Product Summary

The IC695CRH003 harness assembly bridges Series 90-70 and RX3i PacSystems modules. This GE Fanuc component connects the IC697MDL250 to the IC694MDL260 device. It supports 120 Volts AC input modules with 32 total points. Engineers use this harness for reliable signal transmission in automation systems.

Expert Technical Evaluation & Performance Review

The IC695CRH003 assembly meets VME Standard C.1 for industrial use. This harness connects the IC697MDL250 module that provides 32 input points. The system divides those points into 4 isolated groups. Each group contains 8 input points for separate AC phases.

The IC697MDL250 module uses reactive inputs that comply with IEC standards. These inputs work with a wide range of proximity switches easily. LED indicators show the on or off status for every input point clearly. The module consumes 0.35 Amps at 5 Volts DC during operation.

The IC694MDL260 module features isolated input groups for enhanced safety. All circuits within the same group share a common user connection point. Engineers can configure input filter times through a standard programmer device. The system requires 220 milliamps at 5 Volts DC when all inputs activate.

The off-state voltage range spans from 0 to 20 Volts AC safely. The on-state current reaches a minimum of 5 milliamps for reliable detection. The off-state current stays at a maximum of 2.5 milliamps to prevent false signals.

Step-by-Step User & Installation Guide

First verify that your system power is completely disconnected before installation. Mount the IC697MDL250 module securely into the Series 90-70 rack slot. Connect the IC695CRH003 harness between the MDL250 and MDL260 modules properly.

Ensure each of the 4 input groups connects to a separate AC phase. Wire each group's 8 input points according to your application requirements. Verify that all connections meet the 120 Volts AC rating specifications exactly.

Configure the input filter times using your programmer after installation completes. Set the filter values to match your specific industrial application needs precisely. Test each input point using the LED indicators for status verification.

Monitor the power consumption to stay within the 0.35 Amp limit at 5 Volts. Check that the off-state voltage stays between 0 and 20 Volts AC always. Confirm the on-state current exceeds 5 milliamps for reliable operation.

Logistics & Standard Packaging Details

• One GE Fanuc IC695CRH003 harness assembly unit
• Product documentation and installation reference guide
• Anti-static packaging for safe transportation and storage

We ship all orders using express delivery services for fast arrival. Choose FedEx, UPS, or DHL for your shipping method at checkout. Contact our team for bulk order pricing and availability information.
