Allen-Bradley 1747-C13 SLC 500 Cable Overview

The Allen-Bradley 1747-C13 is a specialized cable for SLC 500 systems. This cable measures 0.91 meters (3 feet) in length and weighs only 0.09 lbs (0.04 kg) . The 1747-C13 facilitates connections to DH485/RS-232C interface modules. Additionally, it links to couplers interfaced within a DH485 network environment. This cable supports SLC controllers and fixed controllers for versatile connectivity. Consequently, the 1747-C13 is essential for DH485 network installations.

Connector & Port Specifications

The Allen-Bradley 1747-C13 adheres to specific connectivity requirements. One end features a DH485 port for connection to the interface module. The other end uses a J2 (Peripheral) connector port for the link coupler. This compatibility allows integration with various SLC and fixed controller setups. Therefore, the 1747-C13 works seamlessly with standard DH485 network components.

Environmental Specifications

The Allen-Bradley 1747-C13 offers excellent temperature resilience. Operating temperature ranges from 32°F to 140°F (0°C to 60°C) . Storage temperature withstands -40°F to 185°F (-40°C to 85°C) . The cable also maintains reliable performance in humidity levels from 5% to 95% without condensation . Therefore, the 1747-C13 performs consistently in diverse environmental conditions.

Key Features & Benefits

• DH485/RS-232C compatibility – The 1747-C13 connects DH485 interface modules to link couplers.

• Lightweight design – This cable weighs only 0.09 lbs for easy handling and routing.

• SLC controller support – The 1747-C13 works with both SLC and fixed controllers.

• Wide temperature range – Operates reliably from 32°F to 140°F.

• High humidity tolerance – Functions in 5% to 95% non-condensing environments.

• Allen-Bradley quality – Genuine AB cable ensures reliable DH485 network connections.

Installation Guidelines

Follow these steps to use the Allen-Bradley 1747-C13 correctly. First, power down the SLC controller and DH485 network devices. Second, connect the DH485 port end of the 1747-C13 to the interface module. Third, connect the J2 peripheral connector end to the link coupler. Fourth, verify both connections are secure and properly seated. Finally, power up the system and verify network communication.

Do not exceed the cable's bend radius during installation. Keep the 1747-C13 away from high voltage power cables to avoid interference. The cable requires no special maintenance after installation.

Package Contents

Your shipment includes the following items:

• 1 x Allen-Bradley 1747-C13 SLC 500 cable (0.91 meters)

No additional connectors or adapters are included with the 1747-C13 . Therefore, you must provide the compatible DH485 interface module and link coupler separately.

Frequently Asked Questions (FAQ)

1. What is the length of the 1747-C13 cable?
The Allen-Bradley 1747-C13 measures 0.91 meters (approximately 3 feet) in length. This suits short-distance connections between modules.

2. Which controllers work with this cable?
The 1747-C13 works with SLC controllers and fixed controllers. Therefore, it supports most SLC 500 processor models.

3. Can I use this cable for RS-232 connections?
Yes. The 1747-C13 connects to DH485/RS-232C interface modules. It provides the physical link between the module and the DH485 network.

4. What is the operating temperature range?
The Allen-Bradley 1747-C13 operates from 32°F to 140°F (0°C to 60°C). Storage temperature ranges from -40°F to 185°F (-40°C to 85°C).

5. Does this cable work with third-party DH485 devices?
The 1747-C13 is designed for Allen-Bradley SLC 500 systems. While it may work with some third-party devices, we recommend using genuine AB components for reliable operation.

Why Choose the Allen-Bradley 1747-C13?

This SLC 500 cable delivers reliable DH485 network connections for Allen-Bradley systems. For starters, the Allen-Bradley 1747-C13 provides a direct link between DH485/RS-232C interface modules and link couplers. Its 0.91 meter length suits typical panel installations without excess cable slack. The cable weighs only 0.09 lbs, so it does not strain connectors or require heavy support. The 1747-C13 works with both SLC controllers and fixed controllers for broad compatibility. Operating temperatures from 32°F to 140°F accommodate most industrial environments. The cable also tolerates 5% to 95% humidity without condensation for reliable performance in damp locations. Genuine Allen-Bradley construction ensures signal integrity for DH485 communications. Most importantly, the 1747-C13 integrates seamlessly into existing SLC 500 systems.

Order the Allen-Bradley 1747-C13 today for your DH485 networking needs. Specifically, this cable is perfect for connecting SLC 500 controllers to DH485 networks, programming terminals, and link couplers in industrial automation applications.
