What the Allen-Bradley 1606-XLP36C Delivers in Demanding Environments

The Allen-Bradley 1606-XLP36C is a DIN rail mounted power supply from the Bulletin 1606-XL series. It provides dual ±12 V outputs and 36 W of rated power. The unit accepts AC 100...240 V nominal or DC 110...300 V input, so it suits control panels that need a dependable low-voltage source in oil and gas operations.

Engineers specifying a PLC power supply module replacement often need a compact unit that fits existing DIN rail space. This unit measures 75 × 45 × 91 mm and weighs 240 g. Its spring terminals simplify wiring, while the adjustable output supports fine tuning between 12 and 15 V.

Key Specifications of This unit Power Supply

• Input voltage: AC 100...240 V nominal; DC 110...300 V
• Output voltage: DC ±12 V nominal, adjustable from 12...15 V
• Output current: 2.5 A nominal per output
• Rated power: 36 W
• Efficiency: 86.0% typical
• Ripple and noise: 50 mV maximum (mVpp)
• Operating temperature: -10...+70 °C
• Protection rating: IP20 for DIN rail or enclosure mounting
• Dimensions (H×W×D): 75 × 45 × 91 mm
• Weight: 240 g

The wide input range is a distinctive strength. It lets the same unit operate from AC mains or a DC bus without external selection. In addition, the 50 mV maximum ripple and noise helps protect sensitive analog circuits. The 86.0% typical efficiency reduces heat inside sealed enclosures.

Failure Modes and Reliability in Oil and Gas Panels

Power supplies are a common source of unplanned downtime in mission-critical control cabinets. This unit addresses several failure modes through its design. First, the wide operating temperature range of -10...+70 °C supports reliable operation in hot process areas and cold remote sites. Second, the IP20 rating protects against finger contact when mounted in an enclosure.

Over time, heat is the main enemy of any power supply. The 86.0% typical efficiency limits internal heat generation. Therefore, the unit places less stress on nearby components. In addition, the 50 mV maximum ripple and noise specification supports stable logic-level signals. Field-proven spring terminals resist loosening from vibration, which is common on skids and wellheads.

For a PLC power supply module replacement, engineers should verify that the existing DIN rail can carry the 240 g weight and that the 75 × 45 × 91 mm footprint fits the available space. The dual ±12 V output configuration also requires checking that the load accepts a bipolar supply.

Installation and Integration Guidance

Mount This unit on a standard DIN rail inside a protective enclosure. Connect input wiring to the spring terminals, observing the AC 100...240 V nominal or DC 110...300 V rating. Then set the output adjustment to the required voltage between 12 and 15 V. The unit has no built-in communication ports and no communication protocol. Therefore, integration is limited to hard-wired power distribution.

Because the supply provides dual outputs at 2.5 A nominal per output, plan load balancing across both rails. Keep input and output cables separated to reduce electrical noise. Confirm that the enclosure provides adequate ventilation for the 36 W rated power and the 86.0% typical efficiency. For applications exposed to vibration, inspect spring terminal connections during routine maintenance.

Typical Applications

This unit suits control panels that require a compact, dual-output DC source. For example, it can supply analog signal conditioning modules that need ±12 V rails. It also works in remote monitoring cabinets where AC 100...240 V nominal or DC 110...300 V input is available. In addition, the -10...+70 °C operating range supports installations in hot desert or cold northern sites. Because the unit is DIN rail mounted, it fits standard enclosure layouts used across oil and gas facilities.

Frequently Asked Questions

What input voltage does This unit accept?

The Allen-Bradley unit accepts AC 100...240 V nominal or DC 110...300 V input. This dual input capability allows the same unit to operate from AC mains or a DC bus.

Is This unit suitable for a PLC power supply module replacement?

Yes, This unit is a DIN rail power supply with dual ±12 V outputs and 36 W rated power. For a PLC power supply module replacement, verify that the existing panel space fits the 75 × 45 × 91 mm dimensions and that the load accepts a bipolar supply.

What is the operating temperature range of This unit?

The operating temperature range is -10...+70 °C. This range supports use in demanding oil and gas environments, from cold remote sites to hot process areas.

Does This unit have communication ports?

No. This unit has no built-in communication ports and no communication protocol. It is a power supply intended for hard-wired power distribution only.

How much current can each output provide?

Each output provides 2.5 A nominal. The total rated power is 36 W, and the output voltage is adjustable from 12...15 V.

Contact PetroPartsOnline for parts suited to your application's requirements. The Allen-Bradley unit is built for demanding environments, offering reliability you can depend on in mission-critical operations.
