The T9110 serves as the central processing unit for the AADvance safety controller platform, executing critical control and safety logic.

It delivers scalable fault tolerance, supporting SIL 3 safety integrity for high-demand process applications.

Its robust architecture ensures uninterrupted operation in emergency shutdown (ESD), burner management, and pipeline protection systems.

The module enables seamless integration with a full range of AADvance I/O and communication modules, building a comprehensive safety ecosystem.

Technical Insights

1. Flexible Redundant Architecture & SIL Compliance

• 1 Processor (Simplex): For non-safety or up to SIL 1 applications.
• 2 Processors (Dual Redundant): Certified for SIL 3 safety applications.
• 3 Processors (TMR): Delivers SIL 3 fault tolerance with 2-out-of-3 voting, eliminating single points of failure.
• Built to IEC 61508 standards, ensuring compliance for global hazardous installations.

2. High-Performance Processing & Memory

• 400 MHz processor for fast logic execution and deterministic scan times.
• Internal memory configuration:
  • Boot Flash: 512 kB
  • SRAM: 512 kB
  • Bulk Flash: 64 MB (for application logic)
  • SDRAM: 32 MB (for internal variables)
• 1 ms time-stamping resolution for Sequence of Events (SOE) logging.
• Supports up to 48 I/O modules for extensive system configuration.

3. Communication & Power Features

• Dual Redundant 24 VDC power input (18–32 VDC range) with internal under/over-voltage protection.
• Two Ethernet ports and two serial ports (RS485) per module for system networking.
• Supports standard protocols: MODBUS, HART, OPC, and secure SIL 3 “Black Channel” communication.
• Galvanic isolation from field power and data circuits prevents fault propagation.
• Hot-swappable design allows replacement during online operation without process shutdown.

Installation & Maintenance

1. Mechanical Installation

• Mounts in standard AADvance chassis (T9100 base unit).
• Dimensions: 166 × 42 × 118 mm (6.5 × 1.65 × 4.65 in).
• Weight: 430 g (15 oz).
• Non-flammable plastic casing; requires vertical orientation for cooling.
• Secure backplane connection ensures reliable power and communication.

2. Environmental Specifications

• Operating Temperature: -25°C to +60°C (-13°F to +140°F).
• Power dissipation: 8 W (27.3 BTU/h).
• Designed for Pollution Degree 2 environments per IEC 60664-1.
• Suitable for ATEX/IECEx certified hazardous area enclosures.

3. Routine Maintenance

• Monitor front-panel LED indicators for real-time status (run, fault, communication).
• Automatic self-test diagnostics and watchdog circuit continuously monitor health.
• Quarterly inspection of terminals for tightness, corrosion, and thermal damage.
• Annual battery replacement for the Real-Time Clock (RTC) and memory backup.

Buyer’s Guide

Q1: What is the primary difference between T9110 and other Trusted/TMR processors?

Q2: Is a backup battery required for operation?

Q3: Can the T9110 communicate with non-AADvance systems?
