Product Overview

The Woodward 5441-693 is a discrete I/O module developed for PLC systems.
This module is specifically classified as a relay module for circuit control.
It offers a total of 13 relay circuits within a single module.
Consequently, multiple control and switching functionalities are available.
Seamless integration with PLC systems makes the 5441-693 highly versatile.
Relays provide reliable and precise control over electrical circuits.
They manage high-power equipment while maintaining safe operation.
Therefore, this module suits industries where precision and safety are paramount.

Technical Specifications

Input Characteristics

Part number 5441-693 includes 24 optically isolated discrete input channels .
Input type is optically isolated for protection against electrical noise.
Update time equals 5 ms for fast response to input changes.
Time stamping resolution reaches 1 ms for precise event sequencing.
Isolated 24 Vdc contact supply provides 400 mA maximum current.
The Woodward 5441-693 also detects on/off and high/low states from field devices.

Output Characteristics

The module features 13 relay circuits for output control.
These circuits act as switches for various electrical loads.
Each relay can be turned on or off based on PLC control signals.
The ample number of relay circuits allows multifaceted control.
Consequently, the 5441-693 streamlines complex automation processes.

Physical and Environmental

Country of manufacture is the United States (USA) .
The module inserts into card guides within the control chassis.
Connection to the motherboard occurs through backplane connectors.
Two screws (top and bottom) hold the module securely in place.
Two handles (top and bottom) assist with module removal.
When toggled outward, these handles disengage the motherboard connectors.
Repair time is typically 3-7 days for fast turnaround.
Availability status is In Stock for immediate shipment.

Interface and Communication

The Woodward 5441-693 features a single interface port for connectivity.
This port serves as the connection point between module and PLC system.
Through this interface, the module communicates with the PLC effectively.
Control signals are received and status information is transmitted.
Common communication protocols like Modbus are typically supported.
Profibus, Ethernet/IP, and other protocols may also work.
Therefore, seamless integration with PLCs or DCSs is achievable.

Key Features

13 Relay Circuits

A standout feature is the impressive array of 13 relay circuits.
These circuits serve as the lifeblood of the 5441-693 module.
They enable orchestration of complex control and switching tasks.
Each relay provides reliable switching for industrial loads.

Optical Isolation

All 24 input channels use optical isolation for protection.
This isolation prevents ground loops and electrical noise interference.
It also protects the PLC system from field wiring faults.
Consequently, the Woodward 5441-693 operates reliably in noisy environments.

Time Stamping

Time stamping with 1 ms resolution captures precise event times.
This feature is critical for sequence of events recording.
Troubleshooting becomes easier with accurate time-stamped data.

Fast Update Rate

The 5 ms update time ensures responsive control performance.
Input changes are detected and reported quickly to the PLC.
Output relays respond rapidly to PLC commands.

Advanced Capabilities

The Woodward 5441-693 supports redundancy features in advanced systems.
Backup channels can be configured for critical applications.
Module-level redundancy ensures uninterrupted operation during failures.
This module provides a large number of I/O channels in a compact form factor.
Consequently, efficient use of panel space is achieved.

Installation Guidelines

First, power down the control system completely before installation.
Insert the Woodward 5441-693 into the card guides carefully.
Push the module firmly until the motherboard connectors engage.
Secure the module using the top and bottom mounting screws.
Connect field wiring to the 24 optically isolated input terminals.
Connect output devices to the 13 relay circuit terminals.
For relay outputs, observe the maximum current ratings.
Use appropriate suppression for inductive loads on relays.
Verify the 24 Vdc contact supply provides 400 mA maximum.
After installation, power up and verify module communication.

Wiring Recommendations

Use copper cables with 0.5 to 1.5 mm² cross section for inputs.
For relay outputs, use cable rated for the connected load current.
Keep input wiring separate from high-power AC cables.
Use shielded cables for long input runs in noisy environments.
Label each of the 24 input channels clearly for identification.
Label all 13 relay output circuits according to your drawing.

Package Contents

• 1 x Woodward 5441-693 field terminal module

• 2 x Mounting screws (top and bottom)

• 1 x Terminal connector kit for inputs and outputs

• 1 x Installation and configuration manual

• 1 x Product datasheet with wiring diagrams

Frequently Asked Questions (FAQ)

1. Can the 5441-693 be used as a standalone controller?

No, the Woodward 5441-693 requires a PLC or DCS system. It functions as a remote I/O module, not a standalone controller.

2. What is the maximum switching frequency for the relays?

The 5441-693 relay circuits are for general purpose control. For high-speed switching, consult the Woodward technical manual for specific ratings.

3. Are the input channels compatible with AC voltages?

No, the Woodward 5441-693 inputs are for 24 Vdc only. AC inputs require an external conversion or a different module.

4. How do I know which communication protocol to use?

Check your PLC system's compatibility first. The 5441-693 typically supports Modbus, Profibus, and Ethernet/IP.

5. Can I replace a faulty relay on this module?

Individual relays are not field-replaceable on the Woodward 5441-693 . The entire module must be replaced or sent for factory repair.
