1763-L16DWD | Allen-Bradley MicroLogix PLC Controller
Introduction:
Allen-Bradley MicroLogix 1100 PLC with 16 I/O, Ethernet, and relay outputs. New original in stock with 12-month warranty.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The Allen-Bradley 1763-L16DWD is a MicroLogix 1100 programmable logic controller. It combines a CPU, power supply, and I/O in a compact unit. This controller supports 16 digital I/O points. It is an ideal solution for small-scale automation tasks. The module offers built-in Ethernet and serial ports. It simplifies communication in distributed control systems. This unit is a new original product. It is available for immediate shipment. The controller ensures reliable operation in industrial environments. It is designed for easy integration into existing networks.
Application Scenarios
This controller is used in material handling systems. It manages conveyor belt sequences and sorting operations. The module controls packaging machinery in production lines. It handles simple process control in food and beverage plants. The unit operates in water and wastewater treatment facilities. It monitors pumps, valves, and level sensors. The controller is suitable for HVAC building management. It regulates temperature, humidity, and air flow. The module works in standard industrial warehouse storage. It performs machine guarding and safety interlocks. The controller is deployed in automotive assembly stations. It controls part feeding and robotic work cells.
Technical Specifications
The module has 10 digital inputs and 6 digital outputs. The inputs are 24V DC sourcing type. The outputs are relay type with 2A rating. The controller includes a built-in 24V DC power supply. It consumes 10W of power maximum. The unit has 8K words of user program memory. It supports Modbus RTU and TCP/IP protocols. The operating temperature range is 0 to 55 degrees Celsius. The module is UL and CE certified. It measures 120mm by 80mm by 70mm. The weight is 0.5 kg. The product origin is the United States.
Installation & Maintenance Guide
Mount the controller on a standard DIN rail. Ensure adequate clearance for ventilation. Connect the 24V DC power supply to the input terminals. Wire the digital inputs to sensors and switches. Wire the relay outputs to actuators and contactors. Use shielded cables for Ethernet connections. Ground the controller to the panel earth. Perform a power cycle after initial programming. Check LED indicators for status and faults. Replace the unit if the power supply fails. Keep the controller free of dust and moisture. Test I/O points regularly using the software.
Frequently Asked Questions (FAQ)
What is the primary function of 1763-L16DWD?
The primary function is to execute logic programs for controlling industrial machinery. It integrates CPU, power supply, and I/O in one unit.
What is the operating voltage range for this controller?
The controller operates on a 24V DC power supply. The acceptable range is 20.4 to 28.8V DC.
Can this module communicate with a SCADA system?
Yes, the built-in Ethernet port supports Modbus TCP/IP. It also has a serial port for Modbus RTU communication.
How many digital outputs does the 1763-L16DWD have?
It has 6 relay-type digital outputs. Each output is rated for 2A at 24V DC or 120V AC.
What is the memory capacity of this controller?
The controller has 8K words of user program memory. It also includes 4K words of data memory.
