Product Overview for the 10313/1/1 Distribution Module

The 10313/1/1 is a 5V DC and watchdog (WD) distribution module for the FSC system. Firstly, this module distributes stable 5V DC power to connected I/O backplanes. In addition, it also distributes critical watchdog signals throughout the system. Specifically, the 10313/1/1 serves as a central power hub for both redundant and non-redundant configurations. Consequently, it ensures reliable operation of all connected I/O modules. Moreover, this distribution module simplifies cabinet wiring by consolidating power connections. Therefore, the 10313/1/1 is essential for any FSC-based safety control system.

Key Features and Functions

Redundant I/O Backplane Connections
The 10313/1/1 provides ten connectors labeled RCN-1 to RCN-10. Firstly, these connectors are specifically for redundant I/O backplanes (model 10315/1/1). Consequently, you can connect up to ten redundant backplanes to a single distribution module.

Non-Redundant I/O Backplane Connections
In addition, the 10313/1/1 includes ten connectors labeled SCN-1 to SCN-10. Specifically, these connectors work with non-redundant I/O backplanes (model 10314/1/1). As a result, one 10313/1/1 module supports both types of backplanes simultaneously.

Power Input Faston Terminals
The module features dedicated faston terminals for incoming 5V DC power. Firstly, 'FSC101 or FSC102' fastons supply non-redundant I/O backplanes. In addition, 'FSC101R CP-1' and 'FSC101R CP-2' fastons power redundant I/O backplanes. Therefore, the 10313/1/1 maintains separate power paths for each backplane type.

Watchdog Connectivity
Furthermore, the 10313/1/1 includes connectors for directly attaching watchdog repeaters (WDRs). In addition, it has connectors for the 10005/O/2 WD horizontal buses. Consequently, watchdog signals propagate reliably throughout the entire FSC system.

Cabinet Expansion Capability
The 10313/1/1 also provides connectors for linking an additional module. Specifically, this allows another 10313/1/1 in a separate cabinet. As a result, you can expand your FSC system across multiple cabinets easily.

Technical Specifications of the 10313/1/1

General Specifications

• Type Number: 10313/1/1 (207011 suffix code available).

• Approvals: Holds CE and TÜV safety certifications.

• UL Approval: Currently pending for North American installations.

• Power Consumption: None (included in I/O module data sheets).

Current Ratings

• Max Current on Faston Pin: Rated at 4 A maximum.

• Max Current on I/O Connector Pin: Rated at 2 A maximum.

• Load Capacity: Supports multiple backplanes within these limits.

Physical Dimensions

• Length: 240 mm (9.45 inches).

• Width: 87 mm (3.43 inches).

• Height: 60 mm (2.36 inches).

• DIN Rail Compatibility: Fits TS32 or TS35 x 7.5 rails.

• Used Rail Length: Requires 241 mm (9.49 inches) of DIN rail.

Important Note
The 10313/1/1 modules with suffix code 20700 have a different connector layout. Therefore, always verify your suffix code before installation.

Installation Guide for the 10313/1/1

Follow these steps for a proper installation of the 10313/1/1.

Step 1: DIN Rail Mounting
Firstly, secure a TS32 or TS35 x 7.5 DIN rail inside your cabinet. Then, clip the 10313/1/1 onto the rail at the desired position. Ensure the rail length is at least 241 mm for proper fit.

Step 2: Power Supply Connections
After that, connect incoming 5V DC power to the appropriate faston terminals. Specifically, use 'FSC101 or FSC102' for non-redundant backplanes. In addition, use 'FSC101R CP-1' and 'FSC101R CP-2' for redundant backplanes.

Step 3: I/O Backplane Connections
Then, connect your redundant I/O backplanes (10315/1/1) to RCN-1 through RCN-10. For non-redundant backplanes (10314/1/1), use SCN-1 through SCN-10. Consequently, each backplane receives both power and watchdog signals.

Step 4: Watchdog and Expansion Wiring
Furthermore, attach watchdog repeaters (WDRs) directly to the designated connectors. If you need multiple cabinets, link an additional 10313/1/1 using the expansion connectors.

Step 5: Final Verification
Finally, verify all connections are secure before powering on the system. The 10313/1/1 requires no separate power configuration.

Packaging List for the 10313/1/1

• 10313/1/1 5V DC and watchdog distribution module (1 unit)

• Product identification label (1 sheet)

Frequently Asked Questions (FAQs) About the 10313/1/1

Q1: What is the purpose of the 10313/1/1 in an FSC system?

The 10313/1/1 distributes 5V DC power and watchdog signals to I/O backplanes. Firstly, it supplies power to both redundant and non-redundant configurations. Consequently, it eliminates the need for separate power wiring to each backplane.

Q2: How many I/O backplanes can one 10313/1/1 support?

The 10313/1/1 supports up to ten redundant backplanes via RCN connectors. In addition, it supports up to ten non-redundant backplanes via SCN connectors. Therefore, one module can serve twenty backplanes total.

Q3: What is the maximum current on the faston pins?

The faston pins on the 10313/1/1 carry a maximum of 4 A. In contrast, the I/O connector pins carry a maximum of 2 A. Always calculate your total load to stay within these limits.

Q4: Is the 10313/1/1 approved for safety applications?

Yes, absolutely. The 10313/1/1 holds both CE and TÜV safety approvals. However, UL approval is currently pending at this time. Therefore, check your local requirements before ordering.

Q5: What is the difference between 20700 and 207011 suffix codes?

The 10313/1/1 with suffix 207011 follows the standard connector layout described here. In contrast, modules with suffix 20700 have a different connector layout. Consequently, always verify your suffix code matches your system requirements.
