Introduction:
The TSXCANKCDF90TP is a Schneider CANopen SUB-D9 female connector bent at 90° with an additional SUB-D9, IP20 rated, designed for reliable bus connection.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
What Is the TSXCANKCDF90TP?
When your CANopen bus requires a robust and space-saving connection, the TSXCANKCDF90TP delivers. This Schneider accessory features a SUB-D9 female connector bent at 90° with an additional SUB-D9 male connector, all in an IP20-rated housing. It is engineered to simplify wiring in tight control cabinets while maintaining signal integrity.
Key Features & Technical Specs
- Connector type: 1 female SUB-D 9 elbowed and 1 male SUB-D 9.
- IP degree of protection: IP20.
- Product weight: 0.11 lb (0.051 kg).
- Part of the CANopen range of product.
Installation Guide
Mount the TSXCANKCDF90TP in a clean, dry environment to maintain its IP20 rating. The 90° bend helps route cables neatly in crowded panels. Ensure the female connector is securely fastened to the bus cable, and the male connector links to the next device. No special tools are required for assembly.
Maintenance & Reliability
Inspect the connector periodically for dust or debris that could affect contact quality. Because the TSXCANKCDF90TP is a passive accessory, it requires minimal upkeep. Regular visual checks during system audits help prevent intermittent bus faults.
Compatibility & Integration
This connector is designed for CANopen bus systems. It works with Schneider CANopen devices and other compliant nodes. The dual SUB-D9 ports allow daisy-chaining without extra adapters, simplifying network topology.
FAQ about TSXCANKCDF90TP
Q: What is the IP rating of the TSXCANKCDF90TP?
A: The TSXCANKCDF90TP has an IP20 degree of protection.
Q: Does the TSXCANKCDF90TP include a line terminator?
A: Yes, it is an accessory with a line terminator integrated.
Q: What connectors are on the TSXCANKCDF90TP?
A: It has one female SUB-D 9 elbowed connector and one male SUB-D 9 connector.
Q: What is the weight of the TSXCANKCDF90TP?
A: The product weight is 0.11 lb (0.051 kg).
Product Support & Availability
The TSXCANKCDF90TP is in stock and ready to ship from PetroPartsOnline. Contact our team for bulk pricing or expedited delivery options.
