Technical Specifications of GE Fanuc IC755ACC10GAS

Physical & Environmental Data

The GE Fanuc IC755ACC10GAS weighs 1.36 kg (3.00 lbs). This gasket works with 10-inch Quickpanel+ terminals only. The operating temperature range is 0°C to +50°C. Humidity tolerance reaches 85% RH (non-condensing) at 30°C. The cooling method uses natural convection.

Mounting Specifications

The gasket includes mounting brackets for secure installation. Mounting clamps require a torque of 0.3 Nm. Panel thickness compatibility ranges from 1.6 mm to 5 mm. You need a Phillips head screwdriver for installation. Tighten screws in a clockwise direction for proper seating.

Compatibility & Application

The GE Fanuc IC755ACC10GAS replaces degraded original gaskets on 10-inch Quickpanel+ terminals. The original gasket comes preinstalled from the factory. Certain environmental conditions cause gasket degradation over time. This replacement ensures continued protection for your operator interface terminal.

Material & Construction

This gasket covers the module of the Quickpanel+ terminal. It also covers the screen and each port on the interface. The gasket must seat properly in the bezel channel on the unit sides. You need to cut space from the gasket based on your terminal dimensions.

Installation Guide for IC755ACC10GAS Gasket

Follow these steps to install the GE Fanuc IC755ACC10GAS replacement gasket correctly.

• Remove All Connections: Disconnect all cables from the terminal before starting. Nothing should attach to the unit during gasket installation.

• Seat the Gasket: Place the gasket properly into the bezel channel located on the sides of the unit.

• Cut Space as Needed: Trim space from the gasket according to your terminal dimensions. Match the cutout to your specific unit size.

• Secure with Screws: Use a Phillips head screwdriver to tighten screws clockwise. Apply torque of 0.3 Nm for mounting clamps.

• Verify Panel Thickness: Ensure your panel thickness falls between 1.6 mm and 5 mm. This range ensures proper fit.

• Perform Periodic Inspections: Check mounting screws occasionally and retighten as needed. Avoid frequent insertions and removals to prevent wear.

• Maintain Environment: Keep temperature within 0°C to 50°C. Keep humidity below 85% RH to prevent heat and water damage.

Packaging List

The original package for GE Fanuc IC755ACC10GAS includes:

• 1 x Replacement gasket for 10-inch Quickpanel+ terminals

• 1 x Mounting brackets set

• 1 x Mounting clamps (0.3 Nm torque rating)

• 1 x Installation instructions (basic guide)

Frequently Asked Questions (FAQ)

Q1: Which terminals work with the GE Fanuc IC755ACC10GAS?
A1: This replacement gasket works exclusively with 10-inch Quickpanel+ terminals. It does not fit 7-inch or other screen sizes.

Q2: What tools do I need to install the IC755ACC10GAS gasket?
A2: You need a Phillips head screwdriver for installation. Tighten screws clockwise to 0.3 Nm torque.

Q3: What is the panel thickness range for this gasket?
A3: The panel thickness must be between 1.6 mm and 5 mm. This range ensures proper seating and sealing.

Q4: How do I maintain the GE Fanuc IC755ACC10GAS after installation?
A4: Perform periodic inspections of mounting screws. Tighten them occasionally as needed. Avoid frequent panel insertions and removals.

Q5: What environmental limits apply to the IC755ACC10GAS?
A5: Operating temperature range is 0°C to +50°C. Humidity limit is 85% RH (non-condensing) at 30°C. Natural convection provides cooling.
