

• Type of Supply Voltage: 24 VDC coil voltage.

• Rated Value (DC): 24 V nominal.

• Low Limit of Permitted Range (DC): 20.4 V minimum.

• High Limit of Permitted Range (DC): 28.8 V maximum.

• Voltage Range: Tolerates typical industrial power fluctuations.

Power Specifications

• Power Consumption from Backplane Bus: 100 mW.

• Power Loss (Typical): 1 W total dissipation.

• Efficiency: Low power design for ET 200SP systems.

Address Space

• Address Space per Module: Input 1 byte.

• Configuration: Simple addressing for safety integration.

Digital Output Specifications

• Number of Outputs: 1 fail-safe output channel.

• Voltage Induced on Current Interruption: Limited to no specification.

• Control of a Digital Input: Yes capability.

Switching Capacity of Outputs

• With Resistive Load (Maximum): 5 A.

• With Lamp Load (Maximum): 25 W.

• Load Types: Supports resistive and lamp loads.

• Voltage Range: Operates from 24V DC to 230V AC.

Installation Guide

Follow these steps to install the Siemens 6ES7136-6RA00-0BF0 correctly.

1. Power Down System: Turn off all power to the ET 200SP rack.

2. Select Base Unit: Choose a compatible ET 200SP base unit for this module.

3. Insert Module: Push the F-RQ module into the base unit until it locks.

4. Mount on Rail: Clip the base unit onto the standard mounting rail.

5. Connect Supply Voltage: Wire 24 V DC (20.4 to 28.8 V) to the base unit.

6. Wire Output: Connect the load to the output terminals (5A maximum).

7. AC/DC Consideration: Voltage can be 24V DC or up to 230V AC.

8. Connect Load Type: Ensure resistive or lamp load does not exceed ratings.

9. Apply Power: Turn on the system power to the ET 200SP station.

10. Configure in Software: Use STEP 7 TIA Portal V13 or higher.

11. Set I&M Data: Configure I&M0 to I&M3 identification data as needed.

12. Test Output: Verify the fail-safe output operates correctly.

Installation Notes

• The module provides one fail-safe digital output channel.

• Maximum resistive load is 5A for reliable switching.

• Lamp load maximum is 25W for this F-RQ module.

• Supply voltage range is 20.4 to 28.8 V DC.

• Power loss is typically 1W during operation.

Packaging List

This unit ships as a new and original product.

• Siemens 6ES7136-6RA00-0BF0 F-RQ Digital Output Module

• Product label with hardware version 01

• I&M data sheet

• Anti-static factory packaging bag

Frequently Asked Questions (FAQ)

1. What voltage loads can the 6ES7136-6RA00-0BF0 switch?
The Siemens 6ES7136-6RA00-0BF0 switches both 24V DC and 24 to 230V AC loads. This makes it very versatile for different applications.

2. What is the maximum current rating for this F-RQ output module?
The 6ES7136-6RA00-0BF0 handles a maximum of 5A with resistive loads. For lamp loads, the maximum is 25W.

3. What engineering software versions support this module?
The Siemens 6ES7136-6RA00-0BF0 configures with STEP 7 TIA Portal V13 or higher. It also works with STEP 7 Classic V5.5 SP4 and higher.

4. What is the power consumption from the backplane bus?
The 6ES7136-6RA00-0BF0 consumes only 100 mW from the backplane bus. Typical power loss is 1W during operation.

5. Does this module support I&M identification data?
Yes, the Siemens 6ES7136-6RA00-0BF0 supports I&M0 to I&M3 data. This provides module identification and maintenance information.
