Buy GE Fanuc IC670MDL330 Field Control 16-Point AC Output Module
Introduction:
Product Overview The GE Fanuc IC670MDL330 is a high-density discrete output module. It belongs to the reliable Field Control series. This module provides sixteen AC output channels for industrial automation. It connects directly to a Bus Interface Unit (BIU). The unit manages 12 to 120 Volts AC loads effectively. It uses a sourcing configuration to […]
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The GE Fanuc IC670MDL330 is a high-density discrete output module. It belongs to the reliable Field Control series. This module provides sixteen AC output channels for industrial automation. It connects directly to a Bus Interface Unit (BIU). The unit manages 12 to 120 Volts AC loads effectively. It uses a sourcing configuration to power external devices. You can control solenoids, relay coils, and pilot lights easily. The IC670MDL330 ensures safe operation with built-in group protection. Its compact design saves cabinet space while maintaining high performance.
Technical Specifications
- Brand: GE Fanuc
- Series: Field Control
- Model: IC670MDL330
- Module Type: Discrete AC Output
- Number of Channels: 16 Points (Single Group)
- Nominal Voltage: 12 to 120 Volts AC
- Operating Range: 10 to 132 Volts AC
- Frequency Range: 47 to 63 Hz
- Output Current: 1 Amp per point (4 Amps maximum per module)
- Minimum Load: 10 mA
- On/Off Response Time: 1/2 cycle maximum
- Voltage Drop: 2.0 Volts maximum at full load
- Leakage Current: Less than 2 mA at 120 VAC
- Isolation: 1500 VAC (1 minute) / 250 VAC (continuous)
- Bus Current Draw: 275 mA from BIU power supply
- Inrush Current: 10 Amperes for 20 milliseconds
- Data Width: 2 Bytes (16 Bits)
- Protection: 5A Slow-blow fuse (5x20mm) and RC snubber per point
Installation and Compatibility
- The IC670MDL330 plugs into a standard Field Control terminal base.
- The Bus Interface Unit (BIU) handles all logic communication.
- The module loops data back to the BIU for signal verification.
- You can configure default output states through the host controller.
- Parallel data conversion is possible via serial-to-parallel devices.
- Ensure the total module current does not exceed 4 Amperes.
Diagnostics and Maintenance
- Channel LEDs: Sixteen individual indicators show the status of each output.
- Fuse OK LED: A dedicated light signals if the internal fuse blows.
- Replaceable Fuse: Easily swap the 5 Amp slow-blow fuse during maintenance.
- Signal Feedback: The module verifies serial data accuracy automatically.
- Built-in Snubbers: Protects circuitry from inductive voltage spikes.
Typical Applications
- Controlling AC Solenoid Valves in fluid systems.
- Operating Industrial Relay Coils and contactors.
- Driving Pilot Lamps and indicator panels.
- Managing On/Off actuators in factory environments.
Shipping, Warranty, and FAQ
- Package List: One GE Fanuc IC670MDL330 module in factory packaging.
- Warranty: 12-Month Quality Guarantee included.
- Express Delivery: Fast shipping via FedEx, UPS, or DHL.
- FAQ: Does it include the terminal base? No, the base is sold separately.
- FAQ: Can I use it for DC loads? No, this module supports AC voltage only.
