Siemens 6AR1302-0AC00-0AA0 I/O Communications Module Subrack
Introduction:
This Siemens 6AR1302-0AC00-0AA0 is an I/O communications subrack for up to 2 modules. 24 V DC input, -20°C to 60°C range.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The Siemens 6AR1302-0AC00-0AA0 functions as an I/O communications module subrack. This unit houses up to two I/O modules within its compact design. Operation remains reliable across a temperature range of -20°C to 60°C. Therefore, this subrack adapts to various industrial environments. A 24 V DC input powers the entire assembly. The integrated DC/DC transformer simplifies power supply requirements for connected modules. Metal housing provides robust physical protection for internal components. An IP20 protection rating allows safe usage in indoor environments. Dust and foreign particle exposure remains minimal with this rating. The 6AR1302-0AC00-0AA0 supports passive cooling for optimal temperature management. Consequently, no additional cooling infrastructure is necessary for normal operation.
Technical Specifications
General Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Siemens |
| Part Number | 6AR1302-0AC00-0AA0 |
| Product Type | I/O Communications Module |
| Product Line | I/O Modules |
| UPC | 662643026061 |
| Subrack Type | For up to 2 I/O modules |
| Operating Temperature Range | -20°C to 60°C |
| Protection Class | IP20 |
| Material | Metal Housing |
| Input Voltage | 24 V DC |
| Mounting Type | Panel Mount |
| Cooling Type | Passive cooling |
| Bus Type | Supports I/O communication modules |
| DC/DC Transformer | Integrated |
Physical Specifications
| Parameter | Value |
|---|---|
| Weight (module only) | 0.09 kg |
| Weight (shipping approximate) | 0.12 kg |
Subrack Capacity & Module Compatibility
The 6AR1302-0AC00-0AA0 serves as a subrack for two I/O modules. Each slot accommodates compatible Siemens I/O communication modules. The subrack provides mechanical support and electrical connections for both modules. Bus type support ensures proper communication between modules and the control system. For system expansion, this subrack allows adding two modules in minimal space. The Siemens 6AR1302-0AC00-0AA0 simplifies modular I/O system design.
Integrated DC/DC Transformer
An integrated DC/DC transformer comes built into this subrack. This transformer converts and distributes power to the installed I/O modules. External power supply design becomes significantly simpler as a result. The transformer eliminates the need for separate power conditioning components. For system integrators, this integration reduces both parts count and installation time. The 6AR1302-0AC00-0AA0 accepts 24 V DC input and provides appropriate voltages to connected modules.
Temperature Range & Environmental Adaptability
Operating temperature spans -20°C to 60°C for the 6AR1302-0AC00-0AA0. This wide range suits both cold and warm industrial environments. For unheated warehouses or outdoor enclosures, the low-end tolerance proves valuable. For machine cabinets near hot processes, the high-end tolerance provides adequate margin. Passive cooling maintains optimal operating temperatures without fans. Therefore, the subrack operates silently and reliably without moving parts. The Siemens 6AR1302-0AC00-0AA0 adapts to diverse installation locations.
Metal Housing & IP20 Protection
The 6AR1302-0AC00-0AA0 uses a durable metal housing for physical protection. This housing resists impact, vibration, and electromagnetic interference. IP20 protection class prevents ingress of fingers and large particles. Small dust particles may enter but do not affect functionality. For indoor control cabinets and panels, IP20 provides adequate protection. The metal construction also aids heat dissipation for passive cooling. Consequently, the Siemens 6AR1302-0AC00-0AA0 suits standard industrial electrical enclosures.
Panel Mounting & Installation
Panel mounting is the specified installation method for this subrack. The lightweight design (0.09 kg) simplifies handling during installation. Four mounting points secure the subrack to a panel or backplate. The compact footprint occupies minimal panel space for two I/O modules. For system integrators, this density saves valuable cabinet real estate. The 6AR1302-0AC00-0AA0 mounts quickly with standard tools.
Communication Bus Support
The subrack supports I/O communication modules via an internal bus. This bus carries data between modules and the host controller. Reliable communication ensures proper I/O data transfer for control applications. The bus type is specifically designed for Siemens I/O communication modules. For mixed I/O configurations, the Siemens 6AR1302-0AC00-0AA0 handles various module types.
Passive Cooling Design
Passive cooling eliminates the need for cooling fans in this subrack. Natural convection dissipates heat from the integrated transformer and modules. No moving parts means no fan noise or bearing wear. Reliability improves because passive systems have fewer failure points. For maintenance-free operation, passive cooling proves advantageous. The 6AR1302-0AC00-0AA0 maintains safe temperatures through careful thermal design.
Installation Guidelines
Follow these steps for proper installation of the 6AR1302-0AC00-0AA0.
Select a suitable panel location with adequate clearance for wiring.
Mount the subrack using four screws through the panel mounting holes.
Connect 24 V DC power to the input terminals. Observe correct polarity.
Verify the DC/DC transformer provides correct output voltages before inserting modules.
Insert up to two I/O modules into the subrack slots. Ensure proper seating.
Secure the modules using any provided retaining clips or screws.
Connect field wiring to the installed I/O modules per their specifications.
Power up the system and verify communication with the host controller.
Note: The 6AR1302-0AC00-0AA0 requires a 24 V DC power supply rated for the total load of both installed modules. Do not exceed the subrack's current rating. IP20 protection requires installation in an enclosure providing additional environmental protection.
