MTL5581 | MTL Millivolt/Thermocouple Isolator Supplier
Introduction:
The MTL5581 millivolt/thermocouple isolator from MTL delivers precise signal conditioning for hazardous areas with fast response and low drift.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Introduction to the MTL5581
When temperature signal integrity matters in hazardous locations, the MTL5581 provides reliable isolation and conditioning. This Eaton Crouse-Hinds series MTL5500 millivolt/thermocouple isolator handles low-level signals with high accuracy and speed. Its compact design and robust construction make it a cost-effective choice for demanding industrial environments.
Key Features and Technical Specs of the MTL5581
- Single-channel temperature input with DC millivolt source compatibility.
- Transfer accuracy of <0.05% of reading or ±5μV, whichever is greater.
- Response time settles to within 10% of final value within 150μs.
- Power dissipation of 0.7W typical at 24V, 0.91W at 35V.
- Galvanic isolation of 250V rms between safe-area circuits and power supply.
- Operating temperature range from -20°C to 60°C.
- Mounts on T-section 35mm DIN rail for easy installation.
- LED indication with green power LED for quick status checks.
The standout spec is the 150μs response time. This fast settling reduces measurement lag, enabling quicker process adjustments and minimizing waste. Over time, this speed translates to lower energy consumption and higher throughput, directly impacting operational costs.
Industry Applications and Use Cases
In oil and gas refineries, the MTL5581 isolates thermocouple signals from hazardous Zone 0 areas. Its low drift of <2μV/°C ensures stable readings across temperature swings, reducing recalibration frequency. For chemical plants, the over-range capability to ±55mV prevents signal clipping during process upsets, avoiding costly downtime. Additionally, its DC to 4 kHz switching frequency supports fast temperature cycling in batch processes, improving yield consistency.
Installation and Setup Guide
Mount the MTL5581 on a standard 35mm DIN rail. Use crimp ferrules for electrical connections, accepting conductors up to 2.5mm² stranded or single-core. Set the two early burnout switches to enable or disable safety drive and select upscale or downscale operation. Connect the power supply between 20-35 Vdc, ensuring the load resistance stays within 60Ω to 600Ω for optimal output. Always verify wiring per the manual to avoid signal errors.
Maintenance and Reliability Tips
Inspect the MTL5581 periodically for dust accumulation on the DIN rail mount, as debris can affect heat dissipation. The unit’s low power dissipation of 0.7W typical reduces thermal stress, extending component life. In humid environments (5-95% RH), ensure proper enclosure sealing to prevent condensation. Regular calibration checks every 6-12 months maintain the <0.05% accuracy, reducing long-term maintenance costs.
Frequently Asked Questions about the MTL5581
Q: What is the input signal range for the MTL5581?
A: It accepts any DC millivolt source, with an output signal range of 0mV to ±50mV.
Q: Does the MTL5581 support hazardous area installations?
A: Yes, it is rated for Zone 0 hazardous locations and complies with IECEx/ATEX standards.
Q: What is the power supply requirement?
A: The unit requires 20-35 Vdc and consumes 30mA current.
Q: How fast does the MTL5581 respond to input changes?
A: It settles to within 10% of final value within 150μs, ideal for fast processes.
Q: Can the MTL5581 be used with thermocouples?
A: Yes, it is designed as a millivolt/thermocouple isolator for temperature inputs.
Product Support and Availability
The MTL5581 is in stock and ready to ship from PetroPartsOnline. As a trusted supplier of industrial automation and oil/gas parts, we ensure fast delivery and competitive pricing. Contact our team for bulk orders or technical inquiries.
