Product Overview

The Flexem SD16 is an analog output module designed for industrial automation systems. It provides precise signal conversion and control capabilities. This module is ideal for applications requiring stable and accurate analog output signals.

The SD16 module supports multiple output channels. Each channel can be configured for voltage or current outputs. This flexibility makes it suitable for a wide range of industrial control tasks.

This module is a new original product. It comes in stock and ready for immediate shipment. The SD16 is built to meet rigorous industrial standards for reliability and performance.

Application Scenarios

The Flexem SD16 is commonly used in process control systems. It interfaces with actuators such as valves and drives. The module ensures smooth and accurate control of these devices.

It is also applied in manufacturing automation. The SD16 provides signals to variable frequency drives and other control elements. This enables precise speed and position control.

Another common use is in building automation. The module controls heating, ventilation, and air conditioning (HVAC) systems. It delivers consistent analog signals for temperature and flow regulation.

Technical Specifications

• Output type: Analog voltage and current
• Number of channels: 4
• Signal range: 0-10V or 4-20mA
• Resolution: 16-bit
• Isolation: 1500V AC between channels and system
• Power supply: 24V DC
• Operating temperature: -20°C to +60°C
• Dimensions: 120mm x 80mm x 40mm
• Weight: 0.3 kg

Installation & Maintenance Guide

Install the SD16 on a standard DIN rail. Ensure proper ventilation around the module. Connect the power supply to the designated terminals.

Wire the analog output signals to the corresponding load devices. Use twisted shielded cables for best noise immunity. Verify the wiring before powering the system.

Configure the output type and range using the configuration software. Test each channel with a known load. Monitor the output signals for accuracy.

Regularly inspect the module for dust or debris. Clean with a soft dry cloth if necessary. Check all connections periodically for tightness.

Frequently Asked Questions (FAQ)

What is the primary function of SD16?

The Flexem SD16 is an analog output module that converts digital control signals into precise analog voltage or current outputs.

What types of loads can SD16 drive?

The module can drive actuators, valves, variable frequency drives, and other devices requiring 0-10V or 4-20mA control signals.

Does SD16 require external power?

Yes, the module requires a 24V DC power supply for operation.

What is the maximum cable length for SD16 analog outputs?

For reliable signal integrity, use shielded cables up to 100 meters for voltage outputs and up to 500 meters for current outputs.

Is SD16 compatible with Flexem PLC systems?

Yes, the SD16 is designed for seamless integration with Flexem programmable logic controllers and automation platforms.
