IC754VSB06CTD 6-Inch Color TFT HMI with Windows CE.NET
This IC754VSB06CTD device provides an efficient interface for machinery monitoring. The IC754VSB06CTD belongs to the GE Fanuc QuickPanel View series. It runs on Microsoft Windows CE.NET embedded operating system. This OS offers a runtime environment for user programs. The interface design makes learning and operation easy for operators.

Technical Specifications
The IC754VSB06CTD features a 6.0-inch full color TFT display. Screen resolution reaches 320 x 240 pixels. Display brightness measures 300 NITS for clear visibility. Input type uses an analog resistive touchscreen for parameter entry. The display uses a CCFL backlight with 50,000 hours rated half-life. Please note that the backlight is not field-replaceable.

Processor and Memory:

Processor: Intel XScale PXA25

Clock Speed: 200 MHz

RAM: 16 MB (pre-installed)

Flash Memory: 16 MB (pre-installed)

Communication Ports:

Ethernet: Dual 10/100 Base-T ports (LAN1 and LAN2)

Serial: One RS-232 port

Serial Baud Rate: 300 to 15200 bits per second (programmable)

Clock and Battery:

Internal Clock/Calendar: 1-second resolution

Clock Accuracy: ±2 to 3 minutes per month

Battery Type: Lithium battery assembly

Battery Lifespan: Up to 5 years

Power Specifications:

Input Voltage: 12 to 30 VDC

Power Consumption: 9 Watts (net)

Environmental Ratings:

Enclosure Rating: NEMA 4, 4X, 12

Operating Temperature: -10 to 60 °C (14 to 140 °F)

Operating Humidity: 10% to 80% non-condensing

Storage Temperature: -20 to 70 °C (-4 to 158 °F)

Physical Dimensions:

Maximum Mounting Size: 126.0 x 156.0 x 515.5 mm (H x W x D)

Average Weight: 1.16 kg

Certifications:

UL

c-UL

ATEX

CE

The IC754VSB06CTD offers dual Ethernet ports for network redundancy. One port can serve as LAN1 while the other serves as LAN2. The serial port supports programmable baud rates from 300 to 15200 bps. The internal clock keeps accurate time with battery backup. The lithium battery lasts up to 5 years under normal use. Use the recommended HMI-CAB-CS1 communication cable for serial connections.

Installation Guide
Follow these steps to install the IC754VSB06CTD properly. Prepare a panel cutout according to the mounting dimensions. Maximum mounting size is 126.0 x 156.0 x 515.5 millimeters. Insert the unit into the panel opening from the front. Secure the unit using the provided mounting hardware. Connect 12 to 30 VDC power to the input terminals. The unit consumes only 9 Watts during operation. Attach your controller using the RS-232 serial port. Use the HMI-CAB-CS1 communication cable for best results. Connect Ethernet cables to LAN1 and LAN2 for network access. Configure the serial baud rate between 300 and 15200 bps as needed. Power on the unit and wait for Windows CE.NET to load. Calibrate the analog resistive touchscreen through the system menu. Verify the internal clock shows the correct time and date.

What's in the Box
Please check the package contents upon delivery.

IC754VSB06CTD HMI unit (1 unit)

Panel mounting gasket (1 piece)

Mounting clips with screws (1 set)

DC power connector plug (1 piece)

Quick start guide (1 booklet)

Common FAQs
1. What operating system does the IC754VSB06CTD use?
This unit runs on Microsoft Windows CE.NET embedded operating system. The OS provides a runtime environment for developing and running user programs.

2. Does this HMI have dual Ethernet ports?
Yes, the IC754VSB06CTD features two 10/100 Base-T Ethernet ports. These are labeled LAN1 and LAN2 for network redundancy or separate networks.

3. What is the backlight lifespan on this display?
The CCFL backlight has a rated half-life of 50,000 hours. Please note that the backlight is not field-replaceable.

4. How long does the internal battery last?
The lithium battery assembly lasts up to 5 years. This battery backs up the internal clock and calendar. Replace the battery when clock accuracy declines.

5. What enclosure ratings does the IC754VSB06CTD have?
This unit has NEMA 4, 4X, and 12 industrial enclosure ratings. It also holds UL, c-UL, ATEX, and CE certifications for global use.
