Siemens 6ES7132-6BF01-0BA0 – SIMATIC ET 200SP Digital Output Module DQ 8x24V DC/0.5A

The Siemens 6ES7132-6BF01-0BA0 is a digital output module. Specifically, this module belongs to the SIMATIC ET 200SP family. It is designated as DQ 8x24V DC/0.5A Standard. Furthermore, it features source output (PNP, P-switching) configuration. Consequently, this module provides eight reliable digital outputs for industrial automation.

Ordering Configuration and Product Identification

• Product Type Designation: DQ 8x24VDC/0.5A ST.

• HW Functional Status: From FS02.

• Firmware Version: V0.0 (FW update not possible).

• Usable BaseUnits: BU type A0.

• Color Code: CC02 for module-specific identification plate.

• Packing Unit: 1 piece.

• Weight: Approximately 30 grams.

• Therefore, the Siemens 6ES7132-6BF01-0BA0 is lightweight and compact.

Engineering Compatibility

• STEP 7 TIA Portal: Configurable from version V14.

• STEP 7: Configurable from version V5.5 SP3 or higher.

• PCS 7: Configurable from version V8.1 SP1.

• PROFIBUS GSD: One GSD file each, Revision 3 and 5 and higher.

• PROFINET GSD: GSDML V2.3.

• I&M Data: Yes, I&M0 to I&M3 supported.

• Isochronous Mode: Not supported.

• Thus, the 6ES7132-6BF01-0BA0 integrates with major Siemens engineering platforms.

Supply Voltage and Power Specifications

• Rated Supply Voltage (DC): 24 V.

• Permissible Range Lower Limit: 19.2 V DC.

• Permissible Range Upper Limit: 28.8 V DC.

• Reverse Polarity Protection: Yes.

• Current Consumption (max): 35 mA (without load output voltage/header).

• Power Loss (typical): 1 W.

• Rated Output Voltage (DC): 24 V.

• Consequently, the Siemens 6ES7132-6BF01-0BA0 operates efficiently with standard 24V DC supplies.

Digital Output Specifications

• Type of Digital Output: Source output (PNP, current-sourcing).

• Number of Digital Outputs: 8 channels.

• Parameterizable: Yes.

• Short-Circuit Protection: Yes with typical response threshold of 1 A.

• Limitation of Inductive Shutdown Voltage: Typical L+ (-50 V).

• Controlling a Digital Input: Yes.

• Resistive Load Switching Capacity (max): 0.5 A.

• Lamp Load Switching Capacity (max): 5 W.

• Load Resistance Lower Limit: 48 Ω.

• Load Resistance Upper Limit: 12 kΩ.

• Output Voltage for Signal "1" (min): L+ (-0.8 V).

• Output Current for Signal "1" Rated Value: 0.5 A.

• Output Current for Signal "1" Permissible Range (max): 0.5 A.

• Output Current for Signal "0" Residual Current (max): 0.1 mA.

• Therefore, the Siemens 6ES7132-6BF01-0BA0 delivers consistent output performance.

Output Delay and Switching Frequency

• Output Delay "0" to "1" (max): 50 µs at rated load.

• Output Delay "1" to "0" (max): 100 µs at rated load.

• Parallel Switching for Uprating: Not allowed.

• Parallel Switching for Redundant Load Control: Yes.

• Switching Frequency (Resistive Load, max): 100 Hz.

• Switching Frequency (Inductive Load, max): 2 Hz.

• Switching Frequency (Lamp Load, max): 10 Hz.

• Current per Channel (max): 0.5 A.

• Current per Module (max): 4 A.

• Horizontal Installation (up to 60°C, max): 4 A.

• Vertical Installation (up to 50°C, max): 4 A.

• Thus, the 6ES7132-6BF01-0BA0 handles moderate switching frequencies reliably.

Cable Length Specifications

• Shielded Cable (max): 1,000 meters.

• Unshielded Cable (max): 600 meters.

• Consequently, flexible cabling options suit various installation distances.

Diagnostics and Interrupts

• Diagnostics Function: Yes.

• Substitute Values Connectable: Yes.

• Diagnostic Alarm: Yes.

• Monitoring of Supply Voltage: Yes.

• Wire-Break Detection: Yes (module-wise).

• Short-Circuit to M: Yes (module-wise).

• Short-Circuit to L+: Yes (module-wise).

• Group Error: Yes.

• Diagnostics LED Indicators:

  • PWR-LED: Green for supply voltage monitoring.

  • Channel Status Display: Green LED per channel.

