9200-03-24-10-00 Bently Nevada Two-Wire Velocity Seismoprobe

Product Overview

• The 9200-03-24-10-00 is a high-performance Two-Wire Velocity Seismoprobe.
• It measures absolute vibration by monitoring casing movement relative to inertial space.
• This Bently Nevada module provides a self-generated voltage output proportional to velocity.
• This specific unit is New and Original in Factory Packing for maximum reliability.

Configuration Breakdown

• 9200 Series — Two-wire Velocity Transducer
  • 03 — 90 ±2.5 Degree Mounting Angle (4.5 Hz Frequency)
  • 24 — 24-Feet Integrated Cable Interface
  • 10 — Circular Mounting Base with M10X1 Stud
  • 00 — Standard No Agency Approvals Required

Technical Data

• Brand: Bently Nevada
• Model: 9200-03-24-10-00
• Sensitivity: 20 mV/mm/s (500 mV/in/s) at calibration angle
• Frequency Response: 4.5 Hz to 1000 Hz range
• Measurement Range: 2.54 mm peak-to-peak maximum displacement
• Velocity Range: 25 mm/s maximum at 100 Hz
• Coil Resistance: 1.25 kΩ ±5% for stable signal loops
• Temperature Range: -29°C to +121°C operating environment
• Material: Anodized Aluminum A204 with Neoprene gaskets
• Anti-Interference: Self-generating coil design resists electromagnetic noise

Expert Review

• The 9200-03-24-10-00 is a legacy standard for industrial vibration monitoring.
• Engineers prefer this 4.5 Hz option for low-speed machinery protection.
• The self-generating design eliminates the need for external power sources.
• This module is highly durable and resists dust and moisture effectively.

Application Scenarios

• Large electric motors and industrial pumps
• Centrifugal air compressors and cooling tower fans
• Hydroelectric turbines and medium-speed rotating equipment
• Compatible with Bently Nevada 3500 monitoring systems

Installation & Maintenance

• Mounting: Use the M10X1 stud on a flat machined surface.
• Alignment: Keep the sensor within 2.5 degrees of the vertical axis.
• Wiring: Connect pins A and B to a 10 kΩ load.
• Testing: Check coil resistance annually to ensure circuit integrity.

Shipping & Warranty

• Stock Status: In Stock – Fast Delivery
• Processing: Ships within 12 to 48 hours
• Logistics: Express via FedEx, UPS, or DHL
• Warranty: 12 Months Factory Warranty

FAQ & Buying Guide

• Can I use this sensor at a 45-degree angle?
  No. This 03 option is strictly for 90-degree vertical mounting.
• Does this require a Proximitor or driver?
  No. The 9200 series generates its own voltage signal.
• What is the primary benefit of the 24-feet cable?
  It allows direct connection to junction boxes without extra splices.
• How do I verify if I need the 4.5 Hz or 10 Hz version?
  Check your machine’s minimum operating RPM. Choose 4.5 Hz for slower equipment.
