Product Overview

The Triconex 3411 belongs to the Triconex 3000 Series. This communication module connects your Triconex system to external networks. The Triconex 3411 enables reliable data exchange with host systems and controllers. It supports both Modbus TCP/IP and Ethernet/IP industrial protocols. You can use this module for remote monitoring and control applications. The Triconex 3411 maintains the high integrity expected from Triconex products.

Technical Specifications

The Triconex 3411 delivers robust communication performance for critical systems. All parameters follow the official datasheet.

Communication Capabilities

• Communication protocols: Modbus TCP/IP and Ethernet/IP

• Maximum data rate: 100 Mbps

• Ports: 2 x RJ45 copper ports and 1 x Fiber Optic port

• The fiber optic port provides electrical isolation and noise immunity.

• Module type: TriStation Communication Module (TCM)

Power Requirements

• Power supply: 24 VDC ±10%

• Ensure stable power for reliable communication.

• The Triconex 3411 consumes moderate power for its processing load.

Environmental & Physical

• Operating temperature: -10°C to 60°C

• This range suits most industrial control rooms and panels.

• Dimensions: 6.2 cm (H) x 42 cm (W) x 17.7 cm (D)

• The compact form factor fits standard Triconex chassis.

Installation Guide

Follow these steps to install the Triconex 3411 correctly.

1. Power down the Triconex chassis before inserting any module.

2. Align the Triconex 3411 with the correct slot in the chassis.

3. Slide the module firmly into place until fully seated.

4. Secure the module using the top and bottom retaining screws.

5. Connect network cables to the two RJ45 ports as needed.

6. Connect the fiber optic cable to the dedicated fiber port for long distances.

7. Apply 24 VDC ±10% power to the chassis.

8. Configure communication parameters using TriStation software.

Packing List

This package for the Triconex 3411 includes the following items.

• Triconex 3411 TCM Communication Module (one unit)

• Product installation leaflet

• Fiber optic port dust cap (pre-installed)

• Anti-static protective bag

Frequently Asked Questions (FAQ)

1. What protocols does the Triconex 3411 support?
The Triconex 3411 supports Modbus TCP/IP and Ethernet/IP. These are standard industrial communication protocols for automation systems.

2. Can I use both RJ45 ports at the same time on the 3411?
Yes, you can use both RJ45 ports simultaneously. The Triconex 3411 supports dual copper connections for redundancy or separate networks.

3. What is the fiber optic port used for on the Triconex 3411?
The fiber optic port provides long-distance communication. The Triconex 3411 uses fiber for electrical isolation and noise immunity in harsh environments.

4. What is the maximum data rate for the Triconex 3411?
The maximum data rate is 100 Mbps. The Triconex 3411 delivers this speed on both RJ45 and fiber optic ports.

5. Is the Triconex 3411 hot-swappable?
Refer to your system documentation before hot-swapping. The Triconex 3411 typically requires chassis power-down for safe installation.
