Overview of the Schneider Electric 140XBP00200 Racks Backplane

The Schneider Electric 140XBP00200 serves as a compact 2-slot backplane. Specifically, this unit belongs to the Modicon Quantum automation platform. As a result, it provides the physical and electrical backbone for Quantum I/O modules. Moreover, the 140XBP00200 supports local, remote, and distributed I/O modules. Consequently, this backplane offers a small-footprint solution for systems with limited I/O requirements.

Key Technical Specifications of the 140XBP00200

This section details the technical data for the Schneider Electric 140XBP00200.

Slot Configuration and Capacity

First, regarding slot count, the backplane provides 2 free slots for module installation. These slots accept any standard Modicon Quantum I/O module. For example, you can install discrete input modules, analog output modules, or communication adapters. Therefore, the 140XBP00200 suits small control applications or expansion racks.

Product Application and Compatibility

The 140XBP00200 works with three types of I/O configurations. Specifically, it supports local I/O modules connected directly to a Quantum CPU. In addition, it supports remote I/O modules through a S908 remote I/O head. Finally, it supports distributed I/O modules over a Modbus Plus or Ethernet network. As a result, this backplane adapts to many different system architectures.

Mounting and Mechanical Data

The mounting support uses a standard rack style enclosure or panel. You must secure the 140XBP00200 to a flat surface using screws. The product weight measures only 0.23 kg (0.51 lb) for easy handling. Therefore, this compact backplane adds minimal weight to your control cabinet.

Electrical and Bus Characteristics

The backplane distributes power and data to all installed modules. It carries the 5V DC and 24V DC from the power supply to each slot. In addition, it provides the communication bus between the CPU and I/O modules. Consequently, the 140XBP00200 is essential for proper system operation.

Physical Dimensions and Layout

The 2-slot design makes this backplane very compact. You can place it in tight spaces where larger racks do not fit. The Schneider Electric 140XBP00200 shares the same height as larger Quantum racks. Therefore, it aligns perfectly with other Quantum components in a panel.

Country of Origin

This backplane is manufactured in France (FR) . As a result, you can trust its quality and workmanship. The 140XBP00200 carries the same high standards as all Modicon Quantum products.

Installation Guide for the 140XBP00200

Follow these steps to install your Schneider Electric 140XBP00200 correctly.

1. Plan the Layout: First, determine where to mount the backplane in your cabinet.

2. Mark Holes: Next, mark the mounting hole positions using the backplane as a template.

3. Drill and Tap: Then, drill and tap the holes for the mounting screws.

4. Secure Backplane: After that, place the 140XBP00200 against the mounting surface.

5. Tighten Screws: Subsequently, insert and tighten all mounting screws firmly.

6. Install Power Supply: Now, insert the Quantum power supply into the leftmost slot.

7. Install Modules: Then, insert your I/O modules into the remaining slots.

8. Connect Cables: Finally, connect the backplane to the CPU or network adapter using the appropriate cables.

Always mount the 140XBP00200 on a flat, grounded metal surface. Use all mounting points to prevent flexing or vibration damage. Keep the backplane away from high-voltage or high-noise devices.

What is in the Box for the 140XBP00200?

Your package includes the following items:

• 1 x Schneider Electric 140XBP00200 Racks Backplane (2 slots, Modicon Quantum)

• 1 x Product information sheet (basic installation instructions)

Note: The package does not include mounting screws, a power supply, or any I/O modules. You must purchase these items separately.

Frequently Asked Questions (FAQ) about the 140XBP00200

Q1: What type of power supply works with the 140XBP00200?

A: Any standard Modicon Quantum power supply fits the 140XBP00200. For example, the 140CPS11420 or 140CPS12420 are compatible. The power supply occupies the leftmost slot on the backplane.

Q2: Can I use the 140XBP00200 with a Quantum CPU module?

A: Yes, you can install a Quantum CPU on the 140XBP00200 for local I/O control. However, the CPU uses one of the two available slots. Therefore, only one I/O module remains for field devices.

Q3: Is the 140XBP00200 compatible with hot standby (HSBY) systems?

A: No, the 140XBP00200 has only 2 slots. HSBY systems require a dedicated backplane with more slots. For HSBY applications, use the 140XBP01600 or similar larger backplane.

Q4: Can I mount the 140XBP00200 on a DIN rail?

A: No, the Schneider Electric 140XBP00200 does not mount on DIN rail. It requires direct screw mounting to a flat panel or rack enclosure. The backplane has no DIN rail clips.

Q5: What is the maximum number of I/O points on a 140XBP00200 system?

A: The I/O count depends entirely on the modules you install. Each of the 2 slots accepts one Quantum module. Therefore, a discrete 32-channel module gives you 32 inputs per slot. The 140XBP00200 itself has no inherent I/O limit beyond the module capacity.

Why Choose the Schneider Electric 140XBP00200?

The 140XBP00200 delivers a compact backplane solution for small Quantum systems. This 2-slot rack saves valuable panel space in tight installations. You can use it for local I/O expansion near a CPU. Alternatively, use the 140XBP00200 as a remote drop with a S908 remote I/O head. It also works as a distributed I/O station on Modbus Plus or Ethernet networks. Moreover, this backplane carries the same robust build quality as larger Quantum racks. The French manufacturing ensures reliable performance for many years. Therefore, the 140XBP00200 is ideal for applications with only a few I/O points. For example, use it for machine-mounted I/O, test stands, or small process skids. Finally, its low weight and compact size simplify shipping and handling. Consequently, choose the 140XBP00200 for any Modicon Quantum system that needs a small but reliable backplane.
