Evolution of Compact Control in Industrial Automation

Industrial automation has evolved from simple relay logic to sophisticated programmable logic controllers that manage entire production lines. Today's facilities demand controllers that balance processing power, communication flexibility, and physical footprint. The Schneider Electric TSXP572623M addresses these needs as part of the TSX Micro PLC series, offering a compact solution for a wide range of automation tasks.

Introducing the TSXP572623M from Schneider Electric

The TSXP572623M is a double-format PL7 processor from Schneider Electric's Modicon Premium Automation platform. It is designed to handle up to 30 simple process control loops, making it suitable for applications that require precise loop control without the complexity of a larger PAC. The processor includes a RESET button that initiates a cold start, ensuring a clean state when needed.

Technical Specifications and Performance

Key specifications of the TSXP572623M include:

• Discrete I/O processor capacity: 1024 I/O
• Analogue I/O processor capacity: 80 I/O
• Execution time: 0.19 µs for Boolean instructions without PCMCIA card; 0.21 µs with PCMCIA card
• Internal RAM: 48 Kwords for program and data (without PCMCIA card)
• Memory expansion via PCMCIA card: 160 Kwords program, 2688 Kwords data
• Supports up to 16 racks
• Integrated connections: Non-isolated serial link (2 female mini DIN, 19.2 kbit/s) and Ethernet TCP/IP (RJ45, 10/100 Mbit/s)
• Communication modules: 1 fieldbus module (none if CANopen used), 4 AS-Interface bus modules, 1 CANopen
• Application structure: 1 master task, 1 fast task, 64 event tasks
• Current consumption: 1110 mA at 5 V DC
• Operating temperature: 32…140 °F (0…60 °C)
• Storage temperature: -13…158 °F (-25…70 °C)
• Relative humidity: 10…95% without condensation (operation), 5…95% without condensation (storage)
• Operating altitude: 0...6561.68 ft (0...2000 m)
• IP degree of protection: IP20
• Pollution degree: 2

These specifications make the TSXP572623M a robust choice for environments that demand reliable performance under varying conditions.

Applications in Oil & Gas and Process Industries

In oil and gas facilities, the TSXP572623M can manage process control loops for temperature, pressure, and flow. Its ability to handle up to 30 simple loops makes it ideal for skid-mounted systems, wellhead control panels, and small pipeline monitoring stations. The Ethernet TCP/IP connectivity allows seamless integration with SCADA systems, enabling remote monitoring and data acquisition.

Beyond oil and gas, the processor is well-suited for water treatment plants, food and beverage processing, and packaging lines where discrete and analog I/O are required. The support for up to 16 racks provides scalability for expanding systems.

Customer Scenario: Upgrading a Legacy Control System

Consider a mid-sized chemical plant that currently uses older relay-based controls. By upgrading to the TSXP572623M, the plant can consolidate multiple control functions into a single PLC, reducing wiring complexity and improving diagnostic capabilities. The PCMCIA memory expansion allows for larger programs, while the fast execution time (0.19 µs per Boolean instruction) ensures responsive control.

Compatibility and Integration

The TSXP572623M is designed to work within the Modicon Premium Automation platform. It supports up to 16 racks with 4/6/8 or 12 slots, providing flexibility in I/O configuration. The integrated Ethernet TCP/IP port (RJ45, 10/100 Mbit/s) enables easy connection to plant networks, while the non-isolated serial link (2 female mini DIN, 19.2 kbit/s) allows for legacy device communication. The two PCMCIA slots accept memory extension cards or communication cards, including a 4 MB SRAM memory extension card.

Market Impact and Business Value

Investing in the TSXP572623M can lead to significant operational benefits. Its high-speed processing reduces cycle times, potentially increasing throughput. The ability to handle 1024 discrete I/O points and 80 analog I/O points means fewer controllers are needed, lowering hardware and maintenance costs. The wide operating temperature range (0 to 60 °C) ensures reliable operation in harsh industrial environments, reducing unplanned downtime.

Frequently Asked Questions

What is the maximum number of process control loops the TSXP572623M can handle?

The TSXP572623M can handle up to 30 simple process control loops, as indicated in its specifications.

What are the memory options for the TSXP572623M?

The internal RAM is 48 Kwords for program and data without a PCMCIA card. With a PCMCIA card, you can expand to 160 Kwords for program and 2688 Kwords for additional data storage.

What communication interfaces are available on the TSXP572623M?

The processor includes a non-isolated serial link (2 female mini DIN, 19.2 kbit/s) and Ethernet TCP/IP (RJ45, 10/100 Mbit/s). It also supports communication modules such as 1 fieldbus module (none if CANopen used), 4 AS-Interface bus modules, and 1 CANopen.

What is the operating temperature range for the TSXP572623M?

The operating ambient air temperature range is 32…140 °F (0…60 °C).

How many racks can the TSXP572623M support?

The TSXP572623M supports up to 16 racks, with options for 4/6/8 or 12 slots per rack.

Conclusion and Outlook

The Schneider Electric TSXP572623M offers a balanced combination of processing power, memory, and communication capabilities for modern industrial automation. Its scalability and robust design make it a valuable asset for oil and gas operations seeking to modernize their control systems. As industries continue to embrace digital transformation, controllers like the TSXP572623M will play a key role in bridging legacy processes with future-ready technology.
