Introduction:
FBM230 Modbus Master (Serial and TCP/IP) Driver by Schneider for Foxboro systems. Supports RS-232, RS-422, RS-485, and up to 64 devices.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
Product Overview
The FBM230 is a Modbus Master (Serial and TCP/IP) Driver from Foxboro by Schneider Electric. It provides flexible connectivity for industrial automation systems, supporting multiple serial protocols and Ethernet-based Modbus/TCP communication. This field-mounted module integrates field device data into a Foxboro control database, making it a reliable choice for harsh environments rated Class G3.
Technical Specifications Analysis
The FBM230 operates on a 24 V dc input voltage range with +5% and -10% tolerance, consuming a maximum of 7 W. It dissipates up to 7 W of heat. The module supports operating temperatures from -20 to +70°C and storage temperatures from -40 to +70°C, with relative humidity from 5 to 95% noncondensing. It is suitable for Class G3 (harsh) environments per ISA Standard S71.04. The module measures 102 mm in height (114 mm including mounting lugs), 45 mm in width, and 104 mm in depth.
Application Scenarios & Usage Methods
This driver connects up to 64 RS-485 devices or up to 4 direct connect RS-232 or RS-422 devices. Use it to integrate PLCs, flow meters, or analyzers into a Foxboro DCS. Configure each of the four ports individually in software for RS-232, RS-422, or RS-485. For RS-485, use twisted-pair shielded copper cable. For RS-232, use a DB-25 cable to a device or modem. The FBM230 supports Modbus RTU, Modbus ASCII, and Modbus/TCP protocols, with data in big endian or little endian format.
Installation Guide & Packing List
Mount the FBM230 in a field location using the provided mounting lugs. Connect the termination assembly (TA) per EIA standards for RS-232, RS-422, or RS-485. Ensure intrinsic safety devices are placed between the TA and field devices if required. The package typically includes the FBM230 module, mounting hardware, and documentation. Always follow Schneider Foxboro installation manuals for wiring and configuration.
Purchasing Advice
When selecting the FBM230, confirm your system requires Modbus Master functionality with four configurable serial ports. Verify the 24 V dc power supply meets the input voltage range. For harsh environments, the Class G3 rating ensures reliable operation. PetroPartsOnline offers this genuine Schneider Foxboro module with fast shipping and expert support.
Repair & Maintenance Tips
Regularly inspect the FBM230 for dust or moisture, especially in Class G3 environments. Clean with a dry cloth; avoid solvents. Store between -40 and +70°C with 5 to 95% noncondensing humidity. Check cable connections for corrosion or looseness. Replace the module if communication errors persist after verifying configuration.
