170ADO35000 Schneider Modicon Momentum 32-Output DC Module
Introduction:
Schneider Electric 170ADO35000 is a high-density output module for the Modicon Momentum series. This unit provides 32 solid-state outputs for DC control systems. It operates within a 0 to 24 V DC voltage range. The 170ADO35000 handles demanding industrial automation tasks efficiently. Use this module to control solenoids, indicators, and small relays.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Technical Specifications of 170ADO35000
Output Channels: 32 solid-state outputs for DC loads.
Output Voltage Range: 0 to 24 V DC nominal rating.
Surge Current: Handles 5 A for 1 ms duration during startup.
Voltage Drop: Stays under 0.5 V at 0.5 A load.
Overload Protection: Electronically protected against short circuits.
Maximum Output Frequency: Supports 1 kHz switching for high-speed applications.
Insulation Voltage: Provides 4 kV isolation per IEC 801-2.
Air Discharge Voltage: Withstands up to 8 kV for robust protection.
Radiated Immunity: Resists 10 V/m from 80 to 1000 MHz.
Operating Temperature: Works reliably from 0 to 60 °C.
Storage Temperature: Survives -40 to 85 °C when not in use.
Installation Location: Suitable for Pollution Degree 2 environments.
Installation and Compatibility Guide
Mount the 170ADO35000 on a Modicon Momentum base plate or rack. Connect a 24 V DC power supply to the module. Wire each output point to your field devices carefully. Keep the continuous current below 0.5 A per channel. The module can handle brief 5 A surges for 1 ms only. Do not exceed this surge duration or rating. Use the module in clean, dry locations with Pollution Degree 2 rating. Maintain ambient temperatures between 0 and 60 °C for proper operation. The electronic protection will activate if you overload a channel. After fixing the fault, the module resumes normal function automatically.
Package Contents
One Schneider Electric 170ADO35000 output module.
Product documentation and quick reference guide.
No additional cables or connectors are included.
Frequently Asked Questions (FAQ)
Q: What types of loads can the 170ADO35000 drive?
A: It drives DC loads like indicator lights, small relays, and solenoid valves. Use it for any 24 V DC device under 0.5 A.
Q: Can I use this module for PWM control applications?
A: Yes, the 170ADO35000 supports up to 1 kHz switching frequency. This makes it suitable for basic PWM tasks.
Q: What happens if I short circuit an output channel?
A: The electronic overload protection will trip and disable that channel. Once you remove the short, the channel recovers automatically.
Q: Is the 170ADO35000 compatible with 12 V DC systems?
A: Yes, the module accepts any voltage from 0 to 24 V DC. You can use it with 12 V DC loads without issues.
Q: How do I know if the module is working correctly?
A: Use the status LEDs on the module face. Each output channel has a dedicated indicator light.