  • DIAG LED: Green/red for module diagnostics.

• Channel Diagnostics LED: No.

• Therefore, the Siemens 6ES7132-6BF01-0BA0 provides comprehensive diagnostic feedback.

Potential Separation and Isolation

• Between Channels: No.

• Between Channels and Backplane Bus: Yes.

• Between Channels and Electronics Power Supply: No.

• Isolation Tested With: 707 V DC (type test).

• Thus, proper isolation protects the backplane bus from output-side faults.

Safety and Approvals

• Suitable for Safety Functions: No.

• Suitable for Safety-Related Tripping of Standard Modules: Yes (see FAQ Entry ID: 39198632).

• Highest Safety Class in Safety Mode:

  • Performance Level according to ISO 13849-1: PL d.

  • SIL according to IEC 61508: SIL 2.

• Consequently, this module supports safety-related applications with external evaluation.

Ambient Conditions and Dimensions

• Horizontal Installation Temperature (min): -30°C (from FS02, below 0°C).

• Horizontal Installation Temperature (max): 60°C.

• Vertical Installation Temperature (min): -30°C (from FS02, below 0°C).

• Vertical Installation Temperature (max): 50°C.

• Maximum Installation Altitude: 5,000 meters above sea level (restrictions above 2,000m - see manual).

• Dimensions (Width): 15 mm.

• Dimensions (Height): 73 mm.

• Dimensions (Depth): 58 mm.

• Moreover, the Siemens 6ES7132-6BF01-0BA0 fits compact ET 200SP stations.

Hardware Configuration and BaseUnit Compatibility

• Automatic Encoding: Yes.

• Mechanical Coding Element: Yes.

• Type of Mechanical Coding Element: Type A.

• 1-Wire Connection: BU type A0.

• 2-Wire Connection: BU type A0.

• 3-Wire Connection: BU type A0 with AUX terminals or potential distributor module.

• 4-Wire Connection: BU type A0 + potential distributor module.

• Address Space per Module (max): 1 byte + 1 byte for QI information.

• Therefore, the 6ES7132-6BF01-0BA0 supports multiple wiring configurations.

Installation Guide

First, ensure the system power is completely disconnected. Then, verify that you have a BaseUnit of type BU A0. After that, insert the Siemens 6ES7132-6BF01-0BA0 into the BU type A0 slot. The automatic encoding feature ensures correct positioning. Next, engage the mechanical coding element (Type A) to secure the module. Then, connect the 24V DC supply voltage (19.2V to 28.8V range). Observe reverse polarity protection features. Subsequently, connect your loads to the eight digital output channels. Use shielded cable for runs up to 1,000 meters. Alternatively, use unshielded cable for runs up to 600 meters. Then, configure the module using STEP 7 TIA Portal V14 or higher. Set substitute values if needed for fail-safe behavior. Finally, power on the system and monitor the green PWR LED and DIAG LED. As a result, the Siemens 6ES7132-6BF01-0BA0 will provide reliable digital output control.

Packaging List

• One Siemens 6ES7132-6BF01-0BA0 digital output module

• One mechanical coding element (Type A, pre-installed)

• One color identification plate (CC02)

• One product information sheet

• One manual reference card

Common FAQs

Q1: What type of outputs does the Siemens 6ES7132-6BF01-0BA0 provide?
A: This module provides source outputs (PNP, current-sourcing). Specifically, it delivers 0.5A per channel at 24V DC. Therefore, it switches positive voltage to the load.

Q2: What BaseUnit is compatible with the 6ES7132-6BF01-0BA0?
A: This module requires BU type A0 BaseUnits. Specifically, it supports 1-wire, 2-wire, 3-wire, and 4-wire connections with appropriate accessories. Always verify your BaseUnit type before installation.

Q3: What diagnostic features does this digital output module include?
A: The Siemens 6ES7132-6BF01-0BA0 includes comprehensive diagnostics. Specifically, it monitors supply voltage, wire-break, short-circuit to M, and short-circuit to L+. Diagnostic alarms are also supported.

Q4: Can I use this module for safety-related applications?
A: Yes, but not as a standalone safety module. Specifically, it is suitable for safety-related tripping of standard modules. It achieves PL d (ISO 13849-1) and SIL 2 (IEC 61508) when used correctly.

Q5: What is the maximum cable length for the 6ES7132-6BF01-0BA0?
A: Shielded cable can run up to 1,000 meters maximum. Unshielded cable can run up to 600 meters maximum. Therefore, choose cable type based on your installation distance.
