Technical Specifications

The Bently Nevada 330190-080-00-CN belongs to the 3300 XL series of extension cables. This ETR cable connects Proximitor sensors to monitors in high temperature environments. The PFA insulation provides superior heat resistance compared to standard FEP cables.

Cable Length and Options

DC Resistance Specifications

Center Conductor to Center Conductor (RCORE)

Outer Conductor to Outer Conductor (RJACKET)

Electrical Specifications

Linear Range and Gap Setting

• Linear Range: 2 mm (80 mils)

• Linear Range Start: Approximately 0.25 mm (10 mils) from target

• Linear Range End: 0.25 to 2.3 mm (10 to 90 mils) approximately -1 to -17 Vdc

• Recommended Gap for Radial Vibration: -9 Vdc (approximately 1.27 mm / 50 mils)

Field Wiring Specifications

Cable Materials

Mechanical Specifications

Temperature Range

Interchangeability

The 3300 XL 8 mm components are electrically and physically interchangeable with non-XL 3300 5 mm and 8 mm components. Observe minimum permissible cable bend radius for proper operation.

Compliance and Certifications

FCC Compliance

• Complies with part 15 of FCC Rules

• May not cause harmful interference

• Must accept any received interference

EMC Compliance

RoHS Compliance

• Complies with RoHS Directive 2011/65/EU

Maritime Compliance

Functional Safety

Installation Guidelines

Follow these steps to install your Bently Nevada 330190-080-00-CN extension cable correctly.

1. Inspect the Cable – Check for cuts, kinks, or damage to PFA insulation.

2. Plan the Route – Keep bend radius larger than 25.4 mm (1.0 in).

3. Connect to Proximitor – Attach one end to the 3300 XL Proximitor sensor.

4. Connect to Monitor – Attach the other end to the monitoring device.

5. Secure the Cable – Use non-metallic cable ties every 0.5 meters.

6. Tighten Connectors – Apply maximum 0.565 N•m (5 in•lbf) torque.

7. Keep Away from Heat – Route away from high temperature surfaces.

8. Verify Continuity – Check resistance values match specifications.

Do not exceed 0.565 N•m connector torque. Overtightening will damage gold-plated connectors.

Bend Radius Requirements

Field Wiring Extension

When extending beyond the 8.0 meter cable, observe these limits.

Package Contents (No Certificates or Warranty Terms)

Your shipment for product number 330190-080-00-CN includes the following items:

• 1 x Bently Nevada 330190-080-00-CN Extension Cable (8.0 meters)

• 2 x Gold-plated connectors (one on each end, pre-installed)

• 1 x Anti-static protective bag for storage

• 1 x Installation instruction sheet (printed)

Note: Proximitor sensor and monitor are sold separately.

Frequently Asked Questions (FAQ)

1. What is the difference between standard and ETR extension cables?
The ETR cable uses PFA insulation instead of FEP. This extends the maximum temperature rating from +177°C to +260°C.

2. What is the length of the Bently Nevada 330190-080-00-CN cable?
This cable measures 8.0 meters (26.2 feet). The -080 option specifies the 8.0 meter length.

3. Can I use this cable with non-XL 3300 components?
Yes. 3300 XL 8 mm components are electrically and physically interchangeable with non-XL 3300 5 mm and 8 mm components.

4. What is the minimum bend radius for the 330190-080-00-CN?
The minimum bend radius is 25.4 mm (1.0 inch). Sharper bends will damage the triaxial cable construction.

5. What functional safety ratings does this cable support?
This cable supports SIL 2 with HFT=0 and SIL 3 with HFT=1. Use appropriate system architecture for your safety level.

6. How far can I extend field wiring beyond this cable?
You can extend up to 305 meters (1,000 feet) total between the Proximitor sensor and monitor. Use 3 conductor shielded triad cable.

Why Choose This Model?

The Bently Nevada 330190-080-00-CN offers extended temperature performance for 3300 XL systems. Its PFA insulation withstands up to +260°C for high temperature machinery monitoring. The 8.0 meter length reaches from hot machine surfaces to cooler mounting locations. The gold-plated connectors resist corrosion and maintain signal integrity. The 75Ω triaxial design rejects electrical noise in industrial environments. The SIL 2 and SIL 3 ratings support safety critical applications. The maritime compliance allows installation on ships and offshore platforms. Choose this 330190-080-00-CN for turbine monitoring, compressor protection, and high temperature machinery in power plants, refineries, marine vessels, and offshore facilities.
