Product Overview

The Woodward 5464-843 belongs to the MicroNet Digital Control family. This NetCon 5000 CPU module operates as a smart I/O device. The 5464-843 has its own on-board microcontroller for intelligent processing. During initialization, the module runs power-on self-tests automatically. The CPU tells this module which rate group each channel must run. The 5464-843 then broadcasts a key to all I/O cards for rate group updates.

Technical Specifications

The Woodward 5464-843 delivers intelligent I/O processing for MicroNet systems. All parameters follow the official datasheet.

General Information

• Manufacturer: Woodward

• Model: 5464-843

• Catalog: MicroNet Digital Control

• Description: NetCon 5000 CPU Module

• Origin: United States (US)

• HS Code: 85389091

Physical Specifications

• Dimensions: 16 cm x 16 cm x 12 cm

• Weight: 0.8 kg

Smart I/O Features

• On-board microcontroller for local processing

• On-card online fault detection capability

• Automatic calibration and compensation functions

• Each input channel has a dedicated precision voltage reference

• Reference reading occurs once per minute while not reading inputs

• Voltage reference readings enable temperature compensation

Fault Detection

• Limits set for expected voltage reference readings

• Reading outside limits indicates channel, A/D, or reference failure

• Microcontroller flags the channel with a fault condition

• CPU executes application engineer programmed actions

• Visible fuse accessible through cutout in plastic cover

Rate Group Scheduling

• CPU tells module which rate group each channel runs

• Periodic broadcast of key to all I/O cards

• Each I/O module handles its own scheduling

• Minimal CPU intervention required

Actuator Driver Capabilities

• Two-channel actuator controller module available

• Controls integrating or proportional actuators

• Supports hydromechanical or pneumatic actuators

• Up to two position feedback devices per actuator

• Maximum output current indicated by part number

• Requires MicroNet low-density discrete (gray) cable

• Do not use analog (black) cable with this module

Installation Guide

Follow these steps to install the Woodward 5464-843 correctly.

1. Power down the MicroNet chassis before inserting the module.

2. Align the 5464-843 with the correct VME-bus slot.

3. Slide the module firmly into place until connectors engage.

4. Use MicroNet low-density discrete (gray) cable for connections.

5. Do not use analog (black) cable with the 5464-843.

6. Verify power-on self-tests pass and LED turns off.

7. Check for I/O fault indication if LED remains illuminated.

Packing List

This package for the Woodward 5464-843 includes the following items.

• Woodward 5464-843 NetCon 5000 CPU module (one unit)

• Product documentation and manual references

• Anti-static protective bag

• Basic installation instruction leaflet

Frequently Asked Questions (FAQ)

1. What is the weight of the Woodward 5464-843 module?
The 5464-843 weighs 0.8 kg. The dimensions are 16 cm by 16 cm by 12 cm for easy panel integration.

2. Where is the Woodward 5464-843 manufactured?
The 5464-843 is manufactured in the United States (US). This ensures quality control and reliable performance.

3. What type of cable should I use with the Woodward 5464-843?
Use a MicroNet low-density discrete (gray) cable with the 5464-843. Do not use an analog (black) cable for this module.

4. Does the 5464-843 have onboard fault detection?
Yes, the 5464-843 has on-card online fault detection. Each input channel has a precision voltage reference for automatic calibration and compensation.

5. What does the LED indicate on the Woodward 5464-843?
The LED turns off after power-on self-tests pass and CPU initializes the module. An illuminated LED on the 5464-843 indicates an I/O fault condition.
