MTL5522 | MTL Solenoid/Alarm Driver Supplier
Introduction:
The MTL5522 solenoid/alarm driver from MTL provides reliable digital output for hazardous locations with SIL1 and SIL3 certification.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
When Hazardous Environments Demand Reliable Solenoid/Alarm Control
In hazardous classified locations, equipment failure can lead to costly downtime and safety risks. The MTL5522 from MTL is engineered to deliver consistent digital output for solenoid and alarm applications, ensuring process integrity even in Zone 0 areas. With its loop-powered design and robust galvanic isolation, this single-channel driver meets the stringent demands of industrial automation and oil/gas operations.
Core Specifications of the MTL5522 Solenoid/Alarm Driver
- Power supply: 20-35 Vdc with 125mA current consumption at 24V
- Power dissipation: 1.4W at 24V for efficient operation
- Response time: output within 10% of final value within 100ms
- Galvanic isolation: 250V rms between safe-area circuits and power supply
- Minimum output voltage: 10.7V at 70mA; maximum output voltage: 24V from 158Ω
- Current limit: 70mA minimum for reliable solenoid activation
- Ripple: less than 0.5% of maximum output, peak-to-peak
- LED indication: yellow status light for quick visual confirmation
One standout feature is the 250V rms galvanic isolation, which protects downstream equipment from voltage surges and ground loops. This isolation is critical in harsh industrial environments where electrical noise can disrupt sensitive alarms.
Installation and Mounting of the MTL5522
Mounting the MTL5522 is straightforward on a T-section 35mm DIN rail. The electrical connection uses crimp ferrules, and the terminal accepts conductors up to 2.5mm² stranded or single-core. Ensure the power supply is within 20-35 Vdc and verify polarity before connecting. For optimal performance, keep wiring as short as possible and avoid running signal lines near high-power cables.
Maintenance and Reliability in Hazardous Locations
Routine inspection of the MTL5522 should focus on checking the LED indicator and verifying output voltage at the solenoid. The unit operates reliably from -20°C to 60°C ambient temperature and can be stored from -40°C to 80°C. With a humidity tolerance of 5-95% relative humidity, it suits both indoor and sheltered outdoor installations. Regular cleaning of the DIN rail and terminal connections helps maintain long-term performance.
Frequently Asked Questions about the MTL5522
Q: What is the power supply range for the MTL5522?
A: The power supply range is 20-35 Vdc, with a typical current consumption of 125mA at 24V.
Q: How many channels does the MTL5522 have?
A: It is a single-channel digital output driver, designed for one solenoid or alarm load.
Q: What is the response time of the MTL5522?
A: The output reaches within 10% of its final value within 100ms.
Q: Does the MTL5522 provide galvanic isolation?
A: Yes, it offers 250V rms isolation between safe-area circuits and the power supply.
Q: What is the operating temperature range for the MTL5522?
A: The minimum ambient operating temperature is -20°C, and the maximum is 60°C.
Q: How is the MTL5522 mounted?
A: It mounts on a T-section 35mm DIN rail and uses crimp ferrules for electrical connections.
Product Support and Availability
The MTL5522 is available through PetroPartsOnline, a trusted supplier of industrial automation and oil/gas parts. Contact our team for current stock levels and lead times. We provide fast shipping and dedicated support to keep your operations running smoothly.
