What Is the SICK KUP-1010-S Bar Coupling?

The SICK KUP-1010-S is a bar (beam) shaft coupling designed for encoder-to-drive connections. It features 10 mm bores on both the encoder side (D1) and drive side (D2), enabling direct shaft adaptation in motion feedback systems. With a maximum torque capacity of 0.8 N·m and a maximum speed of 10,000 rpm, this coupling supports dependable encoder mounting in demanding industrial environments.

Engineered for reliability in oil and gas operations, This unit combines a glass-fiber-reinforced polyamide body with an aluminum hub. This construction helps absorb misalignment while maintaining torsional rigidity. The coupling compensates for axial offsets up to ±0.2 mm, radial offsets up to ±0.3 mm, and angular offsets up to ±3°, reducing stress on encoder bearings and shafts.

Key Features and Technical Specifications

• Bore diameter (encoder side, D1): 10 mm
• Bore diameter (drive side, D2): 10 mm
• Coupling type: Bar coupling
• Material: Glass-fiber-reinforced polyamide, aluminum hub
• Nominal torque: 0.8 N·m maximum (80 Ncm per datasheet)
• Max. speed: 10,000 rpm maximum
• Axial offset compensation: max. ±0.2 mm
• Radial offset compensation: max. ±0.3 mm
• Angular offset compensation: max. ±3°
• Operating temperature: –10 °C to +80 °C
• Dimensions: 24 mm overall length

The 10,000 rpm speed rating makes this coupling suitable for high-speed encoder feedback loops. Its torque capacity of 0.8 N·m provides a safety margin for typical encoder loads without overstressing the shaft. The operating temperature range of –10 °C to +80 °C supports reliable performance in both cold and hot process areas.

Applications and Use Cases in Oil & Gas

In oil and gas facilities, encoders often operate in harsh conditions where vibration and misalignment are common. This unit bar coupling addresses these challenges by accommodating shaft offsets while transmitting motion accurately. Typical applications include mounting encoders on motor shafts, gearbox outputs, and valve actuators.

For example, on a pipeline valve actuator, the coupling compensates for small radial and angular misalignments between the encoder and drive shaft. This reduces wear on the encoder bearings and extends service life. Similarly, in pump monitoring systems, the coupling’s glass-fiber-reinforced polyamide body resists corrosion and chemicals often present in upstream and midstream environments.

When specifying a vfd replacement or upgrading a drive system, This unit provides a reliable mechanical interface for encoder feedback. Its 10 mm bores match common shaft diameters, simplifying installation and reducing downtime.

Installation and Setup Guidelines

Proper installation ensures optimal performance and longevity. First, verify that both the encoder shaft and drive shaft are 10 mm in diameter. Next, slide the coupling onto the shafts, ensuring the clamping screws (not included) are accessible. Align the shafts as closely as possible before tightening. The coupling’s offset compensation handles residual misalignment within the specified limits.

Because the coupling is a bar type, it requires careful handling to avoid bending the bars during installation. Do not force the coupling onto the shafts. Instead, use a suitable tool to expand the bore if necessary. After installation, rotate the assembly by hand to check for binding or excessive play. Finally, secure the clamping screws according to the manufacturer’s torque recommendations.

Maintenance and Reliability

This unit is designed for maintenance-free operation under normal conditions. However, periodic inspection is recommended to ensure reliable performance. Check for signs of wear, such as cracks in the polyamide body or loosening of the aluminum hub. Inspect the coupling for debris buildup that could restrict movement.

In high-vibration applications, verify the clamping screws remain tight. Because the coupling compensates for misalignment, it reduces stress on the encoder bearings, which can extend the encoder’s service life. The operating temperature range of –10 °C to +80 °C means the coupling can handle typical oil and gas environments without degradation. For mission-critical operations, keep a spare coupling on hand to minimize downtime.

Compatibility and Integration

The SICK unit is a shaft adaptation accessory for encoders with 10 mm shafts. It is compatible with a wide range of SICK encoder models that use a 10 mm shaft. The bar coupling design allows for angular, radial, and axial misalignment, making it versatile for various mounting configurations.

When integrating with a VFD or servo system, ensure the encoder’s output signals are compatible with the drive’s feedback input. The coupling itself is a mechanical component and does not affect electrical signals. For servo motor replacement projects, This unit can serve as a drop-in coupling if the shaft diameters match. Always consult the encoder datasheet for shaft dimensions and torque requirements.

Frequently Asked Questions

What is the maximum speed of the SICK unit?

The SICK unit has a maximum speed of 10,000 rpm. This makes it suitable for high-speed encoder applications in oil and gas equipment.

Can This unit handle misalignment?

Yes, the coupling compensates for axial offsets up to ±0.2 mm, radial offsets up to ±0.3 mm, and angular offsets up to ±3°. This helps protect encoder bearings from stress.

What is the operating temperature range of this coupling?

This unit operates within a temperature range of –10 °C to +80 °C. This covers most industrial environments, including oil and gas facilities.

Is This unit suitable for vfd replacement projects?

Yes, This unit provides a reliable mechanical interface for encoder feedback in VFD systems. Its 10 mm bores fit common shaft sizes, simplifying replacement.

What material is the coupling made of?

The coupling features a glass-fiber-reinforced polyamide body with an aluminum hub. This combination offers strength and corrosion resistance.

Product Support and Availability

PetroPartsOnline supplies the SICK unit and other vfd parts for industrial automation. Our team can help you confirm compatibility with your encoder and drive system. Contact PetroPartsOnline for parts suited to your application's requirements.
