Lenze E82EV552K4C200 Frequency Inverter Overview

The Lenze E82EV552K4C200 is a frequency inverter and base controller from Series 8200. This device operates on a 3-phase AC mains supply at 400V nominal voltage. It supports vector control for efficient motor performance in dynamic applications. The E82EV552K4C200 handles a typical motor power of 5.5 kW at 400V AC . EMC filter is not included for straightforward integration into existing systems. The IP20 rating indicates suitability for less demanding environments. Consequently, this inverter works well in control cabinets with minimal dust and moisture.

Input & Power Specifications

The Lenze E82EV552K4C200 offers flexible input voltage options. Rated mains voltage is 400V AC with a frequency range of 45/65 Hz . The mains voltage range extends from 320V to 550V AC for brownout tolerance. Additionally, an alternative DC supply ranging from 450V to 775V DC is accepted. Therefore, the E82EV552K4C200 adapts to various power source configurations. Vector control capabilities enhance performance for demanding motor applications.

Environmental & Physical Specifications

The Lenze E82EV552K4C200 operates reliably in standard industrial conditions. Ambient operating temperature ranges from -10°C to +55°C for normal operation. Ambient storage temperature spans -25°C to +60°C for warehouse storage. The IP20 enclosure rating protects against solid objects larger than 12 mm. However, the E82EV552K4C200 is not rated for moisture or dust ingress protection. Therefore, install this inverter inside a suitable control cabinet. The inverter is structured without an EMC filter for simplified system integration.

Key Features & Benefits

• Vector control support – The E82EV552K4C200 delivers precise motor control for dynamic loads.

• Wide voltage range – Operates from 320V to 550V AC for power fluctuation tolerance.

• DC supply option – Accepts 450V to 775V DC for flexible power configurations.

• 5.5kW motor power – Handles typical industrial motor ratings at 400V AC.

• Compact IP20 design – Fits easily into standard control cabinets.

• Series 8200 platform – Integrates seamlessly with other Lenze automation components.

Installation Guidelines

Follow these steps to install the Lenze E82EV552K4C200 correctly. First, mount the inverter vertically on a flat, non-flammable surface. Second, ensure adequate clearance above and below for passive cooling airflow (minimum 100 mm). Third, connect the 3-phase 400V AC mains power to the input terminals L1, L2, and L3. Fourth, connect the motor leads to the output terminals U, V, and W. Fifth, connect the control signal wires to the appropriate terminal blocks. Finally, apply power and configure the parameters for your specific motor.

Do not install the E82EV552K4C200 in dusty or wet locations without an additional enclosure. Use properly sized cables rated for the 5.5 kW motor power. The inverter requires no external EMC filter for basic operation. However, additional filtering may be needed for compliance with strict EMC regulations.

Package Contents

Your shipment includes the following items:

• 1 x Lenze E82EV552K4C200 frequency inverter and base controller

• 1 x Quick start guide with basic wiring diagram

• 1 x Parameter list for configuration reference

• 1 x Control terminal connector plug

No motor or control cables are included with the E82EV552K4C200. Therefore, you must order these separately based on your application. Likewise, no external EMC filter or line reactor is provided.

Frequently Asked Questions (FAQ)

1. What types of motors can this inverter control?
The Lenze E82EV552K4C200 controls standard 3-phase induction motors. Vector control provides excellent speed and torque regulation for demanding applications.

2. Does this inverter include a built-in EMC filter?
No. The E82EV552K4C200 does not include an EMC filter. This simplifies integration but may require external filtering for CE compliance.

3. Can I operate this inverter from a DC supply only?
Yes. The E82EV552K4C200 accepts DC supply from 450V to 775V DC. This allows battery or rectified DC bus operation without AC mains.

4. What is the maximum output frequency of this drive?
The Lenze E82EV552K4C200 supports output frequencies up to 650 Hz. This makes it suitable for high-speed spindle applications.

5. Is the E82EV552K4C200 suitable for outdoor installation?
No. The IP20 rating of the E82EV552K4C200 is not suitable for outdoor use. Install it inside a weatherproof enclosure for outdoor applications.

Why Choose the Lenze E82EV552K4C200?

This Series 8200 frequency inverter delivers reliable motor control for industrial applications. For starters, the Lenze E82EV552K4C200 provides 5.5 kW power at 400V AC for typical motor ratings. Vector control ensures precise speed and torque regulation under varying loads. The wide input voltage range from 320V to 550V AC tolerates power fluctuations. An alternative DC supply from 450V to 775V DC adds installation flexibility. Furthermore, the operating temperature range from -10°C to +55°C suits most factory environments. The compact IP20 design fits easily into standard control cabinets. The E82EV552K4C200 integrates seamlessly with other Lenze Series 8200 components. Most importantly, the absence of an EMC filter simplifies integration into existing systems without compatibility issues.

Order the Lenze E82EV552K4C200 today for your frequency inverter needs. This drive is perfect for conveyors, pumps, fans, and other industrial motor applications requiring vector control and robust performance.
