Product Overview

The Bently Nevada 9200-01-05-10-00 is a rugged two-wire velocity seismoprobe transducer. This device measures absolute casing vibration on industrial machinery. It works perfectly for compressors, turbines, and pumps. The 9200-01-05-10-00 uses a terminal block top mount instead of an integral cable. Engineers choose this version for custom wiring installations.

Key Technical Specifications

The Bently Nevada 9200-01-05-10-00 delivers precise vibration data. Below are the core technical parameters.

Sensitivity and Range

• Sensitivity: 20 mV/mm/s (500 mV/in/s) ±5% at calibration angle

• Velocity Range: 25 mm/s (1 in/s) at +22°C with 10 kΩ load

• Dynamic Operating Range: 2.54 mm (0.100 in) peak-to-peak max displacement

• Frequency Response: 0 ±2.5, 4.5 Hz (270 cpm) minimum

Electrical Characteristics

• Coil Resistance: 1.25 kΩ ±5% between terminals A and B

• Locked Coil Inductance: 125 mH typical

• Temperature Coefficient of Sensitivity: 0.2% per °C

• Calibration Load: 10 kΩ across terminals A and B

Mechanical Specifications

• Connector Option: 05 – Terminal block top mount (no cable)

• Mounting Base Option: 10 – Circular with M10x1 stud

• Mounting Angle Option: 01 – 0° ±2.5° at 4.5 Hz (270 cpm)

• Case Material: Anodized aluminum A204

• Gasket Material: Neoprene

• Height: 102 mm (4 in) typical

• Diameter: 41 mm (1.6 in) typical

• Weight: 300 grams (10.5 ounces) typical

Environmental Specifications

• Operating Temperature: -29°C to +121°C (-20°F to +250°F)

• Storage Temperature: -29°C to +121°C (-20°F to +250°F)

• Relative Humidity: Up to 95% non-condensing

• Environmental Protection: Dust and moisture resistant

• Agency Approval Option: 00 – No approvals required

The Bently Nevada 9200-01-05-10-00 handles harsh industrial conditions. Its anodized aluminum case resists corrosion effectively.

Terminal Block Design Advantage

This 9200-01-05-10-00 model features a top-mounted terminal block. This design offers several practical benefits for field installations.

• No integral cable means you choose your own cable type and length

• Easy field wiring using standard screw terminals

• Simplified replacement without pulling old cables through conduit

• Lower cost when you already have installed wiring in place

• Flexible routing for custom cable pathways

The terminal block accepts wires up to 16 AWG. Use shielded twisted-pair cable for best noise immunity. Keep the total cable length under 305 meters (1000 feet) for accurate signals.

Installation Guide

Follow these steps to install the 9200-01-05-10-00 correctly.

1. Prepare Mounting Surface: Clean the machine casing surface thoroughly. Remove any dirt, oil, or old gasket material.

2. Install Mounting Base: Screw the M10x1 stud into a threaded hole on the machine. Tighten to 10-15 Nm torque.

3. Attach Transducer: Screw the Bently Nevada 9200-01-05-10-00 onto the M10x1 stud. Hand tighten plus one quarter turn.

4. Wire the Terminal Block: Connect two wires to terminals A and B. Use a 10 kΩ load resistor at the monitor end.

5. Route the Cable: Run shielded cable away from high voltage lines. Ground the shield only at the monitor end.

6. Verify Operation: Measure coil resistance across terminals A and B. Expect 1.25 kΩ ±5% at room temperature.

Do not overtighten the transducer on the stud. The 9200-01-05-10-00 requires proper orientation at the calibrated angle of 0° ±2.5°.

Package Contents

The box includes the following items for the Bently Nevada 9200-01-05-10-00.

• One Bently Nevada 9200 Two-Wire Velocity Seismoprobe Transducer (terminal block top mount)

• One circular mounting base (M10x1 stud, pre-installed)

• One neoprene gasket (installed between base and case)

• One terminal block cover (protective plastic cap)

• Two terminal screws (spare set included)

• One installation datasheet (wiring diagram and torque specs)

Note: This package does not include field wiring cable, the 10 kΩ load resistor, or mounting tools. You need to provide these separately.

Common FAQs

1. Why choose the 9200-01-05-10-00 over the version with an integral cable?
This Bently Nevada model uses a terminal block instead of a fixed cable. You can use your own cable type and length. Replacement costs are lower because you keep existing wiring.

2. What cable should I use with this 9200 transducer?
Use a shielded twisted-pair cable, 18 to 22 AWG. Belden 8760 or equivalent works well. Keep the total resistance below 50 ohms per conductor.

3. How do I test the 9200-01-05-10-00 before installation?
Measure resistance between terminal A and terminal B. A good unit shows 1.25 kΩ ±5%. Then shake the transducer gently and watch for an AC voltage output.

4. Can this CEV58M model work in high humidity areas?
Yes, the 9200-01-05-10-00 handles up to 95% relative humidity non-condensing. The sealed terminal block adds extra moisture protection.

5. What happens if I mount the transducer at the wrong angle?
Sensitivity changes by approximately 5% per 10 degrees of misalignment. The 9200-01-05-10-00 needs 0° ±2.5° orientation for rated accuracy.

Typical Applications

The Bently Nevada 9200-01-05-10-00 serves many rotating machinery monitoring applications.

• Steam turbines – casing vibration on bearing housings

• Gas turbines – high temperature areas up to 121°C

• Centrifugal compressors – constant speed machines

• Large industrial fans – slow speed monitoring at 270 cpm

• Cooling tower drives – outdoor dust and moisture exposure

• Pumps and blowers – general purpose vibration protection

This transducer connects directly to Bently Nevada monitors like the 1900/65 or 3500 series. It also works with third-party 4-20 mA vibration transmitters.

Compliance and Quality

The Bently Nevada 9200-01-05-10-00 comes with factory calibration at 100 Hz with a 10 kΩ load. Each unit receives a sensitivity test across its full temperature range. The anodized aluminum case meets NEMA 12 standards for dust and drip resistance. This model has agency approval option 00, meaning no ATEX, CSA, or IECEx certifications. Use it only in non-hazardous locations.

Ordering Reference

Use the full part number 9200-01-05-10-00 when placing your order. This guarantees the terminal block top mount, M10x1 stud base, and no cable. Stock is new and original in factory packing.
