What the 1606-XLP50B Power Supply Delivers in Harsh Conditions

The Allen-Bradley 1606-XLP50B is a Bulletin 1606-XL compact power supply that converts AC 100...240 V or DC 110...300 V input to a regulated DC 24 V output at 50 W. Its 89.0% typical efficiency and -10...+70 °C operating range make it suited to mission-critical control cabinets in oil and gas facilities.

Field engineers often face power modules that drift under load or fail when ambient temperatures climb. This unit addresses those pain points through an adjustable output range of 24...28 V, a low ripple and noise figure of 50 mV maximum, and a DC OK relay contact for status monitoring. This unit is built for demanding environments where dependable power is not optional.

Key Features and Technical Specifications of This unit

• Input voltage: AC 100...240 V nominal; DC 110...300 V, covering common industrial supply ranges.
• Output voltage: DC 24 V nominal, adjustable from 24...28 V for application-specific tuning.
• Output current: 2.1 A nominal, with a range of 2.1...1.8 A.
• Rated power: 50 W continuous output.
• Efficiency: 89.0% typical, reducing heat inside enclosures.
• Ripple and noise: 50 mV maximum (mVpp) for sensitive loads.
• Operating temperature: -10...+70 °C, suitable for outdoor and unheated cabinets.
• Protection rating: IP20 for DIN rail or enclosure mounting.
• Dimensions (H×W×D): 75 × 45 × 91 mm; weight 240 g.
• Approvals: UL 60950-1 / cUL / CE marked per Bulletin 1606 series standard.

The DC OK relay contact is a distinctive feature. It provides a dry contact signal that can be wired to a PLC input, giving operators immediate indication of output status. In a remote wellhead panel, this contact helps avoid unexpected downtime by flagging power loss before it affects the process.

Installation and Setup for Reliable Operation

Mounting This unit is straightforward on a standard DIN rail. Spring terminals accept solid or stranded wire, reducing termination time and improving vibration resistance. Because the input accepts both AC and DC voltages, the same unit can be used across different supply architectures without reconfiguration.

Adjust the output voltage using the front-accessible potentiometer to match load requirements between 24 V and 28 V. For loads sensitive to noise, the 50 mV maximum ripple ensures stable operation. Always verify that the input supply is isolated before wiring. The IP20 rating means the unit must be installed inside a protective enclosure, which is typical for oil and gas control panels.

Why This unit Suits Oil and Gas Applications

Oil and gas operations demand power supplies that tolerate temperature extremes, vibration, and continuous duty. This unit operates from -10...+70 °C, covering most field-mounted enclosures. Its 89.0% efficiency reduces internal heat, which extends the life of nearby components. The DC OK relay contact supports predictive maintenance by alerting operators to output faults.

Typical uses include powering PLC racks, transmitters, and communication modules in wellhead control panels, pipeline monitoring stations, and compressor skids. The compact 75 × 45 × 91 mm footprint saves DIN rail space in crowded cabinets. With no communication interface, the unit focuses on robust power conversion, avoiding unnecessary complexity.

Maintenance and Troubleshooting for Long Service Life

Routine inspection of This unit involves checking terminal tightness and verifying output voltage with a multimeter. Because the unit has no fans or filters, maintenance is minimal. However, dust buildup on the enclosure can impede heat dissipation, so periodic cleaning of the cabinet interior is recommended.

If the DC OK contact does not close, first confirm input voltage is within the specified range. Next, check the output adjustment and load current. This unit is not field-repairable; replace the unit if a fault is confirmed. For detailed diagnostics, refer to official Allen-Bradley documentation or contact PetroPartsOnline for application-specific selection guidance.

Frequently Asked Questions

What input voltages does This unit accept?

The Allen-Bradley unit accepts AC 100...240 V nominal and DC 110...300 V, making it versatile for different supply systems.

Can This unit operate in high-temperature environments?

Yes, the operating temperature range is -10...+70 °C, which covers most oil and gas field installations.

What is the output current rating of This unit?

The nominal output current is 2.1 A, with a range of 2.1...1.8 A, and the rated power is 50 W.

Does This unit have a communication interface?

No, This unit has no built-in communication ports or protocols; it is a dedicated power supply.

How does the DC OK relay contact help with plc power supply module replacement?

The DC OK contact provides a status signal that can be monitored by a PLC, simplifying diagnostics during plc power supply module replacement and reducing downtime.

Contact PetroPartsOnline for parts suited to your application's requirements.
