Introduction:
The SICK KUP-0610-J is a claw coupling with 6 mm and 10 mm bores, designed to connect encoder shafts to drive shafts in rugged industrial environments.
Customer Reviews
UBEST Automation – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Attributes:
Notice: For real-time prices and inventory, please click the button below to contact us.
When encoder shafts meet misaligned drive shafts
In a pump skid retrofit, an engineer found that the encoder shaft and the drive shaft were offset by nearly a millimeter. Direct coupling would have transferred that misalignment into the encoder bearings, risking premature failure. The SICK KUP-0610-J claw coupling solves this by accommodating axial, radial, and angular offsets while transmitting torque reliably. This shaft adaptation coupling features a 6 mm bore on the encoder side and a 10 mm bore on the drive side, making it a direct fit for many SICK encoder models.
Key features and technical specifications of the KUP-0610-J
- Bore diameter (encoder side, D1): 6 mm
- Bore diameter (drive side, D2): 10 mm
- Coupling type: Claw coupling with aluminum flange and polyurethane damping element (80 Shore, blue)
- Nominal torque: 8 N·m maximum (800 Ncm per datasheet)
- Max. speed: 19,000 rpm maximum; max. angle of twist 10°
- Operating temperature: –30 °C to +80 °C (per datasheet)
- Offset compensation: max. axial shaft offset ± 1 mm; max. radial offset ± 0.22 mm; max. angular offset ± 1.3°
- Fastening: Socket set screws per ISO 4029; tightening torque 150 Ncm maximum
- Dimensions: 28.5 mm overall length
The polyurethane damping element absorbs shock loads and vibrations, protecting the encoder from harsh conditions. With a maximum speed of 19,000 rpm, the coupling suits high-speed applications. The operating temperature range of –30 °C to +80 °C covers most oil and gas environments, from cold climates to hot process areas.
Why choose This unit for VFD parts and servo motor replacement?
When specifying vfd parts or planning a servo motor replacement, the mechanical connection between motor and feedback device is critical. This unit provides a dependable interface that compensates for alignment errors. Its claw design allows for easy assembly and disassembly without special tools. The aluminum flange offers rigidity, while the polyurethane element damps vibrations that could otherwise distort encoder signals. This makes it a practical choice for retrofit projects where shaft alignment is challenging.
Applications in oil and gas automation
The SICK unit is suited for use with encoders in motor feedback systems, valve actuators, and metering pumps. In a hypothetical scenario, a refinery uses this coupling to connect an encoder to a variable frequency drive (VFD) on a compressor. The coupling's offset compensation reduces wear on the encoder bearings, extending service life. Its temperature range ensures reliable operation in both cold start-up and hot process conditions.
Installation and maintenance guidance
Install the coupling by sliding the 6 mm bore onto the encoder shaft and the 10 mm bore onto the drive shaft. Tighten the socket set screws to a maximum of 150 Ncm. Ensure that axial, radial, and angular offsets remain within the specified limits. Periodically inspect the polyurethane element for signs of wear or cracking. Because the coupling is a wear item, replace it if vibration or backlash increases. Always follow the encoder manufacturer's safety manual for maintenance procedures.
Frequently asked questions about This unit
What is the operating temperature range of the SICK unit?
The SICK unit operates within –30 °C to +80 °C, as stated in the datasheet.
Can this coupling handle high-speed encoder applications?
Yes, This unit supports a maximum speed of 19,000 rpm, making it suitable for high-speed encoder feedback.
What is the maximum torque capacity of This unit?
The nominal torque capacity is 8 N·m (800 Ncm) maximum.
How do I install This unit coupling?
Slide the 6 mm bore onto the encoder shaft and the 10 mm bore onto the drive shaft, then tighten the socket set screws to 150 Ncm maximum.
What should I do if I need a replacement for my current coupling?
Contact PetroPartsOnline for parts suited to your application's requirements. Please verify current lifecycle status and availability with PetroPartsOnline before ordering.
