GE Fanuc IC693PRG301 – Handheld Programmer for Series 90-30 PLCs

The GE Fanuc IC693PRG301 is a handheld programmer module. This device belongs to the Series 90-30 product family. It is also known as an HHP (Handheld Programmer). The IC693PRG301 configures PLC devices and I/O parameters. It connects to a personal computer or CPU directly. A 15-pin D-type connector handles the physical connection. This GE Fanuc IC693PRG301 supports the statement list programming language. The device edits, inserts, and deletes program changes efficiently. An integrated keypad allows operating mode changes. An LCD screen displays critical information during use.

Full Technical Specifications

Hardware & Display Features

• Connector Type: 15-pin D-type connector.

• Keypad: Yes, fully integrated membrane keypad.

• Display Type: LCD screen present on front panel.

• Display Capacity: 2 lines x 16 characters per line.

• Display Content: Depends on current operating mode.

• Memory Card Interface: Yes, accepts memory cards.

• Memory Card Use: Stores program logic and configuration data.

• The GE Fanuc IC693PRG301 expands memory via card interface.

Programming & Functionality

• Program Language Supported: Statement list program.

• Edit Functions: Insert and delete program changes.

• Monitoring Capability: Monitor reference data values.

• I/O Status Check: Review I/O point status during operation.

• Logic Review: View logic program while monitoring.

• Mode Configuration: Change PLC operating modes via keypad.

• Function Selection: Screen content changes with selected function.

• The IC693PRG301 supports both programming and monitoring tasks.

Communication & Power

• Communication Port: RS-422 compatible port.

• Direct Communication: Connects directly to PLC CPU.

• Cable Type: Latching connector cable required.

• Cable Function: Provides both data and power delivery.

• Connection Indication: PLC detects when HHP is connected.

• Cable Supported: Latching connector cable specifically.

• Power Source: Supplied through the connection cable.

• The GE Fanuc IC693PRG301 requires no separate power supply.

Physical & Environmental

• Brand: GE Fanuc (Emerson Automation).

• Part Number: IC693PRG301.

• Product Lifecycle Status: Discontinued / Obsolete.

• Form Factor: Handheld portable device.

• Construction: Rugged industrial-grade housing.

• Application: Industrial automation programming tasks.

Installation Guide

Connect the GE Fanuc IC693PRG301 to your Series 90-30 PLC first. Use a latching connector cable for secure attachment. Insert the cable into the 15-pin D-type port on the PLC. The cable supplies operating power to the handheld device. Verify the PLC recognizes the connected HHP automatically. Insert a memory card for expanded storage if needed. Power on the Series 90-30 system normally. Use the keypad to select the desired operating mode. Begin programming using the statement list language. Monitor I/O status or reference data as required. Remove the cable carefully after finishing your work.

Packaging List

• One GE Fanuc IC693PRG301 Handheld Programmer unit

• One latching connector communication cable

• One protective dust cover for 15-pin connector

• One quick reference keypad overlay card

• One soft carrying case

Common FAQs

Q1: Can the IC693PRG301 program all Series 90-30 PLCs?
A: Yes, this GE Fanuc IC693PRG301 works with all Series 90-30 CPUs. It configures I/O parameters and logic programs. Use the statement list programming language for best results.

Q2: Does this handheld programmer need a separate power supply?
A: No, the IC693PRG301 receives power through the cable. The latching connector cable carries both data and power. Connect it to the PLC for full operation.

Q3: What type of memory card does the GE Fanuc IC693PRG301 accept?
A: It accepts proprietary GE Fanuc memory cards. These cards store program logic and configuration data. The memory card interface expands the device storage capacity.

Q4: Can I monitor live I/O status with this HHP device?
A: Yes, the IC693PRG301 monitors reference data and I/O point status. You can review the logic program while monitoring. The LCD screen shows two lines of 16 characters.

Q5: Is the GE Fanuc IC693PRG301 still in production?
A: No, this product lifecycle status is discontinued or obsolete. The IC693PRG301 remains available through aftermarket suppliers. Verify compatibility before purchasing used units.
