FANUC A06B-6096-H301 3-Axis Servo Amplifier Module

The FANUC A06B-6096-H301 is a sophisticated servo amplifier module. It belongs to the A06B product series from FANUC. This module is designed specifically for CNC applications. It can control up to three axes simultaneously. This makes it ideal for complex motion control tasks.

Technical Specifications of the A06B-6096-H301

The FANUC A06B-6096-H301 supports three axes named L, M, and N. Each axis provides an output current of 3 Amps. The total power rating of this module is 1.85 kW. The input voltage range spans 283 to 325 Volts. The maximum output voltage is 230 Volts. This ensures flexible compatibility with various power sources.

Environmental and Operating Conditions

The FANUC A06B-6096-H301 operates between 0°C and 40°C. This temperature range covers most industrial environments. The module withstands a maximum vibration of 5G. This rating ensures reliable operation on moving machinery. The maximum altitude rating is 1000 meters above sea level. No derating is required for installations up to this height.

Cooling and Protection Features

A built-in fan provides active cooling for the FANUC A06B-6096-H301. This fan helps dissipate heat generated during normal operation. The module includes comprehensive protection features. Overcurrent protection prevents damage from excessive load current. Overvoltage protection safeguards against input power surges. Overheating protection shuts down the module at unsafe temperatures. Short circuit protection prevents damage from wiring faults.

Installation Guidelines for the A06B-6096-H301

Mount the FANUC A06B-6096-H301 in a well-ventilated cabinet. Ensure the operating temperature stays between 0°C and 40°C. Do not install this module above 1000 meters altitude without consulting specifications. Keep vibration levels below 5G for reliable operation. Allow adequate space around the built-in fan for proper airflow. Verify input voltage is within the 283-325V range before powering on.

Package Contents

• One (1) FANUC A06B-6096-H301 servo amplifier module

• Mounting hardware and basic installation guide

Common FAQs for the A06B-6096-H301

1. How many axes does the A06B-6096-H301 control?
The FANUC A06B-6096-H301 controls up to three axes. These are labeled as L, M, and N axes on the module.

2. What is the output current per axis on this servo amplifier?
Each axis on the FANUC A06B-6096-H301 provides 3 Amps of output current. The power rating is 1.85 kW total for all three axes.

3. What protection features does the A06B-6096-H301 include?
The FANUC A06B-6096-H301 includes overcurrent, overvoltage, overheating, and short circuit protection. These features enhance module reliability and longevity.

4. What is the maximum operating temperature for this module?
The FANUC A06B-6096-H301 operates from 0°C to 40°C. Keep the module within this range for optimal performance.

5. How is the A06B-6096-H301 cooled during operation?
The FANUC A06B-6096-H301 uses a built-in fan for cooling. The fan helps dissipate heat generated during normal servo operation.

Why Choose the FANUC A06B-6096-H301?

This three-axis servo amplifier delivers reliable motion control for CNC systems. The 1.85 kW power rating handles many common servo motor sizes. Built-in protection features prevent damage from electrical faults. The integrated fan keeps the module cool during heavy use. Order the FANUC A06B-6096-H301 today for your CNC motion control application.
