Bently Nevada 200151-60-03-10 Armored Accelerometer Cable

The Bently Nevada 200151-60-03-10 is an armored accelerometer interface standard cable. This cable has connectors on both ends for easy installation. You can use it to connect accelerometers to monitoring systems in harsh environments. The armor provides extra protection against physical damage. The enhanced coupling nuts offer a better grip for tightening.

Technical Specifications of the 200151-60-03-10

The Bently Nevada 200151-60-03-10 has a total length of 6.0 meters. The armor option is blue cable with armor (code -03). The coupling nut option is enhanced type (code -10) on both ends. This configuration provides improved handling for demanding installations.

Enhanced Coupling Nut Feature

The enhanced coupling nut on the Bently Nevada 200151-60-03-10 provides a better grip. This makes tightening to the accelerometer much easier. The improved design is provided on both ends of the cable. This feature is especially useful in tight spaces or with gloved hands.

Cable Construction

The Bently Nevada 200151-60-03-10 uses 4-conductor 22 AWG wire. A braided shield with drain wire provides noise protection. The shield coverage is 85% minimum for reliable signal integrity. The outer jacket is made of blue PVC material. The armor adds an extra layer of mechanical protection.

Connector Specifications

The connectors provide an IP67 seal to transducers and mating hardware. The Bently Nevada 200151-60-03-10 connectors are molded directly to the cable. This molding provides excellent strain relief. DC4 electrical insulating compound is added inside the connectors. This compound provides additional moisture protection during thermal shock.

Temperature Ratings

The operating temperature range is -20°C to +100°C. The Bently Nevada 200151-60-03-10 may be used at lower temperatures. However, the cable must not flex or bend below -20°C. Flexing below -20°C may damage the cable. The connector temperature range is -55°C to +121°C.

Minimum Bend Radius

The minimum bend radius is 63.5 mm (2.5 inches). The Bently Nevada 200151-60-03-10 should not be bent tighter than this radius. The armor requires extra care during routing. Proper routing extends cable service life.

Cure Time

The DC4 insulating compound requires 24 hours cure time. This ensures proper moisture protection. Allow full cure before exposing to harsh environments.

Installation Guidelines for the 200151-60-03-10

Route the Bently Nevada 200151-60-03-10 with a bend radius of at least 63.5 mm. Avoid flexing the cable at temperatures below -20°C. Use the enhanced coupling nuts for a secure grip when tightening. Hand-tighten only; do not use tools. Allow 24 hours for the DC4 compound to cure. Support the cable weight along its 6.0 meter length.

Package Contents

• One (1) Bently Nevada 200151-60-03-10 armored accelerometer cable (6.0 meters)

• Connectors on both ends (pre-molded with enhanced coupling nuts)

Common FAQs for the 200151-60-03-10

1. What is the length of the 200151-60-03-10 cable?
The Bently Nevada 200151-60-03-10 has a length of 6.0 meters. The armor provides extra mechanical protection.

2. What are enhanced coupling nuts on this cable?
The enhanced coupling nuts on the Bently Nevada 200151-60-03-10 provide a better grip. This makes tightening to accelerometers much easier, especially in tight spaces.

3. Is the enhanced coupling nut on both ends?
Yes, the Bently Nevada 200151-60-03-10 has enhanced coupling nuts on both ends. This improves handling for both connections.

4. What is the operating temperature range for this cable?
The Bently Nevada 200151-60-03-10 operates from -20°C to +100°C. Do not flex the cable below -20°C to prevent damage.

5. What is the minimum bend radius for this armored cable?
The minimum bend radius is 63.5 mm (2.5 inches) for the Bently Nevada 200151-60-03-10. The armor requires careful routing.

Why Choose the Bently Nevada 200151-60-03-10?

This armored accelerometer cable provides enhanced protection and easier handling. The 6.0 meter length offers extended reach for large machinery. Enhanced coupling nuts provide a better grip for secure connections. IP67 connectors protect against moisture and dust. Order the Bently Nevada 200151-60-03-10 today for your armored accelerometer cabling needs.
