2094-BC01-MP5-S | Allen-Bradley Integrated Axis Module Supplier
Introduction:
The 2094-BC01-MP5-S Integrated Axis Module from Allen-Bradley delivers 6 kW continuous power to bus with integrated Safe Torque Off for efficient motion control.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
What Is the 2094-BC01-MP5-S?
When a production line demands reliable multi-axis motion control, the 2094-BC01-MP5-S from Allen-Bradley provides a robust solution. This Integrated Axis Module (IAM) is part of the Kinetix 6000 system and operates at 400 Volt class. It accepts an AC input voltage range of 324-528 Volts rms, 3-Phase, with a nominal input of 360/480 VAC. The module delivers a continuous output power to bus of 6 kW and a continuous output current to bus of 9.0 Amperes. For engineers, this means consistent performance in demanding applications while keeping energy costs predictable.
Key Features & Technical Specs
- AC input voltage range: 324-528 Volts rms, 3-Phase (360/480 VAC nominal).
- Continuous output power to bus: 6 kW — reduces energy waste.
- Continuous output current to bus: 9.0 Amperes — supports steady operation.
- DC input voltage (common bus follower): 458-747 Volts DC — enables flexible power sharing.
- Efficiency: 97% — lowers electricity costs over time.
- Integrated Safe Torque Off (STO) — enhances safety without extra hardware expense.
- Weight: 11.0 lbs (4.98 kg) — simplifies installation logistics.
One distinctive spec is the 97% efficiency rating. This high efficiency directly reduces energy consumption, leading to lower operating costs and a shorter return on investment period.
Applications & Use Cases
The 2094-BC01-MP5-S excels in packaging, material handling, and assembly automation. For example, in a high-speed bottling line, the module’s 6 kW continuous power to bus ensures smooth indexing and filling. Its common-bus follower capability allows multiple axes to share a DC bus, cutting energy costs by up to 20% compared to standalone drives. Additionally, the integrated STO function reduces the need for external safety relays, saving both installation time and component costs.
Installation & Setup
Mount the 2094-BC01-MP5-S on a Kinetix 6000 Power Rail. Ensure a minimum enclosure depth of 198 mm (7.8 in.) and an installation clearance of 50.8 mm (2.0 in.) around the module for proper airflow. Wire the 3-Phase AC input within the 324-528 Volts rms range. For common-bus follower applications, connect the DC input between 458-747 Volts DC. Verify the AC input frequency is 47-63 Hertz. Proper setup prevents costly downtime and extends equipment life.
Maintenance & Reliability
Routine inspection of the 2094-BC01-MP5-S every six months helps maintain its 97% efficiency. Check for dust buildup on the enclosure vents and ensure the internal shunt resistor (115 Ohms) operates within its continuous power rating of 50 Watts. The module’s high efficiency means less heat generation, which reduces wear on surrounding components and lowers maintenance costs over the long term.
Compatibility & Integration
The 2094-BC01-MP5-S integrates with Allen-Bradley ControlLogix PACs via the embedded SERCOS communication interface (catalog number 1756-M0xSE). It supports Kinetix MP, TL/TLY, RDB, 1326AB, and F-Series servo motors, as well as LDAT-Series, LDC-Series, and LDL-Series linear actuators. This broad compatibility simplifies system design and reduces the need for multiple drive types, saving inventory costs.
FAQ about 2094-BC01-MP5-S
Q: What is the continuous output power to bus of the 2094-BC01-MP5-S?
A: The continuous output power to bus is 6 kW, which helps keep energy costs low.
Q: Can the 2094-BC01-MP5-S operate on DC input?
A: Yes, it accepts a DC input voltage of 458-747 Volts DC for common-bus follower applications, enabling shared power that reduces overall system cost.
Q: What is the efficiency rating of the 2094-BC01-MP5-S?
A: The module has an efficiency of 97%, meaning less energy is lost as heat, lowering electricity bills.
Q: Does the 2094-BC01-MP5-S include Safe Torque Off?
A: Yes, it comes with integrated Safe Torque Off (STO) functionality, which eliminates the need for external safety components and reduces installation cost.
Q: What is the weight of the 2094-BC01-MP5-S?
A: It weighs 11.0 lbs (4.98 kg), making it manageable for single-person installation, saving labor time.
Product Support & Availability
The 2094-BC01-MP5-S is available from PetroPartsOnline. In stock and ready to ship, this module supports fast deployment. Contact PetroPartsOnline for current lifecycle status and ordering details.
