Product Overview

The SE3008 is a DeltaV SQ Controller from Emerson. This controller provides communication and control functions for your process system. Furthermore, it integrates field devices and other nodes on the control network. The SE3008 offers a smaller controller platform at a reduced price for small to moderate applications. Consequently, you can match controller capacity to your specific process requirements. The SQ Controller complements the SX Controller perfectly within the DeltaV family.

Technical Specifications

Manufacturer: Emerson
Product type: DeltaV SQ Controller
Part Number: SE3008
DST limit: 750
SCADA tags: 3200
User memory: 48 MB
Power dissipation: 5.0 W typical, 7.0 W maximum
Fuse protection (internal): 3.0 A, non-replaceable fuses

Communication and Data Rates

Max data values sent: 2000 per second
Max data values received: 250 per second
Max unsolicited client nodes: 64
Module execution rates: 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 30s, 60s

The SE3008 supports all the advanced control features expected in a world class DCS. Specifically, these include Batch Software, Model Predictive Control, and Neural Networks. Control strategies are developed using IEC-61131 programming techniques. These techniques include Function Blocks, Sequential Function Charts, and Structured Text. As a result, the SE3008 delivers powerful and flexible control for complex processes.

Environmental Specifications

Operating temperature: -40° to 70°C (-40° to 158°F)
Storage temperature: -40° to 85°C (-40° to 185°F)
Relative humidity: 5 to 95%, non-condensing
Protection rating: IP 20
Airborne contaminants: ISA-S71.04-1985 Class G3 with conformal coating
Shock (normal operating conditions): 10 g ½-sine wave for 11 ms

Vibration (operative limit):
- 1 mm peak-to-peak from 5 Hz to 13.2 Hz
- 0.7 g from 13.2 Hz to 150 Hz

LED Status Indicators

The SE3008 includes several LED indicators for quick diagnostics:

Green – Power: Indicates DC power is applied
Red – Error: Indicates an error condition
Green – Active: Indicates the controller is operating as the primary controller
Green – Standby: Indicates the controller is operating as a backup controller
Yellow flashing – Pri. CN: Indicates valid primary control network communication
Yellow flashing – Sec. CN: Indicates valid secondary control network communication

External Connections and Redundancy

Primary control network: 8-pin RJ-45 connector
Secondary control network: 8-pin RJ-45 connector

The SE3008 supports 1:1 redundancy for increased system availability. Redundant SQ Controllers can be upgraded to SX Controllers online without shutdown. Hardware redundancy is automatically detected with zero configuration effort. Furthermore, the SE3008 provides automatic diagnostic and event reporting with time stamps applied directly in the controller.

Electronic Marshalling and I/O Capabilities

The SE3008 is designed for Electronic Marshalling with CHARM based I/O. Electronic Marshalling I/O can be mounted anywhere in your facility. Consequently, this facilitates system design and expansion while reducing overall system footprint. Traditional marshalled I/O subsystems require more space and wiring. The SE3008 delivers highly distributable I/O capabilities for modern control architectures.

Key Benefits and Features

Scalable Controllers: The SE3008 complements the SX Controller perfectly.
Quick Assembly: Carriers snap to standard DIN rails without retaining screws.
Easy to Use: Simply connect the SE3008 to the DeltaV network and use Auto-Sense.
Field Proven Architecture: The SE3008 evolved from the DeltaV MQ Controller.
Late Changes: You can easily upgrade an SQ Controller to an SX controller.
Online Expandable: New I/O cards can be added online with autosense capability.

Certifications and Hazardous Area Approvals

The SE3008 holds multiple certifications for global deployment:

CE: EMC- EN 61326-1
FM (USA): Class I, Division 2, Groups A, B, C, D, T4
cFM (Canada): Class I, Division 2, Groups A, B, C, D, T4
ATEX: II 3G Ex ec IIC T4 Gc
IEC Ex: II 3G Ex ec IIC T4 Gc
Marine certifications: IACS E10, ABS Certificate of Design Assessment, DNV Type Approval Certificate
Wurldtech: Achilles Communications Certification Level 2

Installation Guidelines

1. First, mount the S-series carrier on a standard DIN rail.
2. Then, snap the SE3008 controller into position without retaining screws.
3. Next, connect the primary control network using an 8-pin RJ-45 cable.
4. For redundancy, also connect the secondary control network.
5. After that, apply 24 VDC power to the SE3008.
6. Verify the green Power LED illuminates immediately.
7. Then, connect the SE3008 to the DeltaV network.
8. Use DeltaV Explorer to Auto-Sense the controller automatically.
9. Subsequently, add the controller and all I/O interfaces to the system database.
10. All components are automatically addressed with no dip switches or jumpers.
11. Finally, develop control strategies using IEC-61131 programming techniques.

Packaging List

- 1 x SE3008 DeltaV SQ Controller unit
- 1 x S-series carrier mounting base
- 1 x Quick start installation guide
- 1 x Anti-static protective bag for storage

Common FAQ

1. Can I upgrade an SE3008 to an SX Controller later?
Yes, you can easily upgrade the SE3008 to an SX Controller. Simply replace the SQ with the SX, and all existing configuration remains the same.

2. Does the SE3008 support Electronic Marshalling?
Yes, the SE3008 is designed for Electronic Marshalling with CHARMs. This provides highly distributable I/O capabilities for flexible system design.

3. What programming languages work with the SE3008?
The SE3008 supports IEC-61131 programming techniques. These include Function Blocks, Sequential Function Charts, and Structured Text.

4. Is the SE3008 approved for hazardous locations?
Yes, the SE3008 is certified for Class I, Division 2, Groups A, B, C, D, T4 (FM/cFM). It also holds ATEX and IEC Ex Zone 2 approvals.

5. How much user memory does the SE3008 provide?
The SE3008 provides 48 MB of user memory. Therefore, it can handle complex control strategies and large system configurations.
