Introduction:
Allen-Bradley 1734-ADNX POINT I/O EtherNet/IP adapter module. Compact, din-rail mount, 2 RJ45 ports. New original in stock. 12-month warranty.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The Allen-Bradley 1734-ADNX is a POINT I/O adapter module for EtherNet/IP networks. It enables seamless communication between a controller and I/O modules. This module supports a single network connection. It provides a cost-effective solution for distributed I/O applications. The 1734-ADNX is part of the Rockwell Automation POINT I/O family. It is designed for industrial automation environments. The module is compact and din-rail mountable. It reduces wiring and cabinet space. This adapter module is ideal for remote I/O applications.
Application Scenarios
The 1734-ADNX is used in manufacturing and process industries. It connects remote I/O to a central controller via EtherNet/IP. Typical applications include conveyor systems, packaging machines, and material handling. It also works in water treatment and building automation. The module supports up to 63 I/O modules per network. It is suitable for both new installations and system expansions. The adapter can be placed in hazardous locations. It meets Class I Division 2 requirements.
Technical Specifications
- Network Type: EtherNet/IP
- Number of Ports: 2 (RJ45)
- Power Supply: 24V DC
- Current Consumption: 180 mA @ 24V DC
- Enclosure Type: Open Style
- Operating Temperature: -20°C to 55°C
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Dimensions: 87 x 25 x 75 mm
- Weight: 0.15 kg
Installation & Maintenance Guide
Mount the module on a DIN rail in a clean, dry location. Connect the 24V DC power supply to the correct terminals. Use shielded Ethernet cables for network connections. Do not exceed the specified current rating. Ensure proper grounding to prevent electrical noise. Regularly inspect the module for dust or damage. Replace the module if the LED indicators show faults. Follow all local electrical codes during installation.
Frequently Asked Questions (FAQ)
What is the primary function of 1734-ADNX?
The 1734-ADNX is an EtherNet/IP adapter that connects POINT I/O modules to a network.
How many I/O modules can be connected to one 1734-ADNX?
The adapter supports up to 63 I/O modules per network segment.
What is the operating temperature range for this module?
The operating temperature range is -20°C to 55°C.
Does the 1734-ADNX require a separate power supply?
Yes, it requires a 24V DC power supply with 180 mA current.
Is the module suitable for hazardous locations?
Yes, it meets Class I Division 2 requirements for hazardous environments.
