Is Your Control Panel Power Supply Ready for the Unexpected?

Voltage sags, temperature swings, and continuous duty cycles test every component in an industrial control panel. The Allen-Bradley 1606-XLE240F answers that challenge as a DIN rail mounted power supply in the Bulletin 1606-XL series. It delivers a nominal 48 V DC output at 240 W and accepts a wide-range auto-select input of AC 100...300 V or 200...240 V nominal.

This module is part of the 1606-XLE essential series. It provides a dependable DC source for control relays, sensors, and interface devices in oil and gas facilities. Because it carries UL 60950-1, cUL, and CE markings, it fits into panels that require recognized components.

Key Features and Technical Specifications

• Input voltage: AC 100...300 V / 200...240 V auto-select nominal.
• Output voltage: DC 48 V nominal with adjustment from 48...56 V.
• Output current: 5 A nominal, with a range of 5...4.6 A.
• Rated power: 240 W.
• Efficiency: 91.6% typical.
• Ripple and noise: 50 mV maximum (mVpp).
• Operating temperature: -25...+70 °C.
• Protection rating: IP20 for DIN rail or enclosure mounting.
• Dimensions (H×W×D): 124 × 60 × 117 mm.
• Weight: 700 g.

The wide-range input is a standout feature for field installations. It allows the supply to operate across different AC distribution levels without manual reconfiguration. In addition, the 20% power reserve supports short-term load peaks that occur when multiple contactors energize at once.

Applications in Oil and Gas Operations

Power supplies in this sector must tolerate harsh conditions and continuous operation. The 1606-XLE240F suits several mission-critical roles. For example, it can supply 48 V DC to remote terminal units and flow computer cabinets. It also powers solenoid banks and signal conditioning modules on well pads. Because the unit operates from -25...+70 °C, it handles temperature extremes found in both upstream and midstream sites. Furthermore, the IP20 rating is appropriate for installation inside a protected enclosure, where dust and moisture are controlled.

Installation and Setup Guidance

Mount This unit on a standard DIN rail inside an enclosure. Use the screw terminals for input and output wiring, and verify that the auto-select input matches your available AC supply. The adjustable output lets you fine-tune voltage between 48...56 V to compensate for cable drops. A DC OK relay contact provides a status signal to your control system. Before energizing, confirm that the load does not exceed the 5 A nominal rating. Also, allow clearance for convection cooling around the 124 × 60 × 117 mm housing.

Reliability and Maintenance Practices

Field-proven reliability starts with correct installation and periodic inspection. Check terminal tightness and remove dust from the enclosure vents during scheduled maintenance. Because the unit has no internal communication interface, diagnostics rely on the DC OK contact and output measurements. In addition, monitor the operating temperature to ensure it stays within the -25...+70 °C range. The 91.6% typical efficiency reduces heat buildup inside the cabinet, which supports long service life. For mission-critical panels, keep a spare unit on hand to minimize downtime.

Compatibility and Integration Notes

This unit integrates into 48 V DC control circuits through its screw terminals. It has no built-in communication ports and does not use any fieldbus protocol. Therefore, it works as a standalone power source rather than a networked device. When replacing an existing supply, verify that the form factor and terminal layout match your panel. The DIN rail mount simplifies swap-out procedures. If your system requires remote monitoring, use the DC OK relay contact with your PLC or alarm module.

Frequently Asked Questions

What input voltage does This unit accept?

The Allen-Bradley unit accepts AC 100...300 V or 200...240 V nominal with auto-select. This wide range covers common industrial distribution voltages without manual switching.

Can the output voltage be adjusted?

Yes. The nominal DC 48 V output is adjustable from 48...56 V. This allows compensation for voltage drop across long cable runs.

What is the operating temperature range?

The unit operates from -25...+70 °C. Ensure the enclosure maintains this range for dependable performance.

Does this power supply have communication capabilities?

No. This unit has no built-in ports and does not support any communication protocol. It provides a DC OK relay contact for status signaling.

Is This unit suitable for PLC power supply module replacement?

Yes, it can serve as a PLC power supply module replacement when a 48 V DC, 240 W source is required. Verify the form factor and load requirements before installation.

For parts suited to your application's requirements, contact PetroPartsOnline. The Allen-Bradley unit is active and available. Please verify current lifecycle status and availability with PetroPartsOnline before ordering.
