Product Summary

The IC695PSD140 is a multipurpose power supply for the PACSystems RX3i platform. This module delivers up to 40 Watts of power with three distinct output voltages. It supports both load-sharing and redundancy configurations to ensure system uptime. Engineers rely on this unit for its flexible input range and robust diagnostics. The module installs directly into a universal backplane for easy integration.

Theme: Product Procurement & Buyer Guide

Understanding the IC695PSD140 Power Architecture

The IC695PSD140 provides three critical output rails for your RX3i system. It delivers 0-6 A @ 5.1 VDC and 0-9 A @ 3.3 VDC for internal logic. A third rail supplies 0-1.6 A @ 24 VDC for power circuits and output relays. The total output power is limited to 40 Watts maximum. This design supports a wide range of I/O and CPU modules.

Input Voltage Flexibility for Global Sites

This module accepts a wide DC input voltage range. You can feed it with 18 to 30 VDC from your plant’s DC bus. The maximum input power at full load is 60 Watts. This flexibility allows the unit to work in various industrial environments. It eliminates the need for a separate AC-to-DC conversion stage in many setups.

Redundancy and Load Sharing Capabilities

You can install up to four IC695PSD140 modules in a single backplane. This setup supports both increased capacity and redundant power configurations. In load-sharing mode, all modules must connect to the same power source. Never turn off the front-panel switch inadvertently in this mode. The system requires a minimum number of active supplies to operate safely.

Critical Compatibility Warning for Procurement

Do not mix the IC695PSD140 with the IC695PSD040 or IC695PSA040 modules. These models are incompatible in redundant or increased capacity modes. Using them together can cause damage to both types of equipment. Always verify your existing backplane configuration before ordering. This module occupies two slots in the RX3i universal chassis.

Key Technical Specifications for Selection

The module has a nominal rated voltage of 24 VDC. It supports a ride-through time of 20 ms for power interruptions. The output ripple and noise are both rated at 150 mV. Use wire sizes from 14 to 22 AWG for terminal connections. Each input terminal can handle a maximum current of 6 Amperes.

Logistics & Standard Packaging Details

• One GE Fanuc IC695PSD140 power supply module
• User manual and installation guide
• Terminal block connectors for field wiring
• Anti-static packaging for safe transit
• Express delivery shipping is available via FedEx, UPS, and DHL
