Product Overview

The GE Fanuc IC670GBI001 is a Genius bus interface unit designed for the Field Control product series. This BIU works with IC670, IC670G, IC670GB, IC670GBI, and IC670GBI00 modules. Engineers use the IC670GBI001 to connect Field Control I/O modules to a Genius network. Its robust aluminum housing resists noise, vibration, and temperature extremes. This unit suits applications that need a reliable bus interface for distributed control systems.

Technical Specifications

The GE Fanuc IC670GBI001 delivers flexible power options and reliable bus interface functionality.

• Product Type: Genius Bus Interface Unit (BIU).
• Compatibility: Field Control IC670, IC670G, IC670GB, IC670GBI, and IC670GBI00 modules.
• Nominal Rated Voltage: 115 Volts AC and 125 Volts DC.
• Voltage Range (AC): 90 to 135 Volts AC.
• Voltage Range (DC): 105 to 150 Volts DC.
• Frequency Range: 47 to 63 Hertz.
• Power at 115V AC (full load): 48 Volt-Amps maximum.
• Power at 125V DC (full load): 24 Watts maximum.
• Inrush Current: 20 Amps peak for 3 milliseconds maximum.
• Power Supply Output: 6.5 Volts DC.
• Holdup Time: 20 milliseconds maximum.
• Status Indicators: 4 LEDs (PWR, OK, RUN, BUS B).
• Housing Material: Aluminum.

Power Supply Specifications and Options

The GE Fanuc IC670GBI001 accepts both AC and DC power for global compatibility. AC nominal voltage is 115 Volts with a range of 90 to 135 Volts. DC nominal voltage is 125 Volts with a range of 105 to 150 Volts. Input frequency range spans 47 to 63 Hertz for worldwide use. Power consumption at 115 Volts AC reaches 48 Volt-Amps maximum at full load. Power consumption at 125 Volts DC reaches 24 Watts maximum at full load. Inrush current peaks at 20 Amps for up to 3 milliseconds during startup. The power supply output provides 6.5 Volts DC to connected Field Control modules. Holdup time reaches 20 milliseconds maximum during power interruptions. The IC670GBI001 includes a logic power supply for internal circuit operation. Backplane current may be limited by lower input voltages on DC power.

Genius Network Communication and Integration

The GE Fanuc IC670GBI001 connects Field Control I/O modules to a Genius network. This bus interface unit serves as the central processing unit for the distributed control system. The BIU handles complete I/O data exchange with connected Field Control modules. Configuration files for the IC670GBI001 store in the memory of the terminal block. A compatible bus interface unit power supply works together with this BIU. A bus interface unit terminal block provides the physical connection point for wiring. The module includes an HHM connector for a hand-held monitor device. This handheld programmer allows configuration and diagnostics in the field. The IC670GBI001 operates perfectly with other Field Control components.

LED Status Indicators and Diagnostics

The GE Fanuc IC670GBI001 features four LED indicators for status monitoring. The PWR (Power) LED shows when the unit receives correct input voltage. The OK LED indicates the module is operating without internal faults. The RUN LED shows that the bus interface unit is actively communicating. The BUS B LED indicates the status of communication with the CPU on the Genius network. These LEDs help operators diagnose problems quickly without special tools. All LED indicators are visible from the front of the IC670GBI001 module. The aluminum housing protects internal components while allowing heat dissipation. The module is resistant to common industrial environment conditions. These conditions include noise, vibration, high temperatures, low temperatures, and humidity.

Environmental Durability and Construction

The GE Fanuc IC670GBI001 features top-quality housing made from aluminum material. This aluminum construction provides excellent electromagnetic interference (EMI) shielding. The housing also helps dissipate heat from internal power components. The module resists vibration commonly found on factory floors. Operating temperature range matches other Field Control components for system consistency. The IC670GBI001 tolerates humidity variations without performance degradation. The open enclosure design requires installation inside a protective panel or cabinet. The unit includes a hand-held monitor connector for easy field access. GE Fanuc is known for producing technical solutions for many industries. The IC670GBI001 continues this tradition of industrial-grade reliability.

Installation and Configuration Guidelines

Mount the GE Fanuc IC670GBI001 inside a NEMA-rated panel or enclosure for protection. Connect the AC power input to 115 VAC nominal (90-135 VAC range). Connect the DC power input to 125 VDC nominal (105-150 VDC range). Do not exceed the maximum voltage ratings to prevent internal damage. Use proper grounding techniques to reduce noise on the Genius network. The holdup time of 20 ms allows the unit to ride through brief power dips. Connect up to 8 Field Control modules to the IC670GBI001 for a complete station. Configure the unit using a hand-held monitor connected to the HHM port. Configuration files store in the terminal block memory for each setup. The 6.5 VDC power supply output powers all connected I/O modules.

Package Contents

When you unbox the GE Fanuc IC670GBI001, you will find these items:

• 1 x GE Fanuc IC670GBI001 Genius bus interface unit.
• 1 x Terminal block for power and network connections.
• 1 x Product label and identification tag.
• 1 x Installation and configuration guide.

Frequently Asked Questions (FAQ)

What power supply options does the IC670GBI001 accept?

The **IC670GBI001** accepts 115 Volts AC (90-135 VAC range) or 125 Volts DC (105-150 VDC range). Input frequency ranges from 47 to 63 Hertz for AC power.

What modules are compatible with the GE Fanuc IC670GBI001?

This bus interface unit works with IC670, IC670G, IC670GB, IC670GBI, and IC670GBI00 Field Control modules. Up to 8 modules can connect to one BIU.

What do the LEDs on the IC670GBI001 indicate?

The **IC670GBI001** has four LEDs: PWR (power), OK (module status), RUN (active communication), and BUS B (CPU communication status). These show proper functioning and network status.

Does the IC670GBI001 include a hand-held monitor connector?

Yes, the **IC670GBI001** includes an HHM connector for a hand-held monitor device. This allows field configuration and diagnostics without a computer.

What is the holdup time for the IC670GBI001 during power dips?

The **IC670GBI001** has a holdup time of 20 milliseconds maximum. This allows the unit to ride through brief power interruptions without resetting.
