1762-L24AWAR | Allen-Bradley MicroLogix 1200 PLC
Introduction:
Allen-Bradley MicroLogix 1200 PLC, 24 I/O, 1 analog output, 120/240 VAC, RS-232, new original in stock.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The 1762-L24AWAR is a programmable logic controller from Allen-Bradley. It belongs to the MicroLogix 1200 series. This controller provides a compact solution for small to medium automation tasks. It integrates a power supply, CPU, and I/O in one unit. The module supports 24 digital I/O points. It includes an embedded analog output channel. The controller uses the RS-232 communication port for programming. It is designed for reliable operation in industrial environments. The unit is new and in stock for immediate shipment.
Application Scenarios
This controller suits packaging machines. It controls conveyor systems effectively. The module manages simple process control tasks. It works in material handling applications. The controller is ideal for standalone machines. It operates in small assembly lines. The device supports remote monitoring via serial link. It can replace older relay logic systems. The unit fits in control cabinets with limited space. It is used in water treatment plants. The controller handles lighting control systems. It automates HVAC equipment in buildings.
Technical Specifications
- Manufacturer: Allen-Bradley
- Series: MicroLogix 1200
- Product Number: 1762-L24AWAR
- Input Voltage: 120/240 VAC
- Digital I/O: 24 points total
- Analog Output: 1 channel
- Communication: RS-232
- Memory: 4K words program
- Scan Time: 8 ms typical
- Operating Temperature: 0 to 55 °C
- Mounting: Panel or DIN rail
- Weight: 0.5 kg
Installation & Maintenance Guide
Mount the controller on a flat panel. Use DIN rail for quick installation. Ensure proper grounding before wiring. Connect AC power to L1 and L2 terminals. Wire input devices to input terminals. Connect output loads to output terminals. Use shielded cable for analog output. Set the node address via DIP switches. Download the program using RS-232 cable. Keep the enclosure clean and dry. Check terminal screws for tightness monthly. Replace the unit if the status LED shows fault.
