Introduction:
The 2094-BM03-M is a 400VAC Kinetix 6000 Axis Module from Allen-Bradley with 21.2 A continuous current and 53.0 A peak current.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The 2094-BM03-M is a Kinetix 6000 Multi-Axis Servo Drive System component from Allen-Bradley, manufactured by Rockwell Automation. This Integrated Axis Module belongs to the 400VAC class and delivers robust motion control for demanding industrial applications. With a continuous output current of 21.2 A and peak current of 53.0 A, it provides reliable performance for servo motor drives.
Technical Specifications Analysis
The 2094-BM03-M operates on a nominal drive voltage of 360-480 Volts (3 Phase) and a voltage rating of 460 Volt (AC). It offers a continuous power output of 13.5 kW and an output current of 30 Amperes. The module achieves an efficiency of 98%, minimizing energy loss. Power dissipation ranges from 94 to 255 Watts depending on loading. It includes an internal shunt with 200W continuous power and 22.5 kW peak power. The operating temperature range is 32-122 F (0-50 C). Dimensions are 2.76 x 11.9 x 13.2 inches (70 x 302 x 336 mm), and weight is 7.0 lbs (3.18 kg).
Application Scenarios & Usage Methods
This axis module is ideal for multi-axis motion control in packaging, material handling, and machine tool applications. It interfaces with rotary and linear motors via feedback cables, enabling precise positioning and speed control. The module mounts onto a Power Rail alongside other Kinetix 6000 components, allowing flexible system configuration. Its embedded safety features, such as Safe Torque Off and Safe Speed Monitor, support maintenance without full machine shutdown, improving productivity.
Installation Guide & Packing List
Install the 2094-BM03-M on a compatible Power Rail in a clean, dry environment within the specified operating temperature range. Ensure proper grounding and follow Rockwell Automation guidelines for wiring and bus capacitance. The package typically includes one Integrated Axis Module. Verify the part number matches your system requirements before installation.
Purchasing Advice
When selecting the 2094-BM03-M, confirm your system voltage class (400V) and current needs (21.2 A continuous, 53.0 A peak). This module is suitable for new builds or upgrades of Kinetix 6000 systems. PetroPartsOnline offers this genuine Allen-Bradley module with reliable supply chain support for industrial automation and oil/gas sectors.
Repair & Maintenance Tips
Regularly inspect the module for dust accumulation and ensure adequate ventilation. Check connections for tightness and signs of wear. Store in a dry environment within the 32-122 F range. Monitor power dissipation levels to avoid overheating. Use diagnostic error messages for early fault detection.
